SOMOGYI ELEKTRONIC AD 20 Ultrasonic Aroma Lamp Instruction Manual

ELEKTRONIC AD 20 Ultrasonic Aroma Lamp
Instruction Manual

Safety and maintenance

Function

| STRUCTURE (Figure 1.)
---|---
1| vapor nozzle
2| glass bulb
3| inner lid
4| fan nozzle lid
5| water tank
6| fan nozzle
7| oscillator
8| adapter connector (behind)
9| wooden base
10| vapor and timing push button
11| lighting push button
12| timing indicator lights

AROMA DIFFUSER

IMPORTANT SAFETY INSTRUCTIONS
READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USE AND RETAIN IT FOR LATER REFERENCE!
WARNINGS

1. Before using the product for the first time, please read the instructions for use below and retain them. The original instructions were written in the Hungarian language.
2. This appliance may only be used by persons with impaired physical, sensory or mental capabilities, or lacking in experience or knowledge, as well as children from the age of 8, if they are under supervision or have been given instruction concerning use of the appliance and they have understood the hazards associated with use. Children should not be allowed to play with the unit. Children may only clean or perform user maintenance on the appliance under supervision.
3. Confirm that the appliance has not been damaged in transit!
4. Only for indoor use!
5. Keep the appliance away from heating and other electrical appliances!
6. Connect only to 230 V~ / 50 Hz voltage power sockets!
7. Unwind the power cable completely!
8. Never connect the appliance to the electrical network with wet hands!
9. Do not lead the power cable on the appliance!
10. Do not lead the power cable under carpets, doormats, etc.!
11. The appliance should be located so as to allow easy access and removal of the power plug!
12. Lead the power cable so as to prevent it from being pulled out accidentally or tripped over!
13. If the mains cable is damaged, disconnect the appliance immediately and contact a specialist!
14. When cleaning, filling the water tank, replacing the appliance or other maintenance, disconnect the appliance by unplugging the connection plug.
15. Never touch the water and the parts of the appliance in the water when the appliance is under power.
16. Never operate the appliance without water.
17. Do not scratch the oscillator!
18. Do not immerse the appliance in water, the pieces under voltage cannot get in touch with water!
19. Do not operate unattended in the presence of children!
20. Do not let children play with the unit!
21. Never disassemble the appliance.
22. When not planning to use the unit for an extended period of time, switch it off then remove the power plug from the outlet and empty the water tank.
23. If any irregular operation is detected (e.g., unusual noise or burnt odor from the unit), immediately switch it off and remove the power plug!
24. The actual instruction manual can be downloaded from www.somogyi.hu website.
25. We don’t take the responsibility for printing errors and apologize if there are any.
26. The unit is intended for household use. No industrial use is permitted!
    In the event that the power cable should become damaged, it should only be replaced with cables obtained from the manufacturer or its service facility.

ASSEMBLY AND INSTALLATION OF THE UNIT

1. Place the appliance on a solid, horizontal, flat surface.
2. Follow the steps in figure 2. a.

ASSEMBLY AND INSTALLATION OF THE UNIT

1. Place the appliance on a solid, horizontal, flat surface.
2. Follow the steps in figure 2. a.
3. Remove the glass bulb (1.) and then the inner lid (3.) from the water tank.
4. Replace the inner plastic dip then the glass bulb.
5. Pour distilled water into the water tank up to the circular horizontal line. Do not overfill the water tank, as it does not produce a sufficient amount of cold vapor. Do not allow water to flow into the fan nozzle (6.)!
6. Now, as needed, you can add 5-10 drops. 5-10 drops of good quality, natural aroma oil in the water. Do not use artificial materials as this may damage the appliance.
7. Without waggling the water-charged device, connect the adapter connector to the unit.
8. Connect the unit to a standard 230 V ~ 50 Hz grounded socket.
9. The unit is ready for use.

CLEANING

If hard water is used, over time limescale will be deposited in the water tank and in the parts in contact with the water. The limescale deposited on the oscillator inhibits normal operation.
We recommend that

1. Use distilled water.
2. Clean the water tank and oscillator weekly.
3. Frequently change the water.
4. If it is not used for a long time, clean the entire appliance and store it dry.

Cleaning the water tank, descaling

1. Turn off the humidifier, then discontinue the power supply by unplugging the connection plug.
2. With slightly vinegary water (1 tablespoon full of vinegar in 1 cup of water), rinse the water tank and then with clean water.

