STAR MICRONICS Recovery Document for Windows Update User Guide

June 13, 2024
Star Micronics

Recovery for problems occurring after Windows update
2023.7.10

About problems that cannot be printed [Windows10]

In case of Bluetooth printer

  1. Check the COM port number of using printer.
    How to check the COM port number of using printer .
  • In case of using Using printer driver
    1-1 Click “Control Panel”- “View devices and printers”
    STAR MICRONICS Recovery Document for Windows Update -

1-2 Select using printer, and then right-click , and click “Printer properties”.

STAR MICRONICS Recovery Document for Windows Update -
fig1

1-3 Click “Ports” tab then Check the COM port number of using Printer.

STAR MICRONICS Recovery Document for Windows Update -
fig2

  • In case of using OPOS
    If you are using futurePRNT, please check the procedure of * In case of using printer driver.

    1. -1 Run your Printer Utility and check the COM port number of the red frame below.
      STAR MICRONICS Recovery Document for Windows Update -
fig3

    2. After Windows10 Update, execute the pairing again because the pairing is released.
      For the pairing method, refer to “Pairing with Bluetooth in Windows”. In case of using
      TSP100IIIBI, refer to “TSP100IIIBI Online Manual”. Or, refer to the included “Software Manual”.

    3. Check the COM port number created by re-pairing and the COM port number confirmed in step 1.
      If the confirmed COM port number is different, please proceed to and after step 4.
      If the confirmed COM port number is the same, proceed to and after step 5.
      For the confirmation method of the COM port number created by the pairing, refer to step 5 procedure in “Pairing with Bluetooth in Windows”.

    4. Start Device Manager and change the COM port number created by re-pairing to the COM port number confirmed in step 1.
      How to change the COM port number :
      4-1 Select the COM port number confirmed in step 3 in the list of “Port (COM and LPT)” of the device manager and open the property screen by right clicking.
      Device Manager: Click “Settings”- “Devices” – “Printers & scanners” – “Devices manager”
      4-2 Open the “Port settings” tab on the property screen and click “Advanced…”.
      STAR MICRONICS Recovery Document for Windows Update -
fig54-3 Change the COM port number to the COM port number confirmed in step 1 and click “OK”.
      STAR MICRONICS Recovery Document for Windows Update -
fig6
      When clicking “OK”, the message dialog is displayed, please click “Yes”.
      STAR MICRONICS Recovery Document for Windows Update -
fig7

    5.  Perform the test printing.
      If the test printing fails, please proceed to and after step 6.

    6. Check the outgoing COM port of the Bluetooth device.
      6-1 Click “Settings”- “Devices” – “Bluetooth” – “More Bluetooth options”
      STAR MICRONICS Recovery Document for Windows Update -
Bluetooth
      6-2 If the outgoing COM port and the incoming COM port are the same, perform step 7, otherwise perform step 8.
      STAR MICRONICS Recovery Document for Windows Update - COM
port

    7. Release Bluetooth pairing manually, then re-pairing again.
      7-1 Return to “Bluetooth” screen.
      Click “close” or “cancel” button to close “Bluetooth setting” screen.
      7-2 Release Bluetooth pairing manually.
      Select using printer in “Bluetooth & other devices” screen.
      STAR MICRONICS Recovery Document for Windows Update -
screen
      Click “Remove device” then select “Yes”.
      STAR MICRONICS Recovery Document for Windows Update - Remove
device
      7-3 Re-pairing.
      For the pairing method, refer to “Pairing with Bluetooth in Windows”. In case of using TSP100IIIBI, refer to “TSP100IIIBI Online Manual”. Or, refer to the included “Software Manual”.
      7-4 Finish.

