Aeotec

Doorbell Gen5

SKU: ZW056-B

Quickstart

This is a ****

Siren
for
Australia, NZL, Brasil, etc..

To run this device please connect it to your mains power supply.

To add this device to your network execute the following action:
Turn the primary controller of Z-Wave network into inclusion mode, short press the products Action button that you can find on the product’s housing.

Please refer to the
Manufacturers Manual for more information.

Important safety information

Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law.
The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material.
Use this equipment only for its intended purpose. Follow the disposal instructions.

Do not dispose of electronic equipment or batteries in a fire or near open heat sources.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This
device is suited for use in the region mentioned in the Quickstart section.

Z-Wave ensures a reliable communication by reconfirming every message ( two- way
communication) and every mains powered node can act as a repeater for other nodes
( meshed network ) in case the receiver is not in direct wireless range of the
transmitter.

This device and every other certified Z-Wave device can be used together with any other
certified Z-Wave device regardless of brand and origin as long as both are suited for the
same frequency range.

If a device supports secure communication it will communicate with other devices
secure as long as this device provides the same or a higher level of security.
Otherwise it will automatically turn into a lower level of security to maintain
backward compatibility.

For more information about Z-Wave technology, devices, white papers etc. please refer
to www.z-wave.info.

Product Description

Aeon Labs Doorbell supports playing MP3 music files with a press of this doorbell. It has a 128MB flash memory that can store up to 800 ringtones. The volume can be adjusted manually via short press on the Volume Button, also you can switch the doorbell sound to the next via long press on the Volume Button. You may change/update your doorbell ringtone at any point in time you want by connecting your Doorbell to your PC to update the sound track on your Doorbells flash memory.There is a small Wireless Button, which can trigger the doorbell on the other side of the wall to play the selected doorbell music when pressed.It also act as a repeater that forward Z-Wave command messages to destination nodes if the originating controller is out of range from the destination node.By taking advantage of the Z-Wave mesh network, commands can be routed to their destination via intermediary listening Z-Wave products. Products that are Z-Wave certified can be used and communicate with other Z-Wave certified devices.Also a tool that can be programmed, scheduled, controlled and communicated with from anywhere in the world.

Prepare for Installation / Reset

Please read the user manual before installing the product.

In order to include (add) a Z-Wave device to a network it must be in factory default
state. Please make sure to reset the device into factory default. You can do this by
performing an Exclusion operation as described below in the manual. Every Z-Wave
controller is able to perform this operation however it is recommended to use the primary
controller of the previous network to make sure the very device is excluded properly
from this network.

Reset to factory default

This device also allows to be reset without any involvement of a Z-Wave controller. This
procedure should only be used when the primary controller is inoperable.

Press and hold the Action button that you can find on the product’s housing for 20 seconds and then release. This procedure should only be used when the primary controller is missing or inoperable.

Safety Warning for Mains Powered Devices

ATTENTION: only authorized technicians under consideration of the country- specific
installation guidelines/norms may do works with mains power. Prior to the assembly of
the product, the voltage network has to be switched off and ensured against re-switching.

Inclusion/Exclusion

On factory default the device does not belong to any Z-Wave network. The device needs
to be added to an existing wireless network to communicate with the devices of this network.
This process is called Inclusion.

Devices can also be removed from a network. This process is called Exclusion.
Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is
then performed doing a special manual action right on the device.

Inclusion

Turn the primary controller of Z-Wave network into inclusion mode, short press the products Action button that you can find on the product’s housing.

Exclusion

Turn the primary controller of Z-Wave network into exclusion mode, short press the products Action button that you can find on the product’s housing.

Quick trouble shooting

Here are a few hints for network installation if things dont work as expected.

1. Make sure a device is in factory reset state before including. In doubt exclude before include.
2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing

Association – one device controls an other device

Z-Wave devices control other Z-Wave devices. The relationship between one device
controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always
related to certain events (e.g. button pressed, sensor triggers, …). In case
the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a ‘Basic Set’ Command.