Cleaning the oscillator, descaling (figure 3.)

1. Turn off the humidifier, then disconnect from the power supply by unplugging the connection plug.
2. Drop 5-10 drops of vinegar into the oscillator, and wait 2-5 minutes.
3. With soft material, e.g. cotton swab clean the oscillator’s surface.
4. Rinse with clean water.

TROUBLESHOOTING

Check the power supply!
Humidifying is not effective enough.| Reduce the water level!
Clean the oscillator!
All settings are correct, but the vapor does not come out of the device.| Remove the fan nozzle lid (4.), clean it, and put it
back into its place.

DISPOSAL

Waste equipment must be collected and disposed of separately of household waste because it may contain components hazardous to the environment or health. Used or waste equipment may be dropped off free of charge at the point of sale, or at any distributor which sells equipment of identical nature and function. Dispose of product at a facility specializing in the collection of electronic waste. By doing so, you will protect the environment as well as the health of others and yourself. If you have any questions, contact the local waste management organization. We shall undertake the tasks pertinent to the manufacturer as prescribed in the relevant regulations and shall bear any associated costs arising.

FEATURES

Ultrasonic cold humidifier, aroma diffuser, warm white mood light.

• qualitative material consumption: beech wood base, ceramic bulb
• water tank capacity: 180 ml
• humidifying: 15-20 ml / h
• continuous or intermittent humidifying (30 sec on/ 30 sec off) selectable 1, 3, or 8-hour turn off timing amber yellow LED indicator lights
• warm white mood light with two-stage brightness, or gently pulsating light
• in case of water shortage or at the end of the time the humidifying turns off along with the lighting

FUNCTIONS

Vapor and timing push button

indication 1](https://manuals.plus/wp-content/uploads/2022/04/SOMOGYI- ELEKTRONIC-AD-20-Ultrasonic-Aroma-Lamp-indication-1.jpg)
2x| 1 hour humidifying|
3x| 3 hours humidifying|
4x| 8 hours humidifying|
5x| humidifying off|

If you press the vapor button for 2 seconds, the appliance changes to intermittent humidification mode (30 sec ON / 30 sec OFF), which is indicated by the flashing indicator lights. For continuous mode, press and hold the button for 2 seconds. This mode change does not affect the already set-off timing.

Lighting

Fall asleep-helper mode
Press and hold the lighting button (11.) next to the high or low brightness, then the 3 LEDs one after another flashes up. The light will fade slowly over the next 30 minutes and then turn off. You can exit the mode by briefly pressing the button (11.) again.
Setting independent night light
By default, the unit’s lighting function switches off with humidification.
To operate it independently, hold press the two buttons simultaneously until the two LEDs on the left start flashing.
In this mode, if the turn-off timer, or water shortage humidification is switched off, the lighting continues operation.
If you want the lighting function to switch off with humidifying, hold press the two buttons simultaneously until the right two LEDs start flashing.
FILLING THE WATER TANK
Attention! Before charging the water tank, power off the appliance by unplugging the connection plug.
Fill the water tank in accordance with sections 3-6 of the Installation section.
Excessive cold or hot water will block the formation of vapor and may damage the appliance.
EMPTYING THE WATER TANK
Attention! Power off the appliance before emptying the water tank.
Water should only be poured above the “Drain Side” label because water should not leak to the fan nozzle! figure 2. b

TECHNICAL SPECIFICATION

Power supply, mains adapter: ………………………PRI: 230 V~ / 50 Hz SEC: 24 V / 0,5 A
Length of power cable: ………………………………..1,8 m
Dimensions of water tank: ……………………………180 ml
Humidification: ……………………………………………15 – 20 ml/hour, depending on the mode and ambient
Ambient temperature: ………………………………….5-40 °C
Dimensions: ……………………………………………….Ø127 x 137 mm

producer
Somogyi Elektronic Kft.
H – 9027   www.somogyi.hu
Distribuitor: S.C. SOMOGYI ELEKTRONIC S.R.L.
J12/2014/13.06.2006 C.U.I.: RO 18761195
Cluj-Napoca, judeţul Cluj, România, Str. Prof. Dr. Gheorghe Marinescu, nr. 2, Cod poştal: 400337
Tel.: +40 264 406 488, Fax: +40 264 406 489 • www.somogyi.ro
• Producător: Somogyi Elektronic Kft
