Eyoyo EY-011 Bluetooth 2D Barcode Scanner with Stand User Manual

June 17, 2024
Eyoyo

Eyoyo EY-011 Bluetooth 2D Barcode Scanner with Stand

Product Information

Specifications

  • Model: EY-011 QA
  • Scan Types: 1D & 2D barcodes
  • Connectivity: Bluetooth, 2.4G wireless, USB wired
  • Charging Port: USB Type B
  • Supported Protocols: Bluetooth HID, SPP, BLE

Product Usage Instructions

Enabling Interleaved 2/5 Barcodes

  • To enable Interleaved 2/5 barcodes, scan the provided setup code.

Scanning Barcodes on Phone Screen

  • The scanner can read 1D & 2D barcodes on paper and screen.

Configuring UPC Codes

  • To configure UPC-E and UPC-A codes, scan the respective setup codes provided.

Bluetooth Connectivity

  • The scanner supports Bluetooth connectivity for iPhone and Android devices. Long press the scan button for 8-10 seconds to turn on Bluetooth mode.

Sound Settings

  • To turn off/on sound and adjust the sound level, scan the setup code provided.

Switching Modes

  • To switch from scan mode to keyboard mode, double-click the scan button for IOS devices.

Connecting Multiple Devices

  • You can only operate one device (computer or iPhone) at a time.

Charging

  • The scanner can be charged via a USB Type B port.

Turning Off the Scanner

  • To turn off the scanner, scan the setup code provided.

Frequently Asked Questions (FAQ)

FAQs:

Q: Will this scanner work with Square?

  • A: No, it is not compatible with Square.

Q: Can I use Bluetooth mode only without the receiver for an Android cellphone?

  • A: Yes, by pressing and holding the scan button for 8-10 seconds, you can turn on Bluetooth.

FAQ

Warm Tips:

If this document does not help you, please contact our after-sale email support@eyoyousa.com and we will be sure to help you as soon as possible.
Eyoyo promises to provide a one-year warranty and lifetime technical support.

I cannot scan the Interleaved 2/5 barcodes. Is there a way to enable them?

Answer: Please scan this setup code to enable it.
(If other barcodes need to be turned on or off, please contact us at support@eyoyousa.com)Eyoyo-EY-011
-Bluetooth-2D-Barcode-Scanner-with-Stand-FIG-1

Will this scan a barcode on a phone screen?

Answer Yes, it’s a 2D scanner and can scan the 1D & 2D code on the paper and screen.

3.Can it convert upce to upca?

Answer: Please scan the 2 setup codes below to enable it.

4.Is this compatible with square?

Answer: Not it can't work with square.

5.Can you set tabs so you can enter quantities?

Answer: Please scan this setup code to enable it.

6.Does it work with an iPhone?

Answer: Yes this barcode scanner has bluetooth 2.4G wireless, USB wired connection way. You can choose it according to your needs.

7.Can you configure the options for upc-e such as transmitting check digits ?

Answer: Please scan the setup code below.

8.Can you configure the options for upc-a such as transmitting check digits ?

Answer: Please scan the setup code below as you need.

9.May i connect it to ipad via bluetooth and a pc via your usb adapter. in other words have two devices connected at the same time?

Answer: No you can only operate your computer or iPhone individually.

10.How can i turn off sound?

Answer: Please scan the setup code below to turn on/off sound. You can also adjust the sound level.

11.Can you use Bluetooth mode only without the receiver for an android cellphone?

Answer: Yes please press and hold the scan button for 810 seconds to turn on Bluetooth.

12.Can you charge this via a usb port if so what type of usb port is it micro mini typeb rj45 or other?

Answer: Yes this product can charge via a USB port and it is type b.

13.How do you switch from scan mode to keyboard mode on this model?

Answer: If you want to pull up the IOS keyboard on your phone, you can double- click The scan button. Android devices do not support this function

14.Will Bluetooth connect to an android tablet on Bluetooth option without going through settings Want to setup 100s of tablets using scanner

Answer: Not supported. It can only be set by long pressing the scan button for 8-10 seconds or by scanning the code below.

15.Does this scan work with mobile directly without the adapter piece ? Is the adapter piece can be connected to Android or iPhone.

Answer: The adapter is used for computer connection if you want to connect to an Android iPhone or tablet, you can connect by Bluetooth.

16.Does this scanner work in SPP mode?

Answer: it supports Bluetooth HID SPP and BLE protocols.

17.When I connect the scanner to my phone or computer I scan the code but I dont see any change where is my barcode?

Answer: Please open an Excel sheet, word TXT document, or other program with a cursor and text input box on your phone or computer and place the cursor in the input box before scanning the code.

18.How to turn the scanner off?

Answer: Please scan this setup code.

21.Is it possible to connect without Bluetooth? I just want to connect the scanner to my computer using a 2.4G wireless receiver.

Answer: PC terminals like desktop computers, which is not equipped with Bluetooth please pair it with Dongle Dongle Pairing Steps A.Scan Dongle Setup Barcode B.Scan Compulsory Pair with Dongle Setup Barcode so that enter into the pairing state. Plug the receiver If pair successfully, you will hear a beep.

22.Is this product waterproof or IP-rated for outdoor use?

Answer: This product is not waterproof.Please protect it well when using it in humid environments.

answer-19=

answer-20=

Can it be programmed to remove the first and last character scanned?

  • Answer: Yes, it supports hiding the first and last character. Please scan this setup code.
  • If you need to hide other digits, please contact us via the email below support@eyoyousa.com .Eyoyo-EY-011-Bluetooth-2D-Barcode-Scanner-with-Stand-FIG-9

If your scanner is not working or not scanning anymore, but you don’t know what is causing it yet, please scan these setting codes below to restore the factory settings first.

The scanner will only work when it is plugged into the computer and will not for me via Bluetooth or wireless USB what do I do?

Can this scanner send multiple character prefixes/suffixes?

  • Answer: Yes, it can add multiple characters as prefixes/suffixes. Please contact our email support@eyoyousa.com