    8. Delete the outgoing COM port of the Bluetooth device and add the outgoing COM port again.
      8-1 Delete the outgoing COM port of the paired device.
      Make a note of the outgoing COM port you want to delete.
      8-2 After deleting, click “Add” button.
      STAR MICRONICS Recovery Document for Windows Update - After
deleting 8-3 When the “Add COM port” dialog is displayed, select “Outgoing”, select the paired device from the list of “Device that will use the COM port:”, and click “OK”.
      STAR MICRONICS Recovery Document for Windows Update - Add COM
port
      When clicking “OK”, the message dialog is displayed, please click “Yes”.
      STAR MICRONICS Recovery Document for Windows Update -
message8-4 Confirm that outgoing COM port is added to “Bluetooth Settings”.
      STAR MICRONICS Recovery Document for Windows Update - Bluetooth
Settings8-5 If the added outgoing COM port is different from the deleted outgoing COM port, perform step 4 and change the outgoing COM port number.
      8-6 Finish.

In case of USB Printer

After Windows10 Update, the USB printer may not be available.
In this case, reboot PC with connecting printer.
After reboot PC, cannot use USB printer, refer to following method, make USB printer queue.

  1. Check the COM port number of using printer.

  2. Select using printer, and then right-click, and click “Remove device”.
    STAR MICRONICS Recovery Document for Windows Update -
printer

  3. When you turn the printer on again, the Plug and Play feature automatically starts the installation of the printer driver and creates the printer queue.

  4. Perform the test printing.

  5. Finish.

In case of OPOS
After Windows10 Update, the registration of “Control object” of the device registered with utility may be unregistered, then registered devices may not be used.
To confirm the control object registration status, proceed as follows.

  1. Run your Printer Utility and click the OPOS of the red frame below.
    STAR MICRONICS Recovery Document for Windows Update - Printer
Utility

  2.  To confirm the control object registration status.

  • In case of using Star Printer Software
    If the checkbox of “Control object” of registered device is unchecked, check the checkbox again.
    STAR MICRONICS Recovery Document for Windows Update - Printer
Software

  • In case of using futurePRNT
    If “Control Object Registration” is “Not Selected”, please register the control object again.
    STAR MICRONICS Recovery Document for Windows Update -
Control

    1. Please execute the following “test”or “Check Health” button and confirm that the registered device can be used.
      STAR MICRONICS Recovery Document for Windows Update -
test

    2. Finish.

About communication problems with serial interface printers [Windows10] (garbage printing etc .)

After Windows10 Update, the return of the serial port setting value to the initial value of the OS has been confirmed. As a result, communication with the printer may not work properly, and garbage printing or printing failure may occur.
If such a problem occurs, change the communication port setting according to the following steps.

How to change the serial port settings

  1. Run your Printer Utility.

  2. Switch the “Current Connection” to the printer that is having the problem.

  3. Click “Windows Printer Queue Management”.
    STAR MICRONICS Recovery Document for Windows Update - Current
Connection

  4. When the following screen is displayed, click the [Configure Settings] button.
    STAR MICRONICS Recovery Document for Windows Update - Configure
Settings

  5. When the following screen (Windows Printer Queue Management screen) is displayed, the setting is complete.
    STAR MICRONICS Recovery Document for Windows Update - Configure
Settings1

About problems when uninstall driver [Windows10]

In case of Printer Utility
It may not be possible to acquire the status for any printer queue that was created with a Printer Utility tool which is not the driver subject to deletion.
This problem occurs when the file “smjlmhost3.dll” in folder C:\Windows\System32 (used by software that is not subject to deletion) was deleted by uninstall.
If there is the above problem, please confirm if “smjlmhost3.dll” exist in “C:\Windows\ System32” folder. When you cannot find “smjlmhost3.dll”, follow the procedure below to recover from the problem.

