1×8 HDMI Distribution Splitter
JTD-179 | JTD4KSP0108
JTD4KSP0108 Premium Quality Ultra HD
NOTICE
The information in this document is subject to change without notice. Every
effort has been made in the prepartion of this document to ensure accuracy of
the content, but all statements, information and recommendations in this
document do not constitute the warranty of any kind, expressed or implied.
FEATURES
- Simultaneously display UHD source signal on up to eight UHD displays
- Supports resolutions up to 3840 x 2160 @ 60Hz 4:2:0
- EDID Management – Mixed | Copy | Default 1080p | Default 4K60 4:2:0
- Supports 36 bit Deep Color
- Supports LPCM 7.1 | Dolby TrueHD | Dolby Digital | DTS-HD Master Audio
- HDCP 1.4 Compliant
- Supports 3D
*Note – J-Tech Digital reserves the right to make changes in the
hardware, packaging and any accompanying documentation without prior ritten
notice.
PACKAGE CONTENTS
- 1 x J-Tech Digital JTD4KSP0108 HDMI Splitter
- 1 x 5VDC 1A Power Adapter
- 1 x User Manual
SPECIFICATIONS
| Operating Temperature Range | 23°F to 95°F |
|---|---|
| Operating Humidity Range | 5 to 90% RH (No Condensation) |
| Bandwidth Frequency | 10.2 Gbps |
| Input Ports | 1 x HDMI Type-A 19-Pin Female |
| Output Ports | 8 x HDMI Type-A 19-Pin Female |
| Resolution Output | Up to 3840 x 2160 @ 60Hz YUV 4:2:0 |
| Dimensions (L x W x H) | 10.63 x 4.33 x 1.08 in |
| Power Consumption | 3W (max) |
| Transmission Distance | 45 FT (max) Standard 26AWG HDMI Cable |
| Net Weight | 840g |
PANEL DESCRIPTIONS
-
Power Input Indicator
-
EDID Management DIP Switches
11: Mixed EDID
00: Copy EDID
10: Default 1080p EDID
01: Default 4K EDID -
HDMI Output Indicator
-
On / Off Power Switch
-
Power Adapter Input Port
-
HDMI Output Ports
-
HDMI Input Port
EDID SETTINGS
11: Mixed EDID: Splitter will pass EDID of lowest resolution display connected
to the 8 outputs, in order to provide a source signal to all displays
00: Copy EDID: Splitter will send EDID of display connected to Output 8
(priority port) to source device. When no display is connected, splitter will
default to 1080p EDID
10: Default 1080p EDID: Splitter will provide 1080p EDID to source device
01: Default 4K EDID: Splitter will provide 4K60 4:2:0 EDID to source device
*Note – Please power cycle the splitter after making any EDID DIP switch
setting changes
CONNECTING & OPERATING
- Connect the HDMI source device to the HDMI input port of the JTD4KSP0108
- Connect the HDMI output ports to the desired HDMI displays
- Power on splitter, source and displays
Connecting Diagram
MAINTENANCE
PRODUCT SERVICE
- Damage Requiring Service: The unit should be serviced by qualified service personnel if:
a. The DC power supply cord or AC adaptor has been damaged;
b. Objects or liquids have gotten into the unit;
c. The unit has been exposed to rain;
d. The unit does not operate normally or exhibits a marked change in performance;
e. The unit has been dropped or the cabinet damaged.
*Servicing Personnel: Do not attempt to service the unit beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel. - Replacement Parts: When parts need replacing, ensure the servicer uses parts specified by the manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes may result in fire, electric shock, or other hazards.
- Safety Check: After repairs or service, ask the servicer to perform safety checks to confirm that the unit is in proper working condition.
WARRANTY
If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as “the warrantor”) will, for the length
of the period indicated as below, (Parts(1) Years , Labor(1) Years) which
starts with the date of original purchase (“Limited Warranty period”), at its
option either(a) repair your product with new or refurbished parts, or (b)
replace it with a new of a refurbished product. The decision to repair or
replace will be made by the warrantor.
During the “Labor” Limited Warranty period there will be no charge for labor.
During the “Parts” warranty period, there will be no charge for parts. You
must mail-in your product during the warranty period. This Limited Warranty is
extended only to the original purchaser and only covers product purchased as
new. A purchase receipt or other proof of original purchase date is required
for Limited Warranty service.
Mail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured
and preferably in the original carton. Include a letter detailing the
complaint and provide a day time phone and/or email address where you can be
reached.
LIMITED WARRANTY LIMITS AND EXCLUSIONS
- This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by warrantor, or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, mis-adjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification, or service by anyone other than a Factory Service center or other Authorized Servicer, or damage that is attributable to acts of God.
- THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRNTY. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to and from the service, loss of or damage to media or images, data or other recorded content. The items listed are not exclusive, but are for illustration only.
- PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY.
EXTENDED WARRANTY
With the registration of supported J-Tech Digital products, you extend the
current warranty by 6 months. This extension is added to the warranty that
starts at the purchase date of the device supported. Total product warranty
with the extended period will quate to a total of 18 months of warranty from
the date of purchase.
For extended warranties to be accepted, all warranty extensions must be
claimed within 30 days of purchasing the eligible J-Tech Digital product.
Extensions attempted to be claimed outside of the 30-day window will not be
accepted. Visit www.jtechdigital.com to
register your extended warranty.
J-TECH DIGITAL INC
12803 PARK ONE DRIVE
SUGAR LAND, TX 77478
TEL: 1-888-610-2818
E-MAIL:SUPPORT@JTECHDIGITAL.COM
WWW.JTECHDIGITAL.COM
PUBLISHED BY J-TECH DIGITAL. INC.
SUGAR LAND. TX 77478
