Pipishell PILFK1 TV Wall Mount Full Motion Instruction Manual

INSTRUCTION
MANUAL
Rev0O(A)

PILFK1 TV Wall Mount Full Motion

PLIFK1

Full-Motion TV Wall Mount

(US/CA) 1-800-556-9829
(UK) 44-808-196-3885
support@pipishell.net
www.pipishellav.com

Before getting started, make sure this mount is compatible.

VESA Pattern Compatibility

200 x 100mm
200 x 200mm
200 x 300mm
200 x 400mm
300 x 200mm
300 x 300mm
300 x 400mm
400 x 200mm
400 x 300mm
400 x 400mm
500 x 300mm
600 x 200mm
** 600 x 400mm **

Max: 600 x 400 mm (23.6 x 15.7”)
Min: 200 x 100mm (7.9 x 3.9”)
If the TV weighs more than 132 Ibs (60kg), do not use this product. ****Suitable for 16” (406mm) wood studs, solid concrete, concrete block, and brick walls. DO NOT install on drywall alone. Tools Needed (Not Included)

Contents

Step 1 Attach TV Brackets to TV

1-1 Select TV Bolts Hand thread bolts into the threaded inserts on the back of your TV to determine which bolt (M4, M6 or M8) to use. A minimum of 4-5 turns into the threading is required. Do not turn past the bottom of the hole.
1-2 Spacer and Bolt Configurations
1-3 Attach the TV Brackets to Your TV Ensure the ends with round holes on the TV brackets are directed toward the top of the TV.
Option A (For Flat Back TVs)![Pipishell PILFK1 TV Wall Mount Full Motion

• assembly 10](https://manuals.plus/wp-content/uploads/2023/11/Pipishell- PILFK1-TV-Wall-Mount-Full-Motion-assembly-10.jpg) Add spacers if needed to fit the bolt length and TV back.
  Option B (For Curved TVs) Spacers must be tall enough so that the curved back of the TV does not interfere with the mounting plate.
  Option C (For TVs with a Bump) The TV brackets must be flush on the bump and leveled by spacers on the gap.
  Option D (For TVs with Protruding Cables) Use spacers [B2], [C1] or [C2] to create extra space between the TV and TV brackets.
  Option E (For TVs with Recessed Holes) Spacers [B2], [C1] or [C2] need to fill in the recessed holes on the back of the TV, while keeping the TV brackets as close to the TV as possible.

Step 2 Secure the Front Support Assembly to the Arm Assembly /Wall Plate

2-1 Remove the 4 pre-assembled bolts [B3] from the front support [02] and keep the bolts [B3] for the use in 2-2, then slightly loosen the 4 pre-assembled bolts [B4]. 2-2 Insert the arm extensions [03] into the front support [02]. Then tighten the bolts [B3] and [B4] to secure the arm extensions [03] to the front support [02].2-3 Hang the front support assembly to the arm assembly, making sure that the nut [B5] fits into the groove on the arm assembly [04].
2-4 Secure them with bolts [G1], washers [G2] using Allen key [A3]. Tighten the nut [B5].

Step 3 Mount the Arm Assembly / Wall Plate on Wall

For Wood Studs, follow Page 10.
For Solid Concrete, Concrete Block, and Brick Walls, follow Page 11.

Use a stud finder (not included) to locate wood studs, or use an awl (not included) to find the edges. Mark the edge and center positions. Position the wall plate template at your desired height and line up the holes with your stud centerline. Level the wall plate
template and mark the holes.Drill 4 pilot holes using a 7/32″ (5.5mm) diameter drill bit. Make sure the depth is not less than 2 3/4″ (70mm). Mount the arm assembly / wall plate on the wall using the lag screws. Tighten the lag screws only until they are pulled firmly against the wall plate (DO NOT overtighten).Position the wall plate template at your desired height. Level the wall plate template and mark the holes. Drill 4 pilot holes using a 3/8″ (10mm) diameter drill bit. Make sure the depth is not less than 3″ (75mm). Never drill into the mortar between blocks or bricks.Use a hammer to knock the anchors into the drilled holes. Ensure the anchors are seated flush with the concrete or brick surface. Mount the arm assembly / wall plate on the wall using the lag screws and anchors. Tighten the lag screws only until they are pulled firmly against the wall plate (DO NOT overtighten).

