CONCORD Media Player with Voice Assist Instruction Manual

June 7, 2024
CONCORD

CONCORD Media Player with Voice Assist

CONCORD Media Player with Voice Assist IMPORTANT SAFETY INSTRUCTIONS

TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
PLEASE NOTE: The lightning flash with arrowhead symbol within an
an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and servicing instructions in the literature accompanying the appliance.

 IMPORTANTSAFEGUARDS

CONCORD Media Player with Voice Assist - warning

  1. All the safety and operation instructions should be read before operating the unit.
  2. The safety and operation instructions should be retained for future reference.
  3. Comply with all warnings on the unit and in the operating instructions.
  4. This unit is equipped with a polarized alternating current. line plug. If the plug fails to fit, try reversing the plug. If the plug still fails to fit, contact your electrician to replace your obsolete outlet. To prevent electric shock, do not use this polarized plug with an extension cord, receptacle, or another outlet unless the blades can be fully inserted without blade exposure. If you need an extension cord, use a polarized cord.

Chapter 1: System Introduction

1.1 Environment Operation:

Temperature limitation: 0-40°C; Humidity limitation: 20-80%
Storage: Temperature limitation: 20-50°C; Humidity limitation: 10-00%

1.2 Package contents

CONCORD Media Player with Voice Assist - Package
contents

Chapter 2: Remote Control

2.1 Introduction

CONCORD Media Player with Voice Assist - Introduction full
remote

Please note: When you use the Voice Search function in Apps, please press the microphone knob on the remote to activate, then press and hold the microphone to speak.

2.2 Using your mobile phone to control the box

Download the APP on your mobile phone as follows(please note that the box and your phone need to be connected to the same Wi-Fi from one router):
For 10S: Download “Android TV Remote” from the APP store.
For Android: Download “Android TV Remote” from the Google Play store.

Once you have downloaded the app, open it up, select “XC6010” and follow the prompts. Enter the code that pops up on the screen to pair your phone with the box.

CONCORD Media Player with Voice Assist -Android tv remote
control

Chapter 3: System Connection

3.1 Installation guide

CONCORD Media Player with Voice Assist - Installation
guide

3.2 Connect TV box to the TV and connect network

CONCORD Media Player with Voice Assist - Connect tv
box ![CONCORD Media Player with Voice Assist

3.3 Set up your TV box

Turn on the box and follow the instructions to choose your preferred language, input your WiFi information, etc. until the setup is complete.

CONCORD Media Player with Voice Assist -Set up your tv
box

3.4 Sign in to your account|

You will be asked to sign in to your account by either using your phone or laptop or by using your password. If you have not as yet created a Google account, then select “Use your Phone or Laptop” to create one. If you already have a Google account, then select the option “Use your Password”.

CONCORD Media Player with Voice Assist - Sign into your
account

Chapter 4: Main User Interface

Once your unit is set up, it will automatically enter the Main User interface. Use your smartphone to control the unit.

4.1 Google assistant

CONCORD Media Player with Voice Assist - Google
assistant

4.1.1 Setting up the language for voice commands

Choose your preferred language in settings when pairing your remote to a movie or TV show. For example, if you want to watch a movie or TV show in French, the default language needs to be set to French. You also then need to speak in French when inputting the voice commands.

CONCORD Media Player with Voice Assist - Setting up the language for voice
commands

4.1.2 Operating voice commands

Press and hold the voice button on the remote control. Do not release until you have inputted a voice command. For example, if you are searching for information relating to Kooi, input the voice command “Kooi”. All information relating to this subject will pop up. You can use voice search in the main interface, on YouTube, Play Store as well as All Apps.

CONCORD Media Player with Voice Assist - Operating voice
commands

4.2 Preloaded Apps

In the second column, all preloaded Apps can be found. For example, Google Play Music & TV, YouTube, Play Store, Play Music, Netflix, Play Games, etc. Any of these Apps can be easily be accessed via this section.
CONCORD Media Player with Voice Assist - Preloaded
Apps
4.3 Settings, Internet status, and the App drawer

Settings, Internet Status, and the App Drawer can be found in the last column.

CONCORD Media Player with Voice Assist - Settings, Internet status and the
App drawer

4.3.1 Device setting

WiFi and Ethernet details can be found under the Network section.CONCORD
Media Player with Voice Assist - Device setting

Sound: Set the sound of the system.
If you want to connect the TV box with your audio devices through the SPDIF port, please set up the audio output first by going to setting-device setting- advanced setting-Sound-Dolby sound-RF and digital sound-SPDIF Raw
App : When selecting App, you will be able to view all apps preloaded onto the box. Select the required App, and then you can either open it, force stop, or uninstall the App.

