Rebel RB-0100 Two-Way Radio User Manual
- June 5, 2024
- Rebel
Table of Contents
Rebel RB-0100 Two-Way Radio [
](https://manuals.plus/wp-content/uploads/2022/07/Rebel-
RB-0100-Two-Way-Radio-product.png)SAFETY INSTRUCTION
In order to reduce the injuries or damages, follow basic safety precautions applied when using any electrical device, including the following:
- Read the entire instruction manual before you start installation and assembly and keep it for future reference. Keep the manual for future reference.
- Protect this device from humidity, water and other liquid. Avoid using/storing it in extreme temperatures.
- Do not expose it to direct sunlight and other sources of heat. Avoid using/storing it in the strong magnetic environment.
- Never use this device if the power adapter or the device itself is damaged.
- Disconnect from the power outlet if the device is not going to be used for a long time.
- Use only authorized accessories.
- Prevent the device from falling on the ground or being strongly impacted.
- The producer does not claim liability for any data loss, damage caused by inappropriate use and handling or any mechanical damage.
- Do not attempt to repair this device yourself. In case of damage, contact an authorized service point for a check-up or repair.
- Clean this device with a soft, slightly damp cloth. Do not use any chemical agents to clean this device.
- If the radio is to be used while driving, hands-free systems should be used.
- This appliance must not be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they are supervised by the person who is responsible for their safety.
- Turn off the device in places where using it is forbidden or may cause danger. You must strictly observe any prohibitions on the use of this device in such places.
- If the device is damaged or does not work in proper way, contact the service center.
PRODUCT DESCRIPTION[](https://manuals.plus/wp-content/uploads/2022/07
/Rebel-RB-0100-Two-Way-Radio-fig-1.png)
- Channel switch
- LED light
- PTT button
- MONI button (Monitor)
- Torch button
- Volume/turn on the knob
- LED indicator
- Socket “K” type
OPERATION
Charging
- Before using for the first time, connect the charging station to a wall socket and insert the radio into it..
- During charging, the LED indicator will flash red.
- When the battery is fully charged, the indicator turns green..
Transmit / Receive
- Turn on the device with turn on knob.
- Chose channel with channel switch.
- To start transmitting, press and hold the PTT button (the LED indicator will be red).
- To receive a signal, turn on the unit and set the appropriate channel with the channel switch.
Additional functions
- Monitor – this function allows you to check activity on a chosen channel, regardless of the sub-channels. To enable this function, press and hold MONI button (You will hear a noise from the device speaker).
- VOX -In this mode, the radio automatically receives and transmits a signal without pressing the PTT button. Start talking and the device will automatically go into transmit mode. To turn on/off this function:
- turn off the device,
- switch the channel to one from the range 1-5,
- press the PTT and MONI buttons simultaneously and turn on the device.
- LED indicator will be red when the device detects a voice.
- Voice prompt – the function causes that when changing the channel, its number is read aloud. To turn on this function:
- turn off the device,
- switch the channel to 10,
- press the PTT and MONI buttons simultaneously and turn on the device.
- Changing the language of the voice prompts – to switch the language of the voice prompts between Chinese and English:
- turn off the device,
- Switch the channel to 15,
- press the PTT and MONI buttons simultaneously and turn on the device.
- Continuous scanning – the function enables continuous scanning of all 16 channels. After detecting activity on one of them, it stays on that channel as long as it is active. In case of inactivity, it goes on to further scanning. To turn on/off this function::
- turn off the device,
- switch the channel to 16,
- press the PTT and MONI buttons simultaneously and turn on the device. \
CLEANING AND MAINTENANCE
Clean this device with a soft, slightly damp cloth. Do not use any chemical agents to clean this device.
SPECIFICATION
Main functions
- Voice prompt
- 50 CTCSS / 105 DCS
- VOX mode
- LED flashlight
- PC programmable
- Battery save mode
Technical data
- Frequency: 420 – 450 MHz
- Channels: 16
- Rated voltage: 3,7 V
- Output power: <5 W
- Working temperature: -30°C ~ 60°C
- Power supply: battery Li-Ion 1500 mAh
- Antenna impedance: 50 Ohm
- Range: 2 – 4 km (depending on terrain conditions) Dimensions: 60 x 33 x 115 mm (without antenna)
- Weight: 180 g
- In set: antenna, charging station, belt clip, user’s manual
LEARN MORE
For more information on this device visit:
www.rebelelectro.com.
Read owner’s manual carefully before using your device.
Visit www.rebelelectro.com website for more
products and accessories.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment )
(Applicable in the European Union and other European countries with separate
collection systems) This marking shown on the product or its literature,
indicates that it should not be disposed with other household wastes at the
end of its working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from other types
of wastes and recycle it responsibly to promote the sustainable reuse of
material resources. Household users should contact either the retailer where
they purchased this product, or their local government office, for details of
where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product should not be mixed with
other commercial wastes for disposal.
Made in China for Lechpol Electronics Leszek Sp.k., ul. Garwolińska 1, 08-400
Miętne.
EU DECLARATION OF CONFORMITY
Producer: LECHPOL ELECTRONICS LESZEK
SPÓŁKA KOMANDYTOWA
08-400 Garwolin, Miętne ul.Garwolińska 1
Equipment: Radiotelefon ręczny
Brand: Rebel
Model: RB-0100
Producer declares that this declaration has been issued under its sole responsibility.
EAN 5901890065306
The product mentioned above in this declaration is in conformity with the
relevant requirements of the Union harmonization legislation:
Directive 2014/53/EU
Directive RoHS 2015/863
Applied standards:
- EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
- EN 50566:2017
- EN 62209-2:2010
- Draft ETSI EN 301 489-1 V2.2.0
- Draft ETSI EN 301 489-5 V2.2.0
- ETSI EN 300 086 V2.1.2
