SUB-ZERO ICBCL3650RID Series Classic Refrigeration
Classic Series Refrigeration
Classic Series Models
For the Classic series refrigeration, Sub-Zero designers and engineers took a
fresh look at everything, inside and out. Exterior refinements include
redesigned grilles and lower profile hinges. Inside, new technology in food
preservation makes the Classic series refrigeration nothing short of
revolutionary. Features and specifications are subject to change at any time
without notice. Throughout this guide, dimensions may vary by ± 3 mm.
ALL REFRIGERATOR/FREEZER
OVER-AND-UNDER
SIDE-BY-SIDE MODELS
Overall Dimensions
ALL REFRIGERATORS / FREEZER
OVER-AND-UNDER
Overall Dimensions
OVER-AND-UNDER
SIDE-BY-SIDE
Opening Dimensions
STANDARD INSTALLATION
NOTE
89 mm finished returns will be visible and should be finished to match the
cabinetry. The shaded line represents the profile of the unit.
Opening Dimensions
NOTE
89 mm finished returns will be visible and should be finished to match the
cabinetry. The shaded line represents the profile of the unit.
Electrical Requirements
Installation must comply with all applicable electrical codes. International
models from the factory require a 220-240 V AC, 50/60 Hz electrical supply,
fused at the correct rating for the unit. If required by local or national
codes, the power cord can be easily replaced using the power inlet device. The
electrical supply should be easily accessible and positioned either in a
cabinet above the refrigerator, a minimum of 2200mm above the floor or in an
adjacent cabinet. If reestanding then locate the powerpoint as per the diagram
below.
Plumbing Requirements
Installation must comply with all applicable plumbing codes. For Classic
Series models with an automatic ice maker, a pressure limiting valve and 5
metres of flexible 6mm pipe with fittings is included in the refrigerator
carton. Connect the pressure limiting valve close to the water tap, checking
the water flow is in the right direction. Ensure the water connection is 1/2″
BSP male threaded outlet. Fix the 6mm water line to the wall and floor to
ensure it is not compressed when the refrigerator is pushed into the cavity.
The water tap should be easily accessible and positioned either in a cabinet above the refrigerator, a minimum of 2200mm above the floor, or in an adjacent cabinet. The water line must not interfere with the installation of the anti- tip brackets. A reverse osmosis system can be used provided there is a constant water pressure of 2.4–8.3 bar supplied to the unit at all times. A copper line is not recommended for this application.
Classic Series
Alternative locations of power & water supply depend on ease of access.
- Classic Series. Water supply above the fridge. Location of 6mm flexible hose. Tape to wall and floor with pressure limiting valve next to tap.
- Classic Series. Water supply beside the fridge. Location of 6mm flexible hose. Tape to wall and floor with pressure limiting valve next to tap.
- Freestanding location of power supply.
Dual Installation
If two units are installed side by side, a dual installation kit may be required. Installations without a custom filler strip require a dual installation kit. If a dual installation kit is not specified, a 51 mm filler strip is recommended between the units. A custom filler strip is required when installing two French doors or side-by-side models. Dual installations without a filler strip can only be accomplished using two units with opposite hinges. Refer to the illustrations below. Dual installation kits are available through an authorized Sub-Zero dealer.
Side Panel
The custom side panels must be a minimum of 610 mm deep and 13 mm thick.
Routing will be necessary for the side panel to fit flush against the side of
the unit. Refer to the illustrations below. When installing a Classic series
unit with a custom side panel, an accessory kit is required. Stainless steel
side panels are available through an authorized Sub-Zero dealer.
Standard Handles
Optional stainless steel tubular and pro handles are available through an
authorized Sub-Zero dealer. Refer to the chart below for standard handle
lengths.
Classic Series Refrigeration
Warranty
FOR RESIDENTIAL USE
These Warranty Terms and Conditions (‘Warranty’) constitute your agreement
with Sub-Zero Group Australia Pty Ltd (ACN 610 807 899) (‘Sub-Zero’) and will
apply to your service order. The benefits given by this Warranty are in
addition to all consumer guarantees and other rights and remedies prescribed
by the Australian Consumer Law and any other applicable laws. Our products
come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
In addition to your rights and remedies under the Australian Consumer Law, Sub-Zero provides customers with a Warranty where, if any part of a Sub-Zero Product is found upon inspection by an authorised Sub-Zero representative or an associated licensed technician supplied by either Sub-Zero or a relevant approved supplier (including a Sub-Zero factory certified service) (‘Service Representative’) to be defective in materials or workmanship, Sub-Zero will repair or replace the part free of charge as follows:
*FULL TWO-YEAR WARRANTY (Outdoor product full one-year warranty)
For two years from the date of original installation, this Sub-Zero product
warranty covers all parts and labour to repair or replace, under normal
residential use, any part of the product that proves to be defective in
materials or workmanship. All service provided by Sub-Zero under the above
warranty must be performed by Sub-Zero factory-certified service unless
otherwise specified by Sub-Zero, Inc. Where the Service Representative is
unable to identify any fault in the product, Sub-Zero may require the consumer
to provide proof that the product is defective. For the avoidance of doubt,
defective products or parts become Sub-Zero’s property. Service will be
provided during normal business hours.
FULL FIVE-YEAR SEALED SYSTEM WARRANTY
For five years from the date of original installation, this Sub-Zero product
warranty covers all parts and labour to repair or replace, under normal
residential use, these parts that prove to be defective in materials or
workmanship: compressor, condenser, evaporator, drier and all connecting
tubing. All service provided by Sub-Zero under the above warranty must be
performed by Sub-Zero factory-certified service unless otherwise specified by
Sub-Zero, Inc. Where the Service Representative is unable to identify any
fault in the product, Sub-Zero may require the consumer to provide proof that
the product is defective. For the avoidance of doubt, defective products or
parts become Sub-Zero’s property. Service will be provided during normal
business hours.
TERMS APPLICABLE TO EACH WARRANTY
The warranty applies only to products installed for normal residential use.
This warranty does not cover any parts or labour to correct any defect caused
by negligence, accident or improper use, maintenance, installation, service or
repair.
CLAIM PROCEDURE
To claim the Warranty, you must cease using the product when a fault arises,
contact Sub-Zero or authorised Sub-Zero the dealer where the product was
purchased to report the issue and follow Sub-Zero’s directions regarding what
to do next. SubZero’s general contact details are as follows:
Sub-Zero Group Australia
11-19 Bank Place
Melbourne VIC 3000
Phone: 03 9600 2218 Email:
serviceAU@subzero.com
CLAIM PROCEDURE
Except to the extent required by law, all consumer guarantees,
representations, warranties, terms and conditions concerning the products
(whether implied or otherwise) are hereby excluded to the maximum extent
permitted by law. To the fullest extent permitted by law, Sub-Zero excludes
all liability for damage or injury to any person, damage to any property and
any indirect consequential or other loss or damage. stainless steel (doors,
panels, handles, product frames and interior surfaces) is covered by a limited
60-day parts and labour warranty for cosmetic defects. Replacement water
filters and air purification cartridges are not covered by the product
warranty.A full one-year warranty applies to outdoor products. The product
must be approved for outdoor use, designated by model and serial number.
