**Liene Pearl K100 Portable Photo Printer User Manual
**
Please read this user manual carefully before use and keep it properly.
Product overview
Tip: When the machine is halted, press the reset button with a pin to
forcibly shut down.
Do not press the reset button when the printer upgrades the firmware, so as to
avoid damaging the firmware and making the printer unusable.
Load photo paper
Open printer paper tray cover
Firmly press the paper tray cover to hear a Click sound. The paper tray cover is in place.
Load mono paper or ZINK paper as needed
a. Load mono paper
Unpack the paper and load the entire pack into the printer, making sure the
glossy side of the paper is upward.
b. Load ZINK paper
Unpack the paper and load the entire pack into the printer, making sure that
the Smart Sheet is at the bottom and that the barcode is bottommost and the
glossy side of the paper is upward.
Tip: The Smart Sheet must be placed at the bottom.
Close paper tray cover
Usage
Power on
Press and hold the power button for 3 seconds to turn on the printer. The printer status light will be white and then turn into an orange blink while it waits for connecting with the phone.
Connect Liene Photo App
-
Search “Liene Photo” in iOS App Store or Google Play, or scan the QR code below to download and install “Liene Photo” App.
-
Open Liene Photo App home page, click “+”, or click “Switch Printer” icon on the top left corner, select “+”, and add devices according to the App prompt.
Tip: Due to the upgrade and update of Liene Photo App, the actual operation may be slightly different from the above description, please follow the current guidelines in the App. Once the printer is successfully connected to your phone, you can print photos through the Liene Photo App.
Instruction for buttons
| Press and hold the power button for 3 seconds| ON/OFF
---|---|---
| Press and hold the power button for 7 seconds| Restore factory settings
Tip: In the firmware upgrade status, the upgrade will not be interrupted if you press and release or press and hold the power button.
To save battery power, the printer will automatically shut down after 10 minutes or more of standby.
Battery level indicator
| Orange light on| Low battery level
---|---|---
| White light on| Charging
| Light off| Battery is sufficient/ Fully charged
Status indicator
| Light of| Power off
---|---|---
| White light on| Standby
| Orange light blink| Bluetooth is not connected
| White light blink| Printing / Firmware upgrade
| Orange light on| Printer failure
| White and orange are on for 1 second respectively| Restore factory settings
Troubleshooting
The Liene Photo App will alert you to various error conditions through in-app messaging. Follow the app instructions to resolve issues. For additional help on specific issues with your Liene Photo printer, see the FAQs on www.liene- life.com.
Warranty & Support
Thank you for choosing Liene! We really hope you will enjoy the product! Your satisfaction means everything to us!
Liene provides a 1-year warranty for this product, please contact us immediately if you encounter any of the following, and we will supply a replacement or refund.
- Receiving defective items.
- Parts are broken in transit.
- Item stops working within warranty.
To provide more prompt and professional after-sale service, you may contact us via below ways.
E-mail: [email protected]
Caution & Notice
Use and maintenance of printer
- The printer is best used in an environment with a temperature of 20 ℃ – 25 ℃ and a relative humidity of 40% – 60%. Improper ambient temperature and humidity will affect the printing quality, resulting in paper jam and incomplete printing.
- Please wipe this product with a soft dry cloth. Do not use volatile liquids such as wet cloth or paint thinner to wipe during cleaning.
- Please keep the keep the paper tray cover closed closed to prevent dust or other debris from falling into the printer.
- Please make sure that the printer is fully charged or charged when upgrading the firmware. Do not click the reset button during the upgrade to avoid damaging the firmware and making the printer unusable.
- The printer has built-in lithium battery, which should be stored in high temperature environment and charged at least once every 3 months. It is forbidden to use it after soaking in water.
- Do not place the battery in an extremely high temperature environment, such as sunlight, fire, microwave oven, oven, etc., as this may cause an explosion or leakage of flammable liquids or gases.
- If the battery becomes severely swollen, do not continue to use it.
- Only batteries approved by the manufacturer are allowed. Replacement with the wrong type of battery may make the safety protection failure, and there will be explosion, fire and other risks.
- Do not disassemble, impact, crush or cut the battery, which may cause explosion.
- Please do not dispose of the batteries in the household garbage and follow the appropriate regulations for safe disposal of used batteries.
