OLIGHT Freyr 1750 Lumen Long Throw LED Rechargeable Tactical Flashlight User Manual

USER MANUAL

Freyr

Thank you for purchasing this Olight Product. Please read this manual carefully before use and keep it for future reference!

IN THE BOX

Freyr (With Battery)

SPECIFICATIONS

WHITE LIGHT

HIGH| 1750 lumens|
---|---|---
LOW| 300 lumens|
MOON| 5lumens|

RGB LIGHTS

RED LIGHT

|

30lumens

|
---|---|---

GREENLIGHT

|

60lumens

BLUE LIGHT

|

25lumens

(L)5.35 (D)1.59in
(L)136(D)40.5mm| 202g / 7.13oz
(Including Battery and Pocket Clip)

All above specifications are test results based on ANSI/NEMA FL1-2009 Standard.
The tests are performed using the battery included in the flashlight.

BATTERY INSTALLATION

Before first use, please unscrew the tail cap and remove the insulating film. If the battery needs to be replaced, make sure that the positive end of the new battery faces the flashlight head when you put it in.

AVAILABLE BATTERIES****

• 1 x customized 5000mAh 21700 rechargeable lithium battery


BATTERY LEVEL INDICATOR

![OLIGHT Freyr 1750 Lumen Long Throw LED Rechargeable Tactical Flashlight

• BATTERY LEVEL](https://manuals.plus/wp-content/uploads/2021/11/OLIGHT- Freyr-1750-Lumen-Long-Throw-LED-Rechargeable-Tactical-Flashlight-BATTERY- LEVEL-278x300.png)

NOTE: If using moonlight mode, the battery indicator will only display when the battery level is below 10%.

USB MAGNETIC CHARGING CABLE — MCC3

Green: full (over 95%) or disconnected with a flashlight
Time to fully charge| 5 hours (For reference only. When the USB power source is insufficient to  provide 5V 2A power capacity, the charging time will be longer)

CHARGING

•Before the first use please fully charge the product.
•Connect the USB end of the magnetic charging cable to an external USB power source, then attach the other end of the cable to the charging port of the light (best charging efficiency with a 10W (5V 2A) USB power source). The red indicator means charging, while the green indicator means charging completed (battery level ＞95%).
•Only charge with standard MCC3, not compatible with other MCC.

DANGER

• DO NOT shine the light directly into human eyes. This may cause temporary blindness or permanent damage to the eyes.
  When the flashlight is turned momentarily on with the high white light, the proximity sensor will not work. On this account, please DO NOT shine the light towards any object within 20cm for a prolonged period to avoid hazards.

•DO NOT cover the flashlight’s head or stand the flashlight on its head when it is on. The radiation energy may cause damage to the flashlight itself, or even result in the burning of flammable objects nearby.

WARNING

• The tail switch may not work while immersed in seawater or other conductive media. Please try to keep it clean and dry.

• DO NOT use non-protected rechargeable batteries.

• Please lock out the switches if the flashlight is left unused, carried, or transported. The heat built-up due to accidental activation may melt the lens of the flashlight, cause close objects to burn, or even result in unexpected disasters.
  NOTICE

• DO NOT short-circuit the tail switch cap with the ring surrounding it. The short circuit in this case will result in an electric discharge of below 3mA between them and may lead to a complete battery drain if it is in this state for too long.

• The built-in proximity sensor is underneath the front lens. When the high white light is on, the sensor will dim the brightness automatically if it senses a close-up obstruction or a strong light source right ahead, like sunlight, bright street lamps, car headlights, etc. The brightness will restore when the obstruction is gone and the light source is not right ahead.

• The maximum output brightness will decrease as the battery voltage decreases.

• The proximity sensor will stop working when the battery is low and the brightness of the high white light has decreased to a safe level.

• The response distance of the proximity sensor may vary from 3cm to 50cm according to the reflectivity of obstructive objects. The higher the reflectivity, the farther the distance.

• The sensor may NOT work if it is blocked by water, dirt, or scratches on the front lens. Please keep the lens clean to ensure that it works properly.

• The white light should only be set at low mode or moonlight mode when used with the silicone traffic wand.

HOW TO OPERATE

TAIL SWITCH
ON/OFF : Single press the tail switch to turn the flashlight on or off. Half-press for low white light, or full press for high white light.
MOMENTARY ON : Press the tail switch halfway and hold for a momentary low white light or fully press and hold for momentary high white light. Release the tail switch and the flashlight will turn off.
SIDE SWITCH
ON/OFF : Single-click the side switch to turn the flashlight ON/OFF. When turned on, the colored light or moonlight used previously will be activated.

LIGHT COLOR CHANGE : When the light is already on, press and hold the side switch to automatically cycle through the red, green, blue, and moonlight. The current light mode is selected when the side switch is released.
WHITE LIGHT : Quickly double-click the side switch to access high white light, then cycle between high and low white light with each double click. When the flashlight is off, press and hold the side switch for about 1 second to access moonlight.
STROBE: Quickly triple-click the side switch to activate a white light strobe.
LOCKOUT/UNLOCK : When the light is off, press and hold the side switch for about 2 seconds to enter lockout mode after a short flash of moonlight. Under lockout mode, if you click the side switch or tail switch, the red indicator below the side switch will be on for two seconds to signal that the light is still in lockout mode. To exit lockout mode, press and hold the side switch for over 1  second until the light is on moonlight mode.

WARRANTY

Within 30 days of purchase : Contact the original seller for repair or replacement.
Within 5 years of purchase : Contact Olight for repair or replacement.
Battery warranty : Olight offers a one-year warranty for all rechargeable batteries.
MCC magnetic USB charging cable: One year.
For any of the fragile or low-value fittings not covered above, like holster and clip, you can contact the post-sale in 30 days after the purchase, if it has any quality drawback or damage under normal use conditions. If such drawback or damage occurs after 30 days of the purchase or under abnormal use conditions, we will only offer conditional quality assurance as appropriate.

EU-DECLARATION OF CONFORMITY

EU-Declaration of Conformity can be found here :
https://olightworld.com/ec-declaration

USA Customer Support
cs@olightstore.com
Global Customer Support
customer-service@olightworld.com
Visit www.olightworld.com to see our complete
the product line of portable illumination tools.

Dongguan Olight E-Commerce Technology Co., Ltd
Made in China