Step 4 Verify that the Mount is Firmly Mounted

Step 5 Hang the TV on the Arm Assembly / Wall Plate

5-1 Slightly unscrew the pre-assembled bolts [S] with a Phillips screwdriver.5-3 Hang the TV to the arm assembly / wall plate.5-3 Tighten the bolts [S] on the TV brackets to secure the TV to the arm assembly / wall plate.

Step 6 Adjustments

6-1 Tilt Adjustment 6-1 Slightly loosen the tilting bolts [T]. Adjust TV to the desired angle, then fully tighten the tilting bolts [T] again to lock the tilt angle.
6-2 Level the TV

6-2 If needed, the TV can be levelled. Slightly loosen leveling bolts [G1]. Level your TV. Retighten the leveling bolts [G1] to hold TV in place.

IMPORTANT SAFETY INFORMATION

NOTE

• Please carefully read all instructions before attempting installation. If you do not understand the instructions or if you have any concerns or questions, please contact our technical support line at 1-800-556-9829 (US/CA) / 44-808-196-3885 (UK) or customer service at support@pipishell.net.
• Before starting assembly, confirm that all parts are included and undamaged. Do not use damaged or defective parts. If you require replacement parts, contact our technical support line at 1-800-556-9829 (US/CA) / 44-808-196-3885 (UK) or customer service at support@pipishell.net.
• Not all hardware included in this package will be used.

CAUTION

• Avoid the risk of personal injury or property damage!
• Do not use this product for any purpose that is NOT explicitly specified in this manual.

Do not exceed the maximum weight capacity. We are not liable for damage or injury caused by incorrect assembly, improper mounting, or inappropriate use.
WARNING

• This product is designed for use in 16” (406mm) wood studs, solid concrete, concrete block, and brick walls. DO NOT install in drywall alone.
• The wall must be capable of supporting four times the weight of the TV and mount combined.
• This product contains small parts that may pose a choking hazard.

Note for Wood Stud Installation (Page 10)

• Avoid the risk of personal injury or property damage! Tighten the lag screws only until they are pulled firmly against the wall plate (DO NOT overtighten).
  Do not use a drill; only use a socket wrench.

• Do not use wall anchors for this mounting option. Wall anchors are used for solid concrete, concrete block, and brick installations only.

• Minimum wood stud size: 1 1/2″ (W) x 3 1/2″ (D) (38 x 89mm).

Note for Solid Concrete, Concrete Block, or Brick Walls Installation (Page 11)

• Avoid the risk of personal injury or property damage! Tighten the lag screws only until they are pulled firmly against the wall plate (DO NOT overtighten).
• Do not use a drill; only use a socket wrench.
• Mount the arm assembly / wall plate directly on the concrete surface.
• Minimum solid concrete thickness: 8” (203mm).
• Minimum concrete block size: 8” x 8″ x 16″ (203 x 203 x 406mm).
• Never drill into the mortar between blocks or bricks.

FAQS

Question 1 The stud spacing is greater than what the TV wall mount was designed for or you can not center the TV wall mount in your desired location.
Board size: Thickness: about 2” (51mm), Width: about 4” (102mm). The wood boards / studs must be capable of holding the weight of the TV plus the TV wall mount.

Step 1 : Secure 2” x 4” wood boards horizontally on the wall to the vertical studs.
Step 2: Attach the TV wall mount to the 2 ” x 4” wood boards. Step 1: Add the two extension brackets (available on Amazon) to the TV wall mount.
Step 2: Fix the extension brackets on the wood studs.
Question 2 How to determine the best height when mounting the TV?
Answer: Scan the QR code to watch the mounting video. https://youtu.be/7KpOapBWbAU

Question 3 Why is it so hard to adjust the swivel angle of the wall mount?
Answer 1 : You must attach the TV to the wall mount / arm assembly before adjustment. Only move the TV by gripping the left and / or right TV edges to swivel, push, or pull. Do not press on the screen itself.
Answers 2 : Add macnine oil (not included) to penetrate the joints of the arm. Question 4 How to raise / lower the TV if the TV wall mount is fixed on the wall?

Answer:
Step 1: Remove the TV from the wall mount.
Step 2: Remove the bolts that secure the TV brackets to the TV.
Step 3: Adjust the TV brackets up or down (See diagram below).
Step 4: Re-attach the bolts to secure the TV brackets.
Step 5 : Hang the TV on the wall mount.
If you need to raise the TV by a few inches, you can choose the upper holes of TV brackets to secure with bolts to your TV.
If you want to lower the TV by a few  inches, you can use the lower holes of TV brackets to secure with bolts to your TV. Pipishell offers products in these categories Please remember us when you need one.
