RM5754HD 5-inch Smart Wi-Fi 1080p Video Monitor
Go to www.vtechcanada.com
for the latest VTech product news.
RM5754HD
RM5754-2HD
5-inch Smart Wi-Fi 1080p
Video Monitor
Quick start guide Canada version
For more support information
Congratulations
on purchasing your new VTech product. Before using this HD video monitor,
please read Important safety instructions. For support, shopping, and
everything new at VTech, visit our website at
www.vtechcanada.com.
What does HD Video Monitor do?
VTech 5-inch Smart Wi-Fi 1080p Video Monitor allows you to stay close to your
baby when you are on the move or away.
This monitor is Wi-Fi enabled, which uses your home wireless network to stream
live video and audio through the HD baby unit and 5-inch color screen parent
unit. It allows you to maintain a constant connection to your baby.
You can also monitor from your smartphone and mobile tablet.
VTech 5-inch Smart Wi-Fi 1080p Video Monitor uses MyVTech Baby 1080p app to
let you instantly see and hear what’s happening with your baby from anywhere
in the world.
The app can be downloaded from the App Store or the Google Play TM Store,
directly from your smartphone or mobile tablet.
What’s in the box
Your HD video monitor package contains the following items. Save your sales
receipt and original packaging in the event warranty service is
necessary.
Requirements
For mobile access:
MyVTech Baby 1080p mobile app
Network
Wi-Fi router
Internet connection| Wi-Fi
2.4GHz 802.11 b/g/n
1.5 Mbps @ 720p or 2.5 Mbps @1080p upload
bandwidth per baby unit
---|---
Overview
Baby unit overview
-
Light sensor
-
Camera lens
-
Microphone
-
Infrared LEDs
• Allow you to see clearly in a dark surroundings.
-
Speaker
-
• Press to turn the night light on or off.
-
LED indicator
• Orange is steady on when the baby unit is connecting to the parent unit in direct mode.
• Green is steady on when the baby unit and parent unit are connecting to your home Wi-Fi network via the Wi-Fi router.
• Flashes orange slowly during video streaming in direct mode.
• Flashes green slowly during video streaming via home Wi-Fi network. -
ON
• Power on/off switch. -
PAIR
• Press and hold for three seconds to enter pairing mode.
• Reset the baby unit to factory default.
1. Press and hold the PAIR key until you hear a beep sound.
2. Release the PAIR key, and then press the PAIR key again five times until you hear another beep sound. 3. The baby unit will sound another beep when the reset completes. Then, the baby unit will reboot. -
Night light
-
11 Temperature sensor
-
Slots for wall mounting
• Wall mount bracket is included in your package. -
Power jack
-
LINK LED light
• On when the parent unit is linked to the baby unit.
• Flashes when the link to the baby unit is lost. -
LED light
• On when the parent unit is connected to AC power, and the battery is charging.
• Off when the parent unit is disconnected from AC power, or when the parent unit is connected to AC power and the battery is fully charged.
• Flashes when the parent unit battery is low and needs charging. -
3- level sound indicator light
• Green on when the low sound level is detected by the baby unit.
• Green and amber on when the moderate sound level is detected by the baby unit.
• Green, amber, and red on when a high sound level is detected by the baby unit. -
TALK /
• Press and hold to talk to the baby unit.
• While in a submenu, press to exit. -
• Press to zoom in/out.
- Arrow keys
• Press to navigate leftward, upward, rightward, or downward, within the main
menu and submenus.
• While viewing a zoomed image, press to move the zoomed image leftward,
upward, rightward or downward.
-
MENU/SELECT
• Press to enter the main menu.
• While in a menu, press to choose an item, or save a setting. -
– VOL/ VOL +
• Increase or decrease parent unit’s volume. -
Microphone
-
Speaker
-
POWER / LCD ON/OFF
-
Power jack
-
RESET
• Force reboot the parent unit. -
Antenna
-
Stand
**How the system works
Direct mode
** The parent unit and the baby unit of your video monitor are connected to
each other in Direct mode by default, which allows you to stream live video
right out of the box. Direct mode connection lets you stream live video from
the parent unit only.
- You may experience reduced signal strength if your parent unit and baby unit are far apart, or there are obstructing factors, such as internal walls, between them. Move the parent unit closer to the baby unit to improve the signal strength. You can also set up Router mode to connect via your home Wi-Fi network to improve the connection between your parent unit and baby unit.
Router mode
You can continue using your video monitor with a Direct mode connection, or
you can set up your monitor in outer mode connection.
Router mode uses your home Wi-Fi network to connect your video monitor. It
supports streaming live video through parent units and smartphone app.
We recommend that you set up your monitor in Router mode to enjoy streaming
live video via your parent nit with a better connection.
If you want to stream live video remotely with your mobile device, download
and install the MyVTech Baby 080p mobile app. With the mobile app, your Wi-Fi
router (not included) provides Internet connectivity to your D video monitor
system. It serves as a communicating channel between your baby unit and mobile
device, allowing you to monitor and/or control your baby unit wherever you
are. For detail, see the Download app or mobile access section in this quick
start guide.
• Your parent unit detects the connection signal strength. If you have
connected your video monitor with your home Wi-Fi network, your parent unit
automatically switches to direct or router mode – the one that has stronger
signal strength.
• When both the parent unit and app are viewing the camera simultaneously, the
video quality will be optimized to deliver the best possible viewing result.
