amber M100 Instant Photo Printer User Manual

User Manual for Amber M100 Instant Photo Printer

Product Overview

Accessory List

Install Ink Cartridge

Open the side door
Insert new ink cartridge until the lock is in place
Close the side door

Refill Photo Paper

Open the paper cassette cover along the top seam

Load photo paper in the cassette with the glossy side face-up
Note:

1. The maximum of the cassette is 20 sheets of photo paper.
2. Do not touch the area within the crop marks of a photo paper.
3. Undrawing the paper cassette holder makes refilling easy.

Close the paper cassette cover
Install Paper Cassette
Undraw the paper cassette holder

Rotate the holder down 180° to the bottom

Insert the paper cassette into the printer

Replace Ink Cartridge
Open the side door

Lift the lock upward to pop out the used ink cartridge and take it out

Insert new ink cartridge until the lock is in place, then close the side door

Usage
Working Location
When printing, the photo paper goes back and forth. Please make sure to leave more than 4inchs (10cm) space behind the printer. Note: Paper goes in and out four 4 times.

Storage
When the printer is not in use, place the paper cassette on top of the printer for space-saving and easy storage.

Instruction for Buttons

password
6 times| Quickly press Power Button6 times| Restore factory settings

Note:

1. All indicators light on and blink for 2 seconds simultaneously if the factory settings are restored successfully.
2. Wi-Fi hotspot indicator blinks for 2 seconds if the printer Wi-Fi hotspot password is reset successfully. Reset the printer Wi-Fi hotspot password only when printer is idle or there is a printer failure. The default password is 12345678.
3. During printing, printing will not be interrupted when the power button is pressed.
4. During firmware upgrading, upgrading will not be interrupted when the power button is pressed.
5. When there is a failure, press the power button to power the printer off.

Then, power the printer on again. The printer will try to fix the problem automatically after powering on.

Power Indicator

| Light off| Power off
---|---|---
| Light on| Power on
| White light blink| Printing/Firmware upgrading
| Breath| In sleep mode

Note: Sleep mode starts after the printer is idle for 5 minutes. Press Power Button or send a print job to wake the printer up.

Failure Indicator

| Light off| Printer OK
---|---|---
| Orange light blink| The printer has failed. Follow the APP prompts to solve the problem

Wi-Fi Hotspot Indicator

| Light off| Function off
---|---|---
| Orange light on| Function on
| Blue light on| Connected to one or more devices
| Orange light blink| Function turning on

Power On and Connect
Connect Power Supply
Plug the power jack into the power socket at the back of the printer.

Power On

• Press the power button to power the printer on.
• Power indicator lights on in white, Wi-Fi hotspot indicator starts blinking in orange in about 10s, then lights on in orange.
• The printer enters the idle status.

Connect Device Wi-Fi

• Open the WLAN connection on your smartphone, tablet, computer, etc. and select “Liene Photo Printer [xxxx]”.
• The default connection password is 12345678.
• When the Wi-Fi hotspot indicator lights on in blue, it means successful connection for at least 1 device.

Note:

• You can change the password in the APP.
• Support to connect to a maximum of 5 devices simultaneously.
• [xxxx] refers to the last four digits of the product SN number, which can be found on the label at the bottom of the printer.
• For an Android device, after switching the Wi-Fi signal to the printer Wi-Fi hotspot signal, it will pop up a message that the internet may not be available.
• Please keep the WLAN connection when using the printer.
• Please download and install the computer driver before connecting to a computer.

How to print

Print from Android Device
Print from iOS Device
Print via USB from a computer
Print via Wi-Fi from a computer

Print with “Liene Photo” APP
Search for “Liene Photo” in the App Store or scan the QR code below to download and install the “Liene Photo” App. Open the “Liene Photo” App and follow the APP prompts to add a device. You can find the device in the list on the home page after it is successfully added.
Note: The actual operation may not match the description here due to “Liene Photo” APP upgrades and updates. Please follow the instructions within the current “Line
Photo” APP to operate.

http://support.liene-life.com/download/app/liene/
Make sure that the device is connected to the printer Wi-Fi hotspot, and the Wi-Fi hotspot indicator lights on in blue.
Follow the operation prompts in the APP to print.
Print from Android Device
Make sure that the device is connected to the printer Wi-Fi hotspot, and the Wi-Fi hotspot indicator lights on in blue. Confirm that you agree to use this network. Open the album and select the photos, then select the printer, adjust the printing parameters, and print. If the printer is not found, please turn on “Default Print Service”. If the printing interface is not found in the phone album, go to https://mopria.org/print-from-android to download the APP and see how to use it.
Print from iOS Device
Make sure that the device is connected to the printer Wi-Fi hotspot, and the Wi-Fi hotspot indicator lights on in blue. Confirm that you agree to use this network.
Open the album and select the photos, then select the printer, adjust the printing parameters, and print. Note: USB printing is supported for Mac computers. Print via USB from a computer
Go to www.liene-life.com/download to download the driver for Photo Printer Series and install it.
Connect the printer to the computer using a USB cable. Select the photos, click “Print”, and select “Liene Photo Printer”.