  1. Copy “smjlmhost3 .dll” to C:\Windows\System32 folder.
    When Star Windows Software is installed64bitOS| C:\Program Files (x86)\StarMicronics\PrinterSoftwareformPOP\Star MCP20\amd64\smjlmhost3.dll
    ---|---
    32bitOS| C:\Program Files\StarMicronics\PrinterSoftwareformPOP\Star MCP20\i386\smjlmhost3.dll

When StarPRNT intelligence is installed

64bitOS| C:\Program Files (x86)\StarMicronics\PrinterSoftware\Star TSP650II\amd64\smjlmhost3.dll
---|---
32bitOS| C:\Program Files\StarMicronics\PrinterSoftware\Star TSP650II\i386\smjlmhost3.dll

When StarPRNT for Portable is installed


64bitOS| C:\Program Files (x86)\StarMicronics\PortablePrinterSoftware\Star SM- T300i\amd64\smjlmhost3.dll
---|---
32bitOS| C:\Program Files\StarMicronics\PortablePrinterSoftware\Star SM- T300i\i386\smjlmhost3.dll

  • If you are using both Printer Utility StarPRNT and Mobile Printer Utility, please copy from either one.

    1. Power OFF and ON computer.
      If the status can be acquired by operations 1 to 2, this is the end of the process.
      If the above operation does not resolve the problem, reinstall the Star Window software,
      StarPRNT Intelligence, or StarPRNT for Portable that you are using.

In case of futurePRNT
After uninstalling futurePRNT, the following data may not be deleted.
– Printer Queue for futurePRNT.
– Driver on print server property.
– Both folder and data generated when creating Queue.
In case that data still exist in the PC, please delete those files using procedures below.

  1. Delete printer queue generated by futurePRNT, manually.
    1-1 Open [Start menu] – [Windows System] – [Control Panel], and open “Devices and Printers”
    ![STAR MICRONICS Recovery Document for Windows Update - Start menu]](https://manuals.plus/wp-content/uploads/2023/08/STAR-MICRONICS- Recovery-Document-for-Windows-Update-Start-menu.png)1-2 Select printer queue generated by futurePRNT, then right click and select “Remove device”.
    When the following dialog appears, then click “Yes”.
    STAR MICRONICS Recovery Document for Windows Update - Start
menu1
    1-3 Delete all printer queues generated by futurePRNT.

  2. Delete printer driver manually.
    2-1 Open [Settings] – [Devices] – [Printers & scanners], and open “Print server properties”
    STAR MICRONICS Recovery Document for Windows Update - Start
menu2
    2-2 Select “Drivers” tab, and click [Change Driver Settings].
    2-3 Select one of TSP100 series driver, and click [Remove…].
    STAR MICRONICS Recovery Document for Windows Update - Start
menu3
    2-3 Select “Remove driver and driver package.” and click [OK].
    Then confirmation screen appears, then click [Yes].

2-4 Click [Delete].
STAR MICRONICS Recovery Document for Windows Update - Start
menu5
2-5 Confirm the remove driver package, then click [OK].
STAR MICRONICS Recovery Document for Windows Update - Start
menu6

  1. Delete folders when generate queue.
    3-1 Open “C:\Program Files\StarMicronics” folder, and delete “TSP100” folder completely.
    STAR MICRONICS Recovery Document for Windows Update - Start
menu7
    Complete steps 1 to 3.

About problems when USB printer is not recognized [Windows11]

When connecting and using two or more units of the same model printer When two or more units of the same model printer with USB serial number disabled are connected to a Windows11 PC, the second and later units cannot be recognized correctly.
When a printer where the USB serial number has been set to disabled is not recognized, follow the procedure below to enable the USB serial number before using.

  • When using Star Windows Software
    Use the USB Serial Number Setting Utility.
    STAR MICRONICS Recovery Document for Windows Update - Start
menu8

  • When using futurePRNT
    USB the Serial Number Setting Tool.
    STAR MICRONICS Recovery Document for Windows Update - Start
menu8

  • When using StarPRNT Intelligence
    Please contact the seller.

  • When using StarPRNT for Porable
    Please contact the seller.

  • For the owners of other companies’ trademarks mentioned in this document,see Trademarks in our website (https://www.star-m.jp/eng/trademarks.html).
    ©2023 Star Micronics Co., Ltd.
