Loocam LN8W4B Wireless Security System User Guide
- June 6, 2024
- Loocam
Table of Contents
Quick Start Guide
Wireless Security Camera System
Copyright
2021 © Loocam Technology LLC, California. All rights reserved. Apple and App
Store are trademarks of Apple Inc., registered in the U.S. and other
countries. Google and Google Play are trademarks of Google Inc.
ATTENTION: Please read carefully and keep this guide in a safe
place.www.loocam.com
What’s in the box
Product Overview
NVR Back Panel
Installation and Setup
Hard Drive Installation
The NVR may not include HDD (Hard Disk Drive) depending on the kit you
selected. This NVR works with most 3.5″ SATA HDD (supports up to 8TB).
Note: Please skip this step if HDD is pre-installed in your NVR.
- Unplug your NVR from power, unscrew and remove the top cover.
- Connect the SATA power and data cables from the NVR to the corresponding ports on your HDD (as shown).
- Place the Hard Disk into the DVR. Arrange the wires neatly.
- Hold the HDD and the NVR steadily, gently turn it over and line up the holes on the HDD with the holes on the bottom of the NVR. Using a suitable screwdriver, screw the provided screws into the holes. Assemble back the cover.
- After installing a Hard Disk, you need to first format the Hard Disk before recording. Right-click the mouse > go to Main Menu > Disk Management > Select the Hard Disk > Click Format > Apply.
Note: For a MicroSD card, simply insert the card into the allocated slot at the back of the NVR. The surveillance-certificated hard drive is recommended. Compared to HDD (which supports full-day recording), a MicroSD card is an economical alternative for light recording.
NVR can only support one type of storage at one time.
Security System Connection
To ensure that the product works properly and is not damaged while in transit, we recommend you test the whole system before installation.
-
Install the antenna on the back panel of the NVR as shown in the diagram
on page 1. -
Next, install the other antennas on the back of each camera. Make sure the antennas are tightened.
Note: Antennas for NVR and Cameras are the same. -
Connect the monitor to the NVR using HDMI or VGA.
-
Use a network cable to connect the NVR to the router.
-
Insert the USB mouse into the USB port on the rear panel of the NVR
-
Connect the cameras to the power adapter (DC 12V/1A).
-
Connect the power adapter (DC 12V/2A) to the NVR power input.
-
Plug power adapters into the wall socket.
**Paring Add-on Camera
**
The cameras have been paired before shipping. Simply plug and play. It is
recommended to test the system with the cameras before installation. If it
does not work, please contact Loocam customer service.
In the event of adding new add-on cameras or pairing the cameras after
resetting, please
follow the steps below:
-
Right-click on the mouse which is connected to the NVR for the operation menu.
-
Click on the
to enter the IPC channel configuration interface.
-
Click on the search button on the IPC channel configuration page to search for the corresponding IPC;
-
Next, select the IPC you wanted to add from the search result and click wireless add. Upon successful connection, the connected IPC will appear at the bottom of the page.
Now you can see a live feed from the newly added channel of the camera.
Operating NVR System
NVR System Setup
After connecting the system, power on the NVR, and a Wizard page setting
appear. On the Wizard page setting, you can edit the device name, select
Language, Date Format,
Time Format, Time Zone, System Date, and System Time.
Password Setting:
From the NVR live viewing screen, right-click and tap Main Menu > Setup >
Users. Select the account you want to set password and click <Change
Password>. Default
password (Empty). When setting the password, please enter at least 6
characters or more.
Note: You can write down the password in case you forget.
Password ：
Video Recording
From the NVR live viewing screen, right-click and tap Main Menu > Search, the
system will display as shown:
Search the video you want via
Time or Event, then click on the play button.
Select the channel
Start playing
Previous Record:
Move to last recorded event
Next Record:
Move to the next recorded event
Fast Forward:
Video can be played at different speeds, from 1/4x to 16x speed.
Rewind:
Video play can be rewind at 1x, 8x, 16x and 32x speed.
Screen Display Mode:
Both single-screen and multi-screen are available. You can choose how many
channels
you want to playback one time. Channel without records displays a blank
screen.
