JAMARA 460361 GT R Mercedes-AMG Instructions

[](https://manuals.plus/wp-content/uploads/2022/07/JAMARA-

logo-37.png)JAMARA 460361 GT R Mercedes-AMG

[

](https://manuals.plus/wp- content/uploads/2022/07/JAMARA-460361-GT-R-Mercedes-AMG-product.png)

General information

JAMARA e.K. is not liable for any damage caused to the product itself or through this, provided this is due to improper operation or handling errors. The Customer alone bears the full responsibility for the proper use and handling, including without limitation, the assembly, the charging process, the use and choice of the operation area. Please refer to the operating and user instructions, it contains important information and warnings.

Suitable for children over 3 years.
Warning: Not suitable for children under 36 months.

RISK OF SUFFOCATION

Contains small parts which can be swallowed. Keep away necessarily from children

• Before playing, remove all protective films from all parts.
• This product is not intended for use by individuals (including children) with reduced physical, sensory or mental capabilities or lack of experience and / or knowledge.
• Due to its top speed this toy is not suitable for children under 3 years!
• Minimum age: 3 years (Depending on development, a minimum age of 4 years could be appropriate), Maximum weight: < 25 kg

Before assembly

• Adult required for assembly. Keep children away while assembling.
• Tools (not included) needed for assembly: screwdriver.

Certificate of Conformity

Hereby JAMARA e.K. declares that the products “Mercedes-AMG GT R, No. 460361, No. 460362, No. 460548“ comply with Directives 2014/35/EU, 2014/53/EU, 2011/65/EU and 2009/48/EC.The full text of the EU Declaration of Conformity is available at the following Internet address: www. jamara-shop.com/Conformity

caution

• Read the complete instructions and security instructions carefully before using the model.
• To prevent accidents and injuries, DO NOT leave your child unattended during the operation of the vehicle. Never let your child out of your sight while driving a vehicle.
• DO NOT use the vehicle on public roads or places or other dangerous locations.
• The model stops after releasing the accelerator, independently on a horizontal surface. The vehicle has no brake or parking brake. Do not operate the vehicle uphill or downhill, and secure it when parking.

DANGER.

• For safe driving, you should make sure that your Child understand and adheres to the following rules:
  • Always sit tight, do not get up during the ride.
  • Never take additional Children for a ride. (The vehicle is only suitable for 1 person)
  • Hold tight.
  • Never drive without shoes.
  • Never drive in the dark.
• Keep hands, hair, loose clothing and any other item away from any rotating parts.
• The Model should not be used in rooms or halls with high humidity (for instance garages), in the rain or on wet surfaces. Risk of malfunction or damage to electronics and housing.
• The model is not water- or splash-proof. Only operate on asphalted surfaces (such as paving stones). The model is not suitable to be operated in grass or loose soil.

Parts

1. Chassis
2. Driving wheels 2x
3. Screws 1x Ø5×38
4. Steering wheel
5. Rear Spoiler
6. Screws 1x Ø4×12
7. Rearview mirror 2x
8. Wheel cap 4x
9. Front-wheel 2x
10. Transmitter
11. Windshield
12. MP3 Cable
13. Charger
14. Split pin
15. Washer 6x Ø 10 mm
16. Nut

Assembly of the rear wheels

• Place the body with the underside facing up.
• Attach a drive wheel (6) to the gear unit.
• Slide a washer (14) onto the rear axle.
• Fix the whole thing with a plit pin (13). Bend the ends of the split pin back using a pair of pliers.
• Finally, put a cover (4) on the wheel
• Repeat this on the other side.

Assembly of the front wheels

• Attach a wheel (5) onto the axle.
• Slide a washer (14) onto the axle.
• Fix the whole thing with a plit pin (13). Bend the ends of the split pin back using a pair of pliers.
• Finally, put a cover (4) on the wheel
• Repeat this on the other side.

Steering wheel assembly

Connect the cable from the steering wheel to the cable of the dashboard. Install the steering wheel (2) in the Intended position and secure it with the locking screwand (11) and nut (15).

Attach the Windshield
Insert the tabs on the windshield (8) in the slots on the vehicle body, push until you hear it click into place.

Attach the view mirrors
Install wing mirror (3) to the designated position, and fasten it.

Attach the rear Spoiler
Press the pins of the rear Spoiler (7) into the grooves at the rear of the body.