Technical specifications
Channels
LCD
Nominal effective range
Power requirement| Baby unit: 2412_2462MHz
11
5’’ Color LCD
(IPS 1280×720 pixels)
Maximum power allowed by FCC and IC. Actual operating range may vary according
to environmental conditions at the time of use.
Parent unit/Baby unit power adapters:
VTech, VT05EUS05100
Rated output: 5V DC, 1000mA.
Parent unit battery: BP1763 (3.8V 2100mAh Lithium-ion battery)
ZhongShan Tianmao battery Co. Ltd.
---|---
Android
are trademarks of Google Inc.
App Store is a trademark of Apple Inc., registered in the U.S. and other
countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other
countries and is used under license.
Specifications are subject to change without notice. © 2021 VTech Technologies Canada Ltd. All rights reserved. 04/21. RM5754-XHD_CA_QSG_V
Protect your privacy and online security
VTech cares about your privacy and peace of mind. That’s why we’ve put
together a list of industry-recommended best practices o help keep your
wireless connection private and your devices protected when online. We
recommend you carefully review and consider complying with the following tips.
Ensure your wireless connection is secure.
-
Before installing a device, ensure your router’s wireless signal is encrypted by selecting the “WPA2-PSK with AES” setting in your router’s wireless security menu. Change default settings.
-
Change your wireless router’s default wireless network name (SSID) to something unique.
-
Change default passwords to unique, strong passwords. A strong password:
– Is at least 10 characters long.
– Is complex.
– Does not contain dictionary words or personal information.
– Contains a mix of uppercase letters, lowercase letters, special characters, and numbers. Keep your devices up to date. -
Download security patches from manufacturers as soon as they become available. This will ensure you always have the latest security updates.
-
If the feature is available, enable automatic updates for future releases. Disable Universal Plug and Play (UPnP) on your router.
-
PnP enabled on a router can limit the effectiveness of your firewall by allowing other network devices to open inbound ports without any intervention or approval from you. A virus or other malware program could use this function to compromise security for the entire network. For more information on wireless connections and protecting your data, please review the following resources from industry experts:
1. Federal Communications Commission: Wireless Connections and Bluetooth Security Tips
–
www.fcc.gov/consumers/guides/how-protect-yourself- online.
2. U.S. Department of Homeland Security: Before You Connect a New Computer to the
Internet –
www.us-cert.gov/ncas/tips/ST15-003.
3. Federal Trade Commission: Using IP Cameras Safely –
https://www.consumer.ftc.gov/articles/0382-using-ip-cameras-safely.
4. Wi-Fi Alliance: Discover Wi-Fi Security – http://www.wi-fi.org/discover- wi-fi/security. -
Connect the baby monitor
**** -
The rechargeable battery in the parent unit is built-in.
-
Use only the power adapters supplied with this product.
-
Make sure the parent unit and the baby unit are not connected to the switch-controlled electric outlets Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not designed to hold the weight of the parent unit and the baby unit, so do not connect them to any ceiling, under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the outlets.
-
Make sure the parent unit, the baby unit, and the power adapter cords are out of reach of children.
Slide the switch to ON to power on your baby unit.
- When powering up, the baby unit’s status LED turns on. It will turn off after a while and keeps off.
- The status LED is set to off by default. If you want to keep the LED on, press MENU, then go to
Status LED and turn it on.
NOTE:
The camera lens and surface may get warm during normal operation. WARM WARM
Charge the parent unit battery
before use
The parent unit runs on a rechargeable battery or AC power. To continuously
monitor your baby, keep the parent unit connected to AC power. With the
battery alone, the parent unit can cordlessly run for a short time only.
- Before using the baby monitor for the first time, charge the parent unit battery for 12 hours. When the parent unit battery is fully charged, the battery icon becomes solid
- The standby time varies depending on your actual use. After the parent unit is fully charged, press POWER until the welcoming screen appears.
Battery indicators| Battery status|
Action
---|---|---
The screen displays and. The light flashes.| The battery has very little charge and may be used for only a short time.| Charge without interruption (about 30 minutes).
The battery icon becomes solid
| The battery is fully charged.| To keep the battery charged, connect
it to AC power when not in use.
Raise the parent unit antenna for better reception
Parent unit icons
Main
Options
Menu
Monitoring mode ( For RM5754-2HD only)
Monitoring mode ( For RM5754-2HD only)
- View baby unit 1 or 2 in Single mode.
- View both baby units in Patrol mode.
- View both baby units on the Split screen.
Nigh light
• Select colors 1, 2, or 3.
• Turn off the night light.
Melodies and soothing sounds
- Select play all melodies, or play one of the five melodies and four soothing sounds.
- You can also set the timer to stop playing after 15, 30 or 60 minutes, or playing non-stop.
- View baby unit 1 or 2 in Single mode.
- View both baby units in Patrol mode.
- View both baby units on the Split screen. Nigh light
- Select color 1, 2 or 3.
- Turn off the night light.\
Melodies and soothing sounds
- Select play all melodies, or play one of the five melodies and four soothing sounds.
- You can also set the timer to stop playing after 15, 30 or 60 minutes, or playing non-stop.
Alerts – sound, motion, and temperature
- Select the sound and motion sensitivity level.
- Turn on/off sound and motion detection alerts.
- Select maximum and minimum temperature for alert range.
- Turn on/off temperature alert.
- Turn on/off Auto Wake Up function.
Parent unit settings
- Adjust parent unit screen brightness.
- Turn on/off dim mode.
Baby unit settings
- Turn on/off Night Vision.
- Turn on/off baby unit’s status LED.
- Adjust baby unit’s speaker volume.
- Update baby unit’s security key.