Motion Detection
After setting motion detection, the NVR will only record when it detects
movement or activity.
Right-click > Main Menu> Setup > Alarm > Motion.
Select the camera you want to set up motion detection by ticking the box under
‘Enable’
Note: An icon will be shown
when motion is detected by the camera and the system will start recording.
Human Figure Detection
This NVR supports human figure detection. When the human figure is detected,
it will trigger an alarm/recording. Combining motion detection and human
figure detection, the false alarm rate will decrease.
Backup via USB flash
drive
Insert the USB flash drive. Right click > Main Menu> Backup > select channel
and time > Search >select the video clips > Backup > select storage media >
Start.
System Upgrade via USB flash
drive
You can contact our official customer service or download the latest program
directly from the official website. Copy the firmware file to the root of the
USB flash drive. Then proceed as follows:
First, plug in the USB flash drive, and then unplug the NVR power supply.
Plugin the power plug, you will see an “upgrading” upgrade interface on the
monitor. Please wait for a while. After the upgrade is completed, unplug the
USB flash drive and the upgrade has completed.
Note: After the upgrade is completed, please do not restart the power
supply when the U disk is still plugin, otherwise the system will perform the
upgrade again.
5. Setup for Remote Viewing (Smartphone)
APP Download
Scan the QR Code or search Loocam in AppStore or Google Play to download the
free app.
|
iOS
https://itunes.apple.com/cn/app/loocam/id1359054976?mt=8
|
android
https://play.google.com/store/apps/details?id=com.ansjer.loocamccloud_a
---|---|---
This camera system can work without
internet connectivity. For the best user experience, remote control via the
internet is recommended.
After downloading, register and create an account.
Note: You can write down your account
information below, in case you forgot. (Registered email or phone number, user
account name, password or a security question)
Add Device
-
Go to Loocam App on your phone, tap the icon [+] in the top right corner to add a device.
-
Select your device type of NVR.
-
Scan the UID QR code on the NVR cover. This UID QR code also can be found on the
NVR startup screen or in the NVR main menu (Information-System-Device ID). -
Follow the instructions to add your device and watch the live streaming video.
Note Two-way voice via Loocam App for cameras with built-in mic and speaker.
6. Setup for Remote Viewing (PC)
Client Installation
Download Mac or Windows client (AVSS) from Loocam’s official website
www.loocam.com.
Note: If you have registered an account through Loocam APP, simply log in
using the same account for AVSS.
Add/Manage Device
Click under Device List to add a device, edit a device, or configure the
device.
Live View and Control
Once you have successfully added the device, click on the device name of the
device you want to view under Device List, select the channels to start
viewing.
Camera Installation
Step 1: Loosen the bracket screws, fold the camera bracket and screw
the antenna in the
corresponding place (as shown in the diagram).
Note: Install the cameras at least 7ft. above the ground with antenna
vertical for optimal signal.
Step 2: Drill holes on the wall according to the position of the
mounting hole sticker, and insert the plastic anchors into the holes.
Step 3: Align the mounting hole of the camera with the wall with the
plastic anchors, then screw the screws in.
Installation Tips
- Refer to the image right for the ideal position. It is recommended to place the camera at least 7 ft. above the ground and tilting it towards the area of surveillance for best visual coverage.
- Ensure that the camera has a clear line of sight.
- Place the camera at no more than 20 ft away from the area you want to monitor.
- Install the camera within the wireless signal range of the NVR.
- Install outdoor without worry. Cameras have strong weather resistance casing (IP66 full protection grade).
- Install the cameras within the maximum line-of-sight (LOS) distance of 2000ft. from the
NVR. The maximum Los distance will be reduced by each wall, ceiling, or major obstruction between the cameras and the NVR.
Warranty and Support
Loocam Technology LLC provides a one-year limited warranty from the date of
purchase. Please keep your dated purchase receipt which is required for
limited warranty requests. For more details on the warranty, please visit
www.loocam.com.
If you have any questions in regards to your new Loocam security product,
please email us loocare@loocam.com.
@Loocam
@LoocamTech
@LoocamTech
