PUSR USR-W660 Dual Band WiFi Device Server Owner’s Manual
- May 15, 2024
- PUSR
Table of Contents
www.pusr.com
Communication Expert of Industrial IOT
Dual Band WiFi Device Server
USR-W660
Introduction
USR-W660 is a Wi-Fi 6 industrial wireless device with high speed, wide
connection, low delay, and high stability. The measured rate of Wi-Fi 6 is up
to 800Mbps. In AP hotspot mode, it can carry more than 8 Wi-Fi users. It
integrates rich hardware interfaces: 1RS232, 1RS485, Ethernet ports
(1LAN+1WAN/LAN). It supports AP/STA/AP+STA/bridge mode and can provide stable
and reliable networking solutions for different scenarios and industries.
This device adopts industrial-grade standards: wide temperature and wide
voltage, EMC protection. In software, it supports MODBUS, MQTT, TCP, UDP and
other transmission protocols. The device supports single-link fast roaming. In
a wireless local area network composed of multiple APs, roaming can be
realized without AP switching operations. The built-in software and hardware
dual watchdog, fault self-recovery can ensure the device operate stably and
reliably in different harsh environments and industry scenarios like AGV
automated transportation, robot, smart medical, smart storage, smart factories
etc.
Product Features
Stable And Reliable
- Metal housing, IP30 protection
- Wide operating temperature: -35℃~+70℃
- EMC protection: Surge protection, level 3; ESD protection, level 3; EFT protection, level 3; IEC61000
- voltage input: DC 12V, with power reverse protection.
- Built-in hardware watchdog, fault self-detection, self-repair, firmware backup and restore functions to ensure system stability without crashing.
- Supports wall mounting, Din rail mounting, desktop placement.
Flexible Networking
- Support WIFI6 technology (IEEE 802.11 ax), support dual-band WIFI (2.4 and 5G) AP/STA/AP+STA/bridge mode.
- Support fast Wi-Fi roaming, network switching as low as 100ms.
- Support Gigabit ports: 1 x WAN/LAN, 1 x LAN.
- Support RS232/RS485, serial port data acquisition is easier.
- Compatible with mainstream industrial protocols: TCP/UDP/MODBUS/HTTP/MQTT/SNMP, etc.
- Supports connecting to mainstream cloud platforms such as Alibaba Cloud and AWS Cloud, making it easy for devices to go to the cloud.
Powerful features
- Support a complete anti-drop mechanism to ensure the stability of data transmission.
- Support wired/STA multi-network intelligent backup function, keep the link always unblocked.
- Support PUSR service, users can open the built-in webpage operation and maintenance of wireless client through PUSR platform, which facilitates centralized management of equipment
Support SNMP, NTP time calibration, MAC-IP binding, anti-access restriction and other special functions.
Dimensions
Unit: mm
With pleural spreading
SPECIFICATION
With pleural holding
Items | Description |
---|---|
Power Supply | DC: 12V, 2-pin terminal blocks, reverse polarity protection, |
surge protection
Working Current| Average: 600mA@12V, max: 1.35A @12V
---|---
Serial port
No.| 1 x RS485, 1 x RS232, can’t work simultaneously.
Baud rates| RS232: 1200 ~ 115200bps RS485: 1200 ~ 230400bps
Data bits| 7, 8
Stop bits| 1, 2
Parity| NONE, ODD, EVEN
Packaging Interval| Range: 1 ~ 3000ms, default: 50ms
Packaging Length| Range: 5 ~ 1500 bytes, default: 1000 bytes
Ethernet Ports
No.| 2 x Ethernet ports: 1 x WAN/LAN(configurable), 1 x LAN
Interface| RJ45, 10/100/1000 Mbps, compliance with IEEE 802.3, supports auto
MDI/MDIX, 1.5KV network isolation transformer protection
Wi-Fi
Standards & Frequency| IEEE 802.11b/g/n/ac/ax, 2.4GHz & 5.2G & 5.8G
Working Mode| AP/STA/AP+STA/Bridge
Data speed| 1201Mbps(5.2GHz& 5.8G) & 573.5Mbps(2.4GHz)
MU-MIMO| 2 x 2
OFDMA| DL-OFDMA 8(8 users); UL-OFDMA (4 users)
Covering distance| 200 meters by line of sight.Actual transmission distance
depends on environment of the site.
Wi-Fi Users| 8 +
Antenna| 2 x SMA-female
Wi-Fi Roaming| √
Physical Property
Casing material| Metal shell, IP30 protection
Dimensions| 1159429mm(L x W x H, antenna pedestal,terminal block and DIN
Rail are not included)
Installation| Wall mounting, Din rail mounting, desktop placement
EMC| Surge protection: level 3, IEC61000 ESD protection: level 3, IEC61000 EFT
protection: level 3, IEC61000
Operating temperature| -35℃~ +70℃
Storage temperature| -40℃~+125℃
Operating humidity| 5% ~ 95% RH, non-condensing
Storage humidity| 1% ~ 95% RH, non-condensing
Software Function
Network protocols| TCP, UDP, HTTP, TLS, MQTT, ARP, DHCP, ICMP, PPPoE, IPv4,
DNS, SNMP, NTP,
Modbus Gateway| Modbus RTU/TCP protocol conversion, Modbus multi-host polling
IP| DHCP/StaticIP
MQTT| standard MQTT protocol, 16 subscription topics and 16 publish topics
IOT PLATFORMS| AWS IOT, Alibaba cloud, PUSR cloud
User Configuring| Web console(HTTP)
Others
Reload| Pinhole reset button
Indicators| 1 x RS485, 1 x RS232, 1x WLAN, 1 x RUN, 1 x PWR
Ground protection| Screw
---|---
APPROVALS
Regulatory| CCC, CE/RED, RoHS, WEEE, FCC
Purchase & Support
- For more information, please visit our websites:
- Official website: https://pusr.com
- Official shop: https://shop.usriot.com
- Technical support: http://h.usriot.com/
FCC STATEMENT :
This device complies with Part15 of the FCC Rules. Operation is subject to the
followingtwo conditions:
- This device may not causeharmful interference, and
- This device must accept any interference received, including interference that maycause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible forcompliance could void the user’sauthority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class Bdigital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to providereasonable protectionagainst harmful
interference in a residential installation. Thisequipment generates uses and
can radiate radio frequency energyand, if not installedand used in accordance
with the instructions, may cause harmfulinterference to radiocommunications.
However, there isno guarantee that interference will not occur in aparticular
installation. If this equipment doescause harmful interference to radio
ortelevision reception, which can be determined by turning the equipment off
and on, theuser is encouraged to try to correct the interference by one ormore
of the followingmeasures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
thereceiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits setforth for
anuncontrolled environment.
This equipment should be installed and operatedwith minimum distance 20cm
between the radiator & your body.![PUSR USR-W660 Dual Band WiFi Device Server
- Fig](https://manuals.plus/wp-content/uploads/2024/03/PUSR-USR-W660-Dual-
Band-WiFi-Device-Server-Fig.jpg)Official Website:
www.pusr.com
Official Shop: shop.usriot.com
Technical Support: h.usriot.com
Inquiry Email: inquiry@usriot.com
Skype & WhatsApp: +86 13405313834
