SSV WORKS MAVR-F65U Dashboard Speaker Panels Installation Guide

May 15, 2024
SSV WORKS

MAVR-F65U
2024-Up Can Am Maverick R XRS
Dashboard Speaker Panels

WARRANTY INFORMATION:

All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship. All SSV Works Speakers are covered by a limited 1 year warranty againsdefects in material or workmanship. Labor for replacement of defective components is not covered.
Contact SSV Works for further warranty information.
**** Please read and understand these instructions completely before installation to avoid possible injury, or damage to the accessory or vehicle.SSV WORKS MAVR-F65U Dashboard Speaker Panels -
Fig

MAVERICK R DASH SPEAKER PANEL PARTS LIST

PARTS LIST IMAGESSSV WORKS MAVR-F65U Dashboard Speaker Panels - PARTS
LIST IMAGES

TOOLS NEEDED FOR INSTALLATION

TOOLS NEEDED FOR INSTALLATION| – T30 Torx Driver| – Phillips Screw Driver| – Pry Tool
---|---|---|---

A. Use a plastic pry tool to remove the driver and passenger side front trims.SSV WORKS MAVR-F65U Dashboard Speaker Panels -
driverB. Remove the front fuse box cover.SSV
WORKS MAVR-F65U Dashboard Speaker Panels - box coverC. Use a plastic pry tool to remove the left and right side center panel trims.SSV WORKS MAVR-F65U Dashboard Speaker Panels - plastic pry
toolE. Remove the left and right side corner trims using a 3mm allen wrench.SSV WORKS MAVR-F65U Dashboard
Speaker Panels - corner trimsE. Remove the left and right side dashboard panels.SSV WORKS MAVR-F65U Dashboard Speaker
Panels - dashboard panelsE. Remove the central dashboard.SSV WORKS MAVR-F65U Dashboard Speaker Panels -
dashboard

MAVERICK R DASH SPEAKER PANEL ASSEMBLY

A. Insert the speaker bucket grommets (included in the kit) to the front dashboard support holes encircled above.SSV WORKS MAVR-F65U Dashboard
Speaker Panels - dashboard supportA1. Remove the driver side under seat storage bin by removing the 2 screws fastened to the floor.SSV WORKS MAVR-F65U Dashboard
Speaker Panels - storage binB. Hold the speaker bucket to the back side of the Mav R speaker panel.SSV WORKS MAVR-
F65U Dashboard Speaker Panels - speakerB. Line up the alignment peg of the speaker bucket to the oval hole on the Mav R speaker panel.![SSV WORKS MAVR-F65U Dashboard Speaker Panels

  • R speaker panel](https://manuals.plus/wp-content/uploads/2024/03/SSV-WORKS- MAVR-F65U-Dashboard-Speaker-Panels-R-speaker-panel.jpg)C. Put the panel on the dash and press in the bucket to the rubber grommet. Run the speaker wire to the speaker bucket.SSV WORKS MAVR-F65U Dashboard Speaker Panels - speaker
wireD. Plug in the speaker and mount it to the driver and passenger side Mav R speaker panels using the screws included with the speakers.SSV WORKS MAVR-F65U Dashboard Speaker Panels -
speakers

MAVERICK R DASH SPEAKER PANEL ASSEMBLY
Reassemble the dashboard by reversing the disassembly procedure.SSV WORKS
MAVR-F65U Dashboard Speaker Panels - disassembly
procedureSSV WORKS MAVR-F65U
Dashboard Speaker Panels - Fig 1We are committed to your satisfaction and we know you will enjoy our products.
If you have questions or need any assistance, please let us know.

https://ssvworks.com

 SOVWORKS.COM
1-818-991-1778 EXT 2
SUPPORT@SSVWORKS.COM

Returns must be made within 30 days of purchase date. Claims for missing items or items damaged in transit must be received within five business days of receipt of merchandise. All returns must be in original packaging and in re- sellable condition. Shipping fees are not refundable.

© 2024 SSV Works, Oxnard,
CA 93030 MAVR-F65U
Rev. A 1-29-24