Print via Wi-Fi from a computer
Go to www.liene-life.com/download to download the driver for Liene Photo Printer Series and install it.
After the computer has successfully connected to the printer Wi-Fi hotspot, follow the steps in the table below to set the printer connection.
After successful connection, select the photos, click “Print”, and select “Liene Photo Printer[xxxx]-Wi-Fi”.

Windows 8/8.1| Click “Control Panel” > “Hardware and Sound” > “Devices and Printers” > “Add a Printer”, and select “Liene Photo Printer [xxxx]-WiFi”
---|---
Windows 10| Click “Settings” > “Devices” > “Printers and Scanners” > “Add a Printer or Scanner”, and select “Liene Photo Printer [xxxx]-WiFi”

Note: [xxxx] refers to the last four digits of the product SN number, which can be found on the label at the bottom of the printer.

Troubleshooting

The Line app will alert you to various error conditions through in-app messaging. Follow the app instructions to resolve issues. For additional help on specific issues with your Liene photo printer, see the FAQs on www.liene- life.com

Warranty & Support

Thank you for choosing Liene! We really hope you will enjoy the product! Your satisfaction means everything to us! Liene provides a 1-year warranty for this product, please contact us immediately if you encounter any of the following, and we will supply a replacement or refund.

1. Receiving defective items;
2. Short packaging;
3. Parts are broken in transit;
4. Item stops working within warranty;
5. Wrong order.

To provide more prompt and professional after-sale service, you may contact us via below ways E-mail: liene.service@hannto.com

Caution & Notice

• Use only the official power adapter for use with the product.
• Do not use the original adapter for other devices to avoid damage.
• Do not plugin or unplug the product with wet hands.
• Do not damage, break, or modify the power cord.
• Do not use after immersion in water.
• Do not touch the glossy side of a photo paper to avoid leaving fingerprints and affecting printing quality.
• Do not handle paper with wet hands and keep paper free of dust.
• Do not Write on paper before printing.
• Do not use unofficial ribbon and photo paper.
• Never reuse paper for printing, even if most of the paper is blank. Reusing paper may damage the printer if paper jams or the ink sheet adheres to the paper.
• Do not load paper upside-down, make sure the glossy side of a photo paper is facing up. the photo paper is laid flat in the paper cassette, and the paper cassette is properly installed on the front of the printer.
• Do not block the rear of the printer.
• Do not get the product wet. Do not insert foreign objects or liquids into the product.
• The optimal working temperature for the printer is 10°C~35°C (50°F~95°F), and the relative humidity is 40%-60%. Printing quality may be affected if the environmental temperature and humidity are not appropriate.
• During printing, a photo paper needs to go through the printer four times and will be pushed out automatically when the printing is finished. Do not pull out the photo paper forcibly to avoid damage to the printer.
• Do not touch any parts inside the product, it may cause injury.
• It is normal to have slightly different printing colors between different printers.
• When the printer is not in use for a long time, remove the paper cassette and close the paper cassette cover to prevent dust and debris from entering the paper path. Otherwise, the printing quality of the first photo the next time you print will be affected.
• When keeping the unused photo paper in the printer, avoid storing it in a hot and humid environment.
• Under normal use of conditions, this equipment should be kept at a separation distance of at least 20 cm between the antenna and the body of the user.

FCC Statement

The United States Federal Communications Commission (in 47 CFR 15.105) has specified that the following notice be brought to the attention of users of this product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help
FCC Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment must be installed and operated in accordance with provided instructions and antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons.
Caution!
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Regulatory Compliance Information
Hereby, Hanno Technology Co., Ltd. declares that the radio equipment type DHP512 & DHP513 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.liene-life.com/Service/declaration.html
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the installer or local authorities for more information about the location as well as the terms and conditions of such collection points.
Note: The illustrations of products, accessories, and user interface in this Manual are indicative and for reference only. The actual product may slightly differ due to product updates and upgrades.
Amber M100 Instant Photo Printer

Product Name:
Product Model:
Rated Input:
FCC ID:
Product Size:
Product Net Weight:
Operation Temperature:
Wireless Connectivity:
Maximum Output Power:
Working Frequency:| Amber M100 Instant Photo Printer
DHP513
24V 1.6A
2AZHDDHP513
205×124.6 ×85.4mm
~1.3kg
10°C~35°C
IEEE 802.11 b/g/n 2.4GHz
18 dBm
2400 – 2483.5 MHz
---|---

Manufacturer: Hanno Technology Co., Ltd.
Address: Room 704, Building 1, No.88, Shengrong Road, Pudong, Shanghai,
China For further information, please go to www.liene-life.com
