kaboodle KITCHEN 50532 2x27L Side Mount Pullout Bin Installation Guide
- June 12, 2024
- kaboodle KITCHEN
Table of Contents
2x27L side mount pullout bin
installation guide
50532 2x27L Side Mount Pullout Bin
step 2
Follow these instructions to install your parts and accessories. Things you
need to know
- Always read the full instructions prior to installation.
- Consider possible obstructions to your parts & accessories, like hinges inside the cabinet or adjacent cabinet doors and handles, prior to installation.
- Make sure you leave plumbing and electrical work to qualified trades people. Never try this yourself.
- Make sure you always use safety gear like a mask, ear muffs and glasses when using tools.
- Tip: After marking out the pre-drill holes as per the instructions, take the part that is to be installed and align the appropriate holes with the markings to ensure they match up prior to pre-drilling the holes.
- If you have any questions, contact us on: Australia: 1800 666 078 Monday to Friday between 8:00am and 6:00pm AEST, New Zealand: 0800 522 663 Monday to Friday between 8:00am and 5:00pm NZST or email: info@kaboodlegroup.com.au.
Hardware included
*May be required when
using cabinets different to Kaboodle
Tools you will need
To put your kaboodle kitchen waste bins together you will need the following
tools.
plan select create enjoy
step 2
hardware key
|
---|---
runners| 16mm wood screws
pre-drilling for lid brackets
On both sides of your
cabinet, draw a horizontal line 343mm up from the bottom. Measuring from the
front of the cabinet along these lines, mark out the pre-drill holes at 133mm,
229mm and 341mm as pictured above. Use a 2mm drill bit to pre-drill holes to a
depth of roughly 2.5mm.
pre-drilling for runners
On both sides of
your cabinet, draw a horizontal line 295mm up from the bottom. Measuring from
the front of the cabinet along these lines, mark out the pre-drill holes at
37mm, 235mm and 393mm as pictured above. Use a 2mm drill bit to pre-drill
holes to a depth of roughly 2.5mm.
separating runners
Separate each
runner (A) into two parts by extending the guide (i) and pushing up on the
lever (ii) while continuing to pull apart the two components. The guide should
separate easily from the runner without too much force being applied.
attaching runners
Using the lower
sets of pre-drilled holes, align with the holes on the runners (A) and fix to
the cabinet using 6 x 16mm wood screws (B) as pictured above.
step 2
hardware key
| |
---|---|---
16mm wood screws| lid brackets| m4 8mm screws
attaching lid brackets
Using the top sets
of pre-drilled holes, align with the 2nd, 5th and 7th holes on the lid
brackets (C) and fix to the cabinet using 6 x 16mm wood screws (B) as pictured
above.
pre-drilling for door
Measure from the
bottom of door. Mark out and pre-drill four holes on the back of your cabinet
door as pictured above.
Use a 2mm drill bit to pre-drill holes to a depth of roughly 2.5mm.
attaching door brackets
Position the door
fixing brackets so the elongated holes on each bracket align with the holes
drilled in Step 7. Ensure the open side of the brackets face inward as
pictured above.
Fix the brackets to the door using 4 x 14mm wood screws (F).
reassembling runners Carefully slide
the guides back into the runners. The runners should open and close smoothly
if assembled correctly. Extend the runners once they have been correctly
reassembled.
attaching bin frame
Place
the bin frame (D) carefully onto the extended runners, aligning the holes and
then securing into place with the 4 x M4 8mm screws (E). Note: Support the
runners from underneath when screwing the frame into place. Do not tighten
screws.
inserting bin lid
Slide
the back plastic catches of the bin lid along the top of the lid brackets
until both plastic catches fall into the channels at the back. The front two
plastic catches should fit into the front channels at the same time.
attaching door panel
Note:
Loosen off screws highlighted above before making any adjustments to the door.
Once adjustments are completed, these screws must be tightened again.
installing bins
Place
the bins into the frame to complete assembly.
Note: Max weight capacity, including door if attached, is 25kg.
Caring for your kaboodle parts and accessories
Looking after your cabinets is really easy and with the right care and maintenance they will last you for many years. Just follow these simple steps and if you need any more information you can contact us: Australia: 1800 666 078 Monday to Friday between 8:00am and 6:00pm AEST. New Zealand: 0800 522 663 Monday to Friday between 8:00am and 5:00pm NZST or email: info@kaboodlegroup.com.au.
Hinges, runners and other parts and accessories should be kept dry at all times.
To keep the mechanisms performing at their best, regularly wipe them with a dry cloth removing any dust and grime that may build up.
We offer a dedicated customer service line for advice or any questions you may have on kaboodle products.
Call customer service on:
Australia: 1800 666 078 Monday to Friday
between 8.00am and 6.00pm AEST
New Zealand: 0800 522 663 Monday to Friday
between 8.00am and 5.00pm NZST or email:
info@kaboodlegroup.com.au
