Commercial Electric HLF-HD08a-200 Multi Lumen Led Industrial High Bay Light User Guide
- June 12, 2024
- Commercial Electric
Table of Contents
SKU# 1008 640 846
Model# HLF-HD08a-200
USE AND CARE GUIDE
MULTI-LUMEN LED INDUSTRIAL HIGH BAY LIGHT
Questions,
problems, missing parts? Before returning to the store, call Commercial
Electric Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric
through the purchase of this Round LED High Bay. We strive to continually
create quality products designed to enhance your home. Visit us online to see
our full line of products available for your home improvement needs. Thank you
for choosing Commercial Electric!
Safety Information
For your safety, always remember to:
- Turn off the power supply at the fuse or circuit breaker box before you install the fixture.
- Ground the fixture to avoid potential electric shocks and to ensure reliable starting.
- Double-check all connections to be sure they are tight and correct.
- Wear rubber soled shoes and work on a sturdy wooden ladder.
- Account for small parts and destroy packing material, as these may be hazardous to children.
This fixture is designed for use in a circuit protected by a fuse or circuit
breaker. It is also designed to be installed in accordance with local
electrical codes. If you are unsure about your wiring, consult a qualified
electrician or local electrical inspector, and check your local electrical
code.
WARNING: RISK OF SHOCK. House electric current can cause painful shock or
serious injury unless handled properly.
WARNING: THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF
THE PRODUCT AND THE HAZARDS INVOLVED.
WARNING: MIN 75°C SUPPLY CONDUCTORS.
CAUTION: Turn off the main power at the circuit breaker before installing
the fixture, in order to prevent possible shock.
NOTICE: All electrical connections must be in accordance with local and
National Electrical Code (N.E.C.) standards. If you are unfamiliar with proper
electrical wiring connections obtain the services of a qualified electrician.
Remove the fixture and the mounting package from the box and make sure that no
parts are missing by referencing the illustrations on the installation
instructions.
CAUTION: Suitable for damp locations.
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
- This device may not cause harmful interference, and
- this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the manufacture could void the user’s authority to operate the equipment.
Warranty
LIMITED WARRANTY
This product is warranted to be free from defects in workmanship and materials
for up to 5 years from date of purchase.
If it fails to do so, please contact the Customer Service Team at
1-877-527-0313 or visit
www.HomeDepot.com.
Electrical Ratings
Volts (V)| Frequency (Hz)| Watts (W)| Current (mA)|
Color Temperature (K)| Lumen (lm)| Life (Hrs)
---|---|---|---|---|---|---
120~277| 50/60| 110/150 /200| 2300| 5000| 18000/24000 /30000| 60000
Pre-Installation
TOOLS REQUIRED
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
| Part | Description | Quantity |
|---|---|---|
| A | Safety rope | 1 |
| B | Hook | 1 |
| C | Screw(M5×14) | 1 |
| D | Screw (M4×28) | 1 |
PACKAGE CONTENTS
| Part | Description | Quantity |
|---|---|---|
| A | Fixture | 1 |
Installation
-
Disassembling the package and remove the fixture.
• Turn off the power supply at the fuse or circuit breaker box before you install the fixture.
• Locate the lumen select switch by turning over the fixture to the lens side. In the middle of the fixture is the switch. Move the switch to the desired lumen output. This fixture allows you to select the preferred lumen output: 18000lm, 24000lm and 30000lm.
-
Attaching the Hook to the fixture
• Install the hook (B) by rotating the clockwise into the threaded hole located on top of the driver box.
• Lock the screw (C) on the side of the driver box to secure the hook. -
Installing fixture to the ceiling
• Hang the chain (not included) to the ceiling.
• Fit the hook (B) to the lower end of chain, then lock the hook with screw (D).
-
Installing the safety rope(A) on the fixture
• Thread the safety rope(A) through the metal strut below, while passing the hook of the front safety rope through the loop at the end.
• Hang the safety rope(A) hook on the top of the chain(not included).
-
Connecting the supply wires
• Loosen the wire and pull it into the junction box in the ceiling.
• Connect the three supply wires (black-hot, white- neutral, green-ground) coming from top of high bay fixture to the electrical power supply same color wires.
• If a 0-10v dimming circuit is available, connect the purple and pink wires from the fixture to the same color wires in the dimmer.
• If 0-10v dimming is not desired, wrap the ends of the purple and pink wires with electrical tape to cover the wire.
-
Turning on the light
• After the wiring is complete, restore power and turn on the high bay xture.
0-10V Dimming Schematic
REMARK: Please reference the dimmers manufacturer wiring diagrams for
correct wiring of 0-10 Volt Dimmer.
WARNING: Refer to Local and National Electrical codes fry correctly
sizing wire gauge and making the proper electrical connections and ground
connections to prevent electrical shock and ski offer. Installation requires
knowledge of luminaires and electrical systems. f not qualified, do notattempt
instalation. Contact a qualified licensed electrician, to ensure wiring is
correct and in compliance of local odes.
WARNING: The circuit i intended for connection to an external Class 2
supply. To avoid damage, to assure a cumulative leakage current of less than 3
5mA o the control circuit
Care and Cleaning
- Clean the fixture with a soft, dry cloth.
- Do not use any cleaners with chemicals, solvents, or harsh abrasives.
WARNING: Shut off power at the circuit breaker or fuse panel before cleaning the fixture.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| The fixture will not light. | The power is off. | ■ Ensure the power supply is |
On.
The circuit breaker is off.| ■ Ensure the circuit breaker is in the On
position.
The fuse blows or the circuit breaker trips when the light is turned on.| The
wires are crossed or the power wire is grounding out.| ■ Check the wire
connections.
■ Contact a qualified electrician or call the Customer Service Team at
1-877-527-0313.
FCC compliance information is listed as below:
Responsible party: Leedarson America, Inc.
Responsible party address: 300 Technology Court SE Suite 100, Smyrna, GA 30082
Telephone number: 678-293-8382
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday
9 a.m. – 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.com
Retain this manual for future use.
