Carrier Indus CXI ( 5 Star Inverter) AC User Manual

June 5, 2024
Carrier

Carrier Indus CXI ( 5 Star Inverter) AC

Carrier Indus CXI ( 5 Star Inverter) AC

Technical specification
Type Details
MODEL NO. CAI12IN5R31W1
TONNAGE CATEGORY TR
CAPACITY (HIGH/RATED/LOW) *Watts 3.9 / 3.6 / 1.2
POWER INPUTS (HIGH/RATED/LOW) *Watts 1250 / 995 / 325
FULL LOAD CAPACITY (Watts) 3550
--- ---
HALF LOAD CAPACITY(Watts) 1775
FULL LOAD POWER INPUT*(Watts) 995
HALF LOAD POWER INPUT*(Watts) 350
ANNUAL POWER CONSUMPTION(KWH) 594.17
BEE STAR RATING*** 5 Star
ISEER VALUE(W/W) 4.62
RATED POWER SUPPLY(V-Ph-Hz) 230 – 1 – 50
RATED AMP 4.80676328502415
NET WEIGHT 8 / 26
AIR FLOW RATE 2021 Claim 400
INDOOR NOISE LEVEL (H/M/L) 40/38/32
FAN MOTOR (INDOOR) 4
FAN MOTOR (OUTDOOR) 1
WITH CONNECTING KIT PIPE YES
VALVE SIZE(Inch) 1/2″ x 1/4″
MOISTURE REMOVAL RATE(Kg/Hr) 1.2
INDOOR UNIT (HEIGHT) mm 282
INDOOR UNIT (WIDTH) mm 798
--- ---
INDOOR UNIT (DEPTH) mm 192
OUTDOOR UNIT (HEIGHT) mm 540
OUTDOOR UNIT (WIDTH) mm 780
OUTDOOR UNIT (DEPTH) mm 250
HD FILTER YES
PM 2.5 MICRON FILTER( 3M Brand) NA
PM 2.5 MICRON FILTER NA
AIR CLEANER (COMPOSITE AIR FRESHING MESH) NA
AG+ NANO FILTER NA
HYPER PROTECTIVE FILTER NA
(AVG) ANTIVIRAL GUARD COATED FILTER YES
OUTDOOR UNIT( with Hybrid Jet Grill) HYBRIDJET
TURBO MODE Yes
REFRIGERANT R32
AIR DIRECTION CONTROL Yes
SECURITY LOCK Yes
IDU TEMP DISPLAY Hidden Display
REMOTE CONTROL TYPE LCD Remote
--- ---
REMOTE BACKLIT Yes
AUTO OFF TIMER Yes
AUTO ON TIMER Yes
ECO function Yes
SLEEP MODE Yes
REFRIGERANT LEAKAGE DETECTOR Yes
LOUVER POSITION MEMORY NA
DRY MODE Yes
AUTO FAN SPEED Yes
INTELLIGENT CRF ALERT Yes
AUTO SWING Yes
AUTO CLEANSER Yes
FOLLOW ME Yes
AUTO MODE Yes
AUTO RESTART Yes
DOUBLE DRAIN (EASY INSTALLATION) Yes
FLEXICOOL ( 50% , 75% , 100% Power) NA
FLEXICOOL (40%, 60% , 80% , 100%, 120% Power) YES
--- ---
Wi Fi (Optional) YES
GOOGLE ACTION (Optional) YES
AMAZON ALEXA (Optional) YES
REFRIGERANT COOLING PCB Yes
MY Mode (Favourite mode) Yes
TEMP DISPLAY ON/OFF Yes
ANTI CORROSION COATING (BLUE) Evap- Hair pin in side
HIGH AMBIENT WORKING 55°C even @195V
STABILIZER FREE OPERATION(Even @48°C Yes
KW display KW display- Flexicool

Disclaimer :

All specifications as per IS1391 (Part 2): 1992 Room air-conditioner. Rounded off as per IS 2:1960 rules for rounding off numerical values.
Data shown herein is under test conditions and may vary from model to model. As a continuing policy of product improvement, the design & specifications are subject to change without prior notice.
BEE (Bureau of Energy Efficiency) an autonomous body under Ministry of Power, Government of India, started this initiative of star rating basis ISEER ranging from 1 Star to 5 Star, Annual Electricity Consumption (Units or kWh basis 1600 hrs)
Max Air Flow Rate mentioned
