PYLE PDUSBPP10 Microphone XLR-to-USB Adaptor User Manual
- June 6, 2024
- Pyle
Table of Contents
PyleUSA.com
Microphone XLR-to-USB Adaptor
PDUSBPP10
USB Mic Interface with Volume Control, Easy USB Plug-and-Play (+48V Phantom
Power)
User Manual
INSTALLATION- WINDOWS 7/8/10
CHANGE SOUND INPUT/OUTPUT ON MAC OS
-
On your Mac, choose Apple menu > System Preferences, Click Sound, then click Output.
-
Select the device you want to use in the list of sound output devices. For any device plugged into the computer’s sound port, choose Microphones.
-
Do any of the following to adjust your sound output settings: Adjust the balance or volume: Drag the volume slider. Show a volume control in the menu bar: Select the “Show volume in menu bar” tickbox so you can turn the volume up or down from anywhere.
To set a separate volume for alert sounds, click Sound Effects.
VOLUME CONTROL
Features:
• Universal USB Microphone Adapter
• Allows the Use of XLR Microphones on Your Computer
• Simple ‘Plug-and-Play’ Operation
• Provides +48V Phantom Power
• Connects to Computer via Included USB Cable| • Adjustable Headphone Volume &
Mix Audio Control
• Compact, Mini USB Audio Interface Design
• Universal Computer Compatibility: Works with PC, Mac, Linux
• For Home, Office & Business Use
---|---
What’s in the Box:
- Mic Adaptor
- USB Cable
Technical Specs:
• Connection Interface:
USB Mini 2.0, Powered / XLR, 3-Pin
• Frequency Response: 20-20kHz
• Mic Gain: -15dB (22dB Max)
• S/N Ratio: 90dB
• Dynamic Range: 100dB
• T.H.D.: 0.9%
• Bit Depth: 24 bit| • Sampling Rate: up to 96kHz
• Construction Material: Engineered Aluminum Alloy
• Computer Operating System Support: Windows XP,
Vista, 7, 8, 10, Mac OS X, Linux
• Power Output: USB-Powered, 500 mA
• USB Cable Length: 5.9’ ft.
• Dimensions (L x W x H): 5.7’’ x 1.14’’ x 1.14’’ -inches
---|---