Association Groups:

Group NumberMaximum NodesDescription

1| 5| Association group 1 is the lifeline group. The Doorbell can add max 5 nodes to this group. The Basic report CC or Hail CC (can be configured by parameter 80) can be sent to the associated nodes in association group 1.
---|---|---
2| 5| The Basic Set or Switch Binary Set can be sent to the associated nodes in this group when the Doorbell receives the Basic Set or Switch Binary Set CC from the primary controller. It can add max 5 nodes to this group.

Configuration Parameters

Z-Wave products are supposed to work out of the box after inclusion, however
certain configuration can adapt the function better to user needs or unlock further
enhanced features.

IMPORTANT: Controllers may only allow configuring
signed values. In order to set values in the range 128 … 255 the value sent in
the application shall be the desired value minus 256. For example: To set a
parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56.
In case of a two byte value the same logic applies: Values greater than 32768 may
needed to be given as negative values too.

Parameter 10: Define the functions of Button – and Button+.

Define the functions of Button – and Button+ for your Doorbell.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 11: Define functions of Button -and Button+when short pressing

and long pressing it.

Define functions of Button -and Button+when short pressing and long pressing it.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 2: Set the repetitions for playing doorbell ringtone.

Set the repetitions of playing doorbell ringtone.Note: If the time of playing doorbell ringtone is more than 20s, the volume of ringtone will be reduced to silence no matter how many repetitions of doorbell ringtone are set.
Size: 1 Byte, Default Value: 2

SettingDescription

Parameter 241: Pair the Wireless Button with your Doorbell

Pair the Wireless Button with your Doorbell.When the Doorbell enters into pair mode, the blue LED will blink slowly, at this time, press the Wireless Button once, if the blue LED is changed to be solid, which means the pairing is successful.
Size: 4 Byte, Default Value: 0

SettingDescription

Parameter 252: Enable/ disable lock the configuration parameters

Enable/ disable lock the configuration parameters.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 255: Reset your Doorbell

Reset your Doorbell.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 42: Get the Wireless Buttons battery status

Get the Wireless Buttons battery status.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 5: Set the default doorbell ringtone.

Set the default doorbell ringtone.
Size: 1 Byte, Default Value: 1

SettingDescription

Parameter 6: Select a ringtone to play.

Select a ringtone to play.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 7: Control items

Control items.
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 8: Set the volume of ringtone.

Set the volume of ringtone for your Doorbell.
Size: 1 Byte, Default Value: 10

SettingDescription

Parameter 80: Which notification would be sent when the state of Doorbell

is changed

To set which notification would be sent to the associated nodes in association group 1 when the state of Doorbell is changed
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 81: Enable/disable to send a notification to associated nodes

when the Wireless Buttons battery is in low battery state

Enable/disable to send a notification to associated nodes in association group 1 when the Wireless Buttons battery is in low battery state.
Size: 1 Byte, Default Value: 1

SettingDescription

Technical Data

Controlled Command Classes

• Hail

Explanation of Z-Wave specific terms

• Controller — is a Z-Wave device with capabilities to manage the network.
  Controllers are typically Gateways,Remote Controls or battery operated wall controllers.

• Slave — is a Z-Wave device without capabilities to manage the network.
  Slaves can be sensors, actuators and even remote controls.

• Primary Controller — is the central organizer of the network. It must be
  a controller. There can be only one primary controller in a Z-Wave network.

• Inclusion — is the process of adding new Z-Wave devices into a network.

• Exclusion — is the process of removing Z-Wave devices from the network.

• Association — is a control relationship between a controlling device and
  a controlled device.

• Wakeup Notification — is a special wireless message issued by a Z-Wave
  device to announces that is able to communicate.

• Node Information Frame — is a special wireless message issued by a
  Z-Wave device to announce its capabilities and functions.