CONCORD Media Player with Voice Assist - Sound

Screen Saver: Go to App Drawer and select “BurnKeyTool” App. Once a key is successfully burnt, reboot your device.

CONCORD Media Player with Voice Assist - Screen Saver

About: In this section, all information pertaining to your TV box can be found.

CONCORD Media Player with Voice Assist - about

Advance Setting – Display – Screen Resolution: Select the correct screen resolution according to your TV.

CONCORD Media Player with Voice Assist - Advance
Setting

Advance Setting – Display – Screen Position: Zoom in/ out of the screen.

CONCORD Media Player with Voice Assist - Advance
Setting

Advance Setting – More Setting: You will be redirected to the original android setting below.

CONCORD Media Player with Voice Assist - Advance Setting - More
setting

4.3.2 Preference setting

From this section, you can customize your preferred Date & Time, Language, Keyboard, Home Screen, Search, Speech, and Accessibility settings.

4.3.3 Remote & accessories

You can add accessories through Bluetooth by clicking “Add Accessory”, or you can unpair the remote by clicking the remote icon.CONCORD Media Player with
Voice Assist - Remote & accessories

4.3.4 Personal setting

Location: Wi-Fi can be used to estimate location, alternatively, this can be disabled. Security and restrictions Allow installation of apps from sources other than the Play Store or you can disable this function.CONCORD Media
Player with Voice Assist - personal setting

4.3.5 Accounts setting

Delete or add a Google account.

CONCORD Media Player with Voice Assist - Account
setting

Manage all your accounts in this box.![CONCORD Media Player with Voice Assist

4.4 Internet status

By selecting the Network setting, Internet settings can also be selected and configured.CONCORD Media Player with Voice Assist - Internet
Status

4.5 App Drawer

By clicking this icon, all Apps loaded onto the TV box can be viewed.CONCORD
Media Player with Voice Assist - App Drawer
Chapter 5 – How to Install/ Uninstall Apps

5.1 How to install Apps from the Play Store or through an APK installer.

Open the “Play Store” and search for the Apps you want to install, then click “Install”.

CONCORD Media Player with Voice Assist - How to Install Un install
Apps

Alternatively, you can install Apps via a hard drive. Insert the external hard drive into the USB port of the Android box, it will be recognized immediately and ES File Explorer will pop up automatically. Press OK to enter and select the App you intend to install, then press OK and wait until the installation is complete.CONCORD Media Player with Voice Assist - How to Install Un
install Apps 1

5.2 How to uninstall Apps

Open “Play Store”-“My apps”, and you will be able to see all of the Apps you have installed. Click on the App you want to uninstall, then click on the “Uninstall” option.CONCORD Media Player with Voice Assist -How to uninstall
apps

Chapter 6: Browse

Select Chrome from the App Drawer to surf the InternetCONCORD Media Player
with Voice Assist - Browse

Chapter 7: How to manage your files – ES File Explorer

Select “ES File Explorer”, click ok to enter, then you will be able to view and manage all files from hereCONCORD Media Player with Voice Assist - ES
File Explorer

Chapter 8: Tips on pairing your remote

if the Bluetooth remote won’t pair with your Android TV box, try the troubleshooting steps below:

8.1 Connecting the TV box to a keyboard

Connect the Android TV box to a keyboard or mini wireless keyboard via the USB port, press the ESC key on the keyboard, and enter into the system’s initial boot interface (Please use the UP & Down arrows and Enter key on the Keyboard to finish pairing).CONCORD Media Player with Voice Assist - keyboard
icon

8.2 Add Accessory

Select Settings, then scroll down to select “Remote & Accessory”. Select “Add Accessory” to Search for Bluetooth devices.CONCORD Media Player with Voice
Assist - Add Accessory

8.3 Activating pairing mode

To activate pairing mode, press and hold both the V-and PG- buttons on the remote for 5 to 10 seconds simultaneously.CONCORD Media Player with Voice
Assist - Activating pairing mode

8.4 Pairing

The TV box will find the Bluetooth control device, then press Enter to Start Pairing.CONCORD Media Player with Voice Assist -
Pairing

8.5 Pairing completed

Use the Bluetooth remote to navigate the box once pairing is successful.

Chapter 9: Troubleshooting

CONCORD Media Player with Voice Assist -
TroubleshootingCONCORD Media Player with
Voice Assist - Troubleshooting

Chapter 10: Specification

CONCORD Media Player with Voice Assist -
Product Specification

Copyright and Trademark Notices

  • Wi-Fi is a registered mark of the Wi-Fi Alliance.
  • Android, Google Play, and other marks are trademarks of Google lnc.
  • Screenshots and product images are simulated and for instructional purposes only.
  • They may differ from the actual product and are subject to change without notice.
  • The content shown may vary from actual available content, which may change without notice.