Use of photo paper
- Please do not put the paper where children can touch it to avoid accidental touch. High temperature and direct sunlight will change the color of photographic paper; Humid environment, water and other solutions will make photographic paper discolor and bend deformation; Dust will scratch the surface of photographic paper and damage the machine.
- Do not use unofficial Mono paper, ZINK paper or the Smart Sheet of ZINK paper to ensure the printing quality.
- Do not mix the ZINK paper and the Smart Sheet in different packs, otherwise the printing quality will be affected. When a pack of ZINK paper is used, it is recommended to load the whole pack, load another pack after it is used up, and calibrate it with the Smart Sheet in the original pack.
- Please do not unpack the photographic paper package in advance, and unpack the photographic paper and load it into the printer before preparing for printing.
- When loading the paper, do not touch the glossy side of the paper to avoid leaving fingerprints and affecting the printing quality, and ensure that the glossy side of the paper is upward; When placing the ZINK paper, place the Smart Sheet barcode down at the bottom and lay it flat inside the machine.
- You can only fit up to 10 sheets of color photographic paper and 1 blue calibration card, or 10 sheets of black and-white photographic paper. If load too much photographic paper, it will cause printing errors.
- During printing, do not cover the paper outlet or touch the paper, as this will affect the print quality; do not forcefully pull the paper to avoid damaging the printer.
- If there is paper jam in printing, just restart the printer according to the prompt of App, and the paper jam will be automatically cleared. Please do not try to pull out the paper jam.
- Do not damage or bend photographic paper, or use damaged photographic paper to print, so as to avoid paper jam and other errors.
- When pasting photos, choose a smooth and flat surface to avoid moisture and prevent curling, warping or degumming.
Use of Smart Sheet for ZINK photo paper
-
Each package of ZINK photo paper contains 1 Smart Sheet.
-
To ensure the best ZINK paper printing effect, please load the Smart Sheet and ZINK photo paper in the same package of ZINK photo paper in the printer. Each Smart Sheet is customized for ZINK photo paper in the same package.
-
Before starting printing, in order to optimize the printing quality of this package of ZINK photo paper, the printer will automatically feed the paper with a Smart Sheet to clean and calibrate the printer.
-
Using Smart Sheet in other ZINK photo paper packages may lead to poor print quality.
-
Please keep the Smart Sheet before using the same package of ZINK photo paper. If the print quality is not as good as expected, you can use it again. Just print the Smart Sheet with the barcode down under the remaining photo paper.
-
The Smart Sheet can also optimize the printer quality of Mono photo paper.
If you want to use mono photo paper only for a long time, you need to keep the Smart Sheet of random ZINK photo paper. -
When printing Mono photo paper, if there is dirt on the photo, you can use the Smart Sheet to clean the printer. If one cleaning fails, please try several times more.
FCC Statement
The United States Federal
Communications Commission (in 47 CFR 15.105) has specified that the following
notice be brought to the attention of users of this product.This device
complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.This
equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:– Reorient or relocate
the receiving antenna.– Increase the separation between the equipment and
receiver.– Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.– Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.This equipment must be installed and operated in accordance with provided instructions and theantenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons.
Caution!
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipmen.
Regulatory compliance information
Hereby, Hannto Technology Co., Ltd.
declares that the radio equipment type ZPP110 is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at
the following internet address:
https://global.liene-life.com/pages/Service/declaration.html
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the installer or local authorities for more information about the location as well as terms and conditions of such collection points.
- The operation temperature range of the battery is 5 °C~40 °C.
- Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types);
- Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion;
- Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas;
- A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas.
Tip: The illustrations of products, accessories and user interface in this Manual are indicative and for reference only. The actual product may slightly differ due to product updates and upgrades.
Pearl K100 Portable Photo Printer
Product Name: Portable Photo Printer
Model: ZPP110
Rated Input: 5 V 1 A
Battery Capacity: 500 mAh
FCC ID: 2AZHDZPP110
CMIIT ID: 2022DP9145
Dimensions: 126×85×25 mm
Net Weight: ~183 g
Operation Temperature: 15°C~32°C
Wireless Connectivity: Bluetooth 5.0
Maximum Output Power: 4.5 dBm
Working Frequency: 2402-2480 MHz
Manufacturer: Hannto Technology Co., Ltd.
Address: Room 704, Building 1, No.88, Shengrong Road, Pudong, Shanghai,
China.