Battery connection

• Connect all connectors as shown. Only plug matching connectors into eachother and be sure not to reverse the polarity.
• Make sure the red wire is well connected with the red terminal on the battery, and same as the black one.

Charging Your Vehicle[

](https://manuals.plus/wp- content/uploads/2022/07/JAMARA-460361-GT-R-Mercedes-AMG-fig-22.png)

• The power swich must be turned in OFF position when charging.
• Insert the charger (4) into the socket – the LED lights up green. Connect the charger to the charging socket.
• The LED on your charger lights up red as long as the battery is being charged. If the LED lights green again, the battery is fully charged.
• The charge time is 9 hours.
• Do not charge the battery more than once within 24 hours.
• Charger and battery heat up during the charging process.

Attention!

• Let the model cool off sufficiently after each use before putting it back into operation. When using an additional batteries let it cool off for minimum 15 minutes until the model is operated again. Overheating can damage the electronics or may result in fire.
• Use the charger only in dry rooms.

Caution!
Always switch off the model immediately after each use. Immediately after each use the battery should be disconnected from the model. The battery can be deeply discharged by leaving it switched on accidentally or leaving it plugged in. Deep discharge causes the battery to lose power or can be damaged to such an extent that charging or discharging is no longer possible or the battery can self-ignite during charging or discharging (fire hazard). Never attempt to charge or discharge deeply discharged batteries. The battery voltage should never fall below 11,9 volts to avoid deep discharge. The fully charged battery has a voltage of approx. 13 Volt. After use, the intact battery should be fully charged immediately after a cooling phase of at least 10 minutes but at the latest after 12 hours to avoid subsequent deep discharge by self- discharge. If the battery is not used or stored for a longer period of time, the battery should be checked for voltage (min. 12,3 volts) or dama-ge at least every 3 months and charged or disposed of if necessary.

Description of the functions on the transmitter[

](https://manuals.plus/wp- content/uploads/2022/07/JAMARA-460361-GT-R-Mercedes-AMG-fig-23.png)

This transmitter has the following function

1. Forward
2. Backward
3. Binding button
4. right
5. left
6. Speed adjustment
7. Stop (Transmitter and model are nonfunctional)
8. Speed display

Binding of transmitter and model
If the model does not respond to the transmitter, press the connection button until the speed info is permanently lit and does not blink anymore.If this does not work, repeat the process.

Functions[

](https://manuals.plus/wp- content/uploads/2022/07/JAMARA-460361-GT-R-Mercedes-AMG-fig-24.png)

1. ON/Off switch With the ON / OFF switch you start the vehicle.
2. Shift Lever

• Forward
  Press the “Forward-backward switch” on the “Forward” position.
  Press the “Foot pedal”, the model drives forward.

• Reverse:
  Press the “Forward-backward switch” on the “Backward” position.
  Press the “Foot pedal”, the model drives backward

• Press the “Foot pedal”, the model drives backward.

• IMPORTANT
  Always stop vehicle when changing the direction to avoid damage the gears and motor.

• Light button

• Speed

  • High speed
    Fast speed

  • Low speed
    Slow speed

• Sound and connecting external audio sources

• Foot pedal
  To move the car, press the pedal down.
  To brake or slow down, release pressure from the pedal.

Only use in direct supervision of an adult

To control the vehicle a minimum skill level and caution is needed. Make sure you are familiar with the operation of the model and its characteristics. The model is heavy. This is an increased risk of injury and damage in the event of loss of control. Avoid any kind of intentional or unintentional collisions with objects or hazards to persons.

Troubleshooting – The vehicle does not run

• The battery may low on power.
  After each use, or once a month minimum, charge the battery. Do not leave the battery on the charger for more than 15 hours.

• The battery connector or wires are loose.
  Make Sure the battery connectors are firmly plugged in to each other.

• The electric system is damaged.
  Water may have corroded the system, or loose dirt, gravel or sand might have jammed the switch.

Disposal restrictions

Batteries and accumulators must not be disposed of in domestic waste. You are obliged to dispose of batteries (seperate collection) appropriately. After use you can return batteries free of charge to the retail store. As batteries contain substances that can be irritant, can cause allergy and are highly reactive, separate collections and proper recycling is important to the environment and to your health. If the batteries are marked with a chemical symbol Hg, Cd or Pb below the crossed-out waste bin on wheels it refers to that more than 0.0005% of mercury (Hg), more than 0.002% of cadmium (Cd) or more than 0.004% Lead (Pb) is included.
