Shenzhen Rehent Technology RH-FC1 Floodlight Security Camera User Guide
- June 5, 2024
- Shenzhen Rehent Technology
Table of Contents
**1080P Full-HD
Floodlight Security Camera**
Quick Start Guide
*Thanks for purchasing and using our product. Please read this quick start guide before using it, and keep it for future reference.
- Manual contents are subject to change without notice in accordance with our policy of continuous product improvement
Installation guide
- Please consult the below checklist for all the components
WHAT’S IN THE BOX
Please check the box for each of the following items before installing your cloud camera:
CAMERA STRUCTURE DIAGRAM
1 2 LEDS 1000LM
3 PM Motion Sensor
5 LED Indicator| 2 IMP Camera
4 Solar Panel Power Port
6 Microphone
---|---
7 12V 2A Port DC 55112.1MM
9 SD Card Slot| 8 On/Off Button
10 Reset Button
---|---
BATTERY CHARGING
- 1 The batteries inside the Battery camera are not fully charged in accordance with transportation safety regulations.
- Please make sure to install the battery solar-powered floodlight camera during the day under the sunshine for charging the first
- The built-in rechargeable battery and solar panel provide non-stop power once installed. It can also use a 12V 2A power adapter to charge about 8-10 hours prior to installation.
DOWNLOAD APP
-
Download and install the ‘CI oudEdge’ app from Google PlayTM or the App StoreTht 2.)TheApp is also available by scanning the OR code down below, using your QR code scanner on your smartphone. NOTE Google PlayTM is a trademark of Google Inc. App 5tortIM is a service mark of Apple Inc.
-
https://itunes.apple.com/app/id1294635090?mt=8| https://play.google.com/store/apps/detai
Wi-Fi SET UP
Before you start the Wr-FI configuration, please note below
- The Battery camera works with 2.4 GEN Wi-Fi, but not with 5 GHz Wi-Fi.
- Avoid using special characters or symbols like )(g–!*5%A54.., either In your Wi-11 name or password.
- Perform the configuration near your Vfi-Fi router.
3.1). Press the On/Off button (8), and the 11D5(1) will be on, wait until the LED indicator light(5) blinks and open the app to add the camera.
Note: if the indicator light(5) does not blink, Please hold the Reset button° 0) for 5 seconds until you see the indicator light(5) blink red light. Then Open APP follows these steps in the app to add It to the network.
BATTERY CHARGING
After setup, tap on the live view window in the app for a test. Then take your
cloud camera to the installation spot and run a test there. Make sure the
installation spot is covered by a strong 2.4 GHz WiFi signal.
Note: if the video quality from the cloud camera outside is not as good
as it was indoors, you may need to move your router closer to your
installation spot, or use a WIFI extender.
LIVE VIEW INTERFACE
| 1 Quit Live View | 2 Settings Menu | 3 Battery Status |
|---|---|---|
| 4 Volume On/Off | 5 HD/SD Switch | 6 Full-Screen Display |
| 7 Stream Bit Rate | 8 Wi-Fi Signal Status | 9 Make a Screenshot |
| 10 Speak to the Visitor | 11 Start Recording | 12 Human Detection On/Off |
| 13 Notification History | 14 Cloud |
|---|---|
| 15 Local Recording | 16 Make a Screenshot |
| 17 View Recording History | 18 View Alarm History |
Smart Playback and Multi-View Function
-
Time Line
Drag the timeline to the left or right to check the recorded video -The green bar means recorded video length; The red bard means alarm recorded length © -
Calendar
Check video history by dates, the gree number means motion detected -
Screenshot
Tap to capture a photo and save it to Me- >Pictures & Videos -
Record
Tap to record a local video and save it to Me- >Pictures & Videos -
Alarm
Check motion detection recorded video easily by the time -
Cloud
Note: Cloud history playback Is the same as SD Card. When subscribing to Cloud Storage service, SD Card functions stop
Cloud Storage Subscription Cost
| Alert Recording| 7/24 Days Recording
Storage Day| Monthly| Yearly| Monthly| Yearly
3 Days| $2.99| $30.00| 53.99| $40.00
7 Days| 54.99| 550.00| $6.99| $70.00
30 Days| $15.99| $160.00| $21.99| $220.00
MENU SETTINGS
| 1 hi» ireVeittehot | 2 Ellit*Ttlint | 3 Rdle/W*65mm |
|---|---|---|
| 3 together-2velbliritOn | 5 OnetiOdibrrecn | 6 Basichnk, |
| 7 AlimSetre | 8 SCald*”14f! | 9 tkuiStopSatfodto |
| 10 OnlInstfinittolmnat | 11 Ater/Ad | |
| Motion Detection Setting | Basic Function 1Status Light–Turn On/Off LED | |
| indicator 2. Rotate View–Turn the live view upside down | SD Card Setting | |
| --- | --- | --- |
FREQUENTLY ASKED QUESTIONS
Ql: I cannot set up the cloud camera to my WiFi network?
Al: Ct. Device works with 2.4GHz WiFi only, but does not support 5GHz
WiFi.eWiFi signal is not strong enough, try to keep the cloud camera near the
WiFi router when setting up. ®. The WiFi password is wrong. Please check if
there are special characters in the password, or if the network is specially
encrypted.
Q2: How do I know if I have 2.4G or 5G WiFi?
A2: Please check the user manual of your Router or call the network operator
for help.
Q3: Can I only view my cloud camera when I am on the same WiFi network, or
can I view it over the internet from anywhere?
A3: You can view the cloud camera from anywhere, as long as your cloud camera
is connected to the internet and you have an internet connection on your smart
device.
Q4: Do any of the recordings get saved to the cloud?
Or is it mainly saved in the built-in SD card? A4: It supports SD card
recording as well as cloud storage. You can activate the cloud storage service
in-app.
Q5: What happens when the SD card is full?
A5:When the memory card is full, the cloud camera automatically erases the
oldest footage.
Q6:Does it works with Google Home or Alexa?
A6: This model does not support Google Home or Alexa.
Q7: Why does it lose connection to WiFi?
A7: Please check the network connection of your smart device and the WiFi
router. If the network signal is not strong enough, you may need to move your
router closer to the device, or use an extender.
Q8:Can motion detection be disabled?
A8:Yes. The recording is triggered by detected motions. You can adjust the
sensitivity or disable motion detection in the setting menu.
Q9: Can I use 2 or more cloud camera’s in the same house?
A9: Yes. You can add more than one device to the same house.
Q10:How can I share this product?
A10: The person you shared must register an account. After that, there are two
ways to share the camera: Method 1: Scan the QR Cord; Method 2: Input the
person you shared the APP account.
Q11: What’s the capacity of the Battery?
Is the solar panel included?
It is built-in 4x 18650 batteries with 12000mAh capacity and a solar panel
included for charging. Once installed, do not worry about the battery out.
Q12:What’s the view angle of this camera?
Al 2:This camera wide-angle view is 120 degree
Q13:How long is my cloud camera covered under warranty?
A13:We provide a 12-month warranty on all our products after purchase (with
some exceptions).
Unfortunately, we cannot treat products that have become defective due to
incorrect use, fall damage, water damage, etc.
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
- this device may not cause harmful interference, and
- this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
a minimum distance of 20cm between the radiator and your body.
