APM Technical specification
APM6 APM Intelligent Frequency Conversion Circulating Pump
SHIMGE PUMP (
JIANGSU) CO., LTD
USE
For domestic hot water system such as mix water underfloor heating system, air
energy hot water circulation system, solar hot water circulation system and
family hot, cold water pressurization circulation, etc.
PERFORMANCE RANGE
APM6
- Flow rate up to 3 m³/h
- Head up to 6m
APM8
- Flow rate up to 8 m³/h
- Head up to 8m
APM10
- Flow rate up to 9 m³/h
- Head up to 10m
APM12
- Flow rate up to 10 m³/h
- Head up to 12m
APPLICATION LIMITS
- Liquid temperature: 2℃～110℃
- Maximum ambient temperature +40℃
- Maximum system pressure 10bar
- Protection level: IP42
- Mains connection: 220V～240V; 50Hz
- Insulation class: F
- Pumped liquid characteristics: clean, free from solids and mineral oils, non-toxic, chemically neutral, close to the characteristics of water
- Installation: the motor shaft must be kept in horizontal direction
FEATURES AND BENEFITS
- “A” Rated energy efficiency-lowest power consumption
- Permanent magnet motor-intelligent frequency conversion control
- Compact design, with control box integrated into the pump head
- Proportional pressure mode
- Constant pressure mode
- Constant speed mode
- AUTOADAPT mode
- Night-setback mode
- Actual power display
- Low noise, no leakage
EXPLODED DRAWING（4 &6m）
MATERIAL SPECIFICATION（4 &6m）
| Pos. | Component | Material |
|---|---|---|
| 1 | Pump body | Cast iron |
| 2 | Impeller | PES+GF |
| Shaft | Ceramic | |
| Pump cover | SS 304 | |
| Thrust bearing | Graphite | |
| Radial bearing | Ceramic | |
| Radial bearing sleeve | EPDM | |
| Magnet ring | Ferrite | |
| Magnet ring sleeve | SS 304 | |
| Magnet ring package | PA66+30%GF | |
| 3 | Sealing ring I | EPDM |
| 4 | Rotor can | SS 304 |
| Thrust bearing | Graphite | |
| 5 | Sealing ring II | EPDM |
| 6 | Air cock | Brass |
| O-ring | EPDM | |
| 7 | Stator | / |
| 8 | Stator housing | Aluminium |
| 9 | Hex socket screws | Steel |
| 10 | Fast plug | / |
| 11 | Control box gasket | EPDM |
| 12 | Control box seat | PC+10%GF |
| 13 | Drive PCB | / |
| 14 | Control box cover | PC+10%GF |
| 15 | Screws | Stainless steel |
| 16 | Rubber stopper | EPDM |
| 17 | Operation panel | PVC+PET |
EXPLODED DRAWING（8 &10m）
| Pos. | Component | Material |
|---|---|---|
| 1 | Pump body | Cast iron |
| 2 | Impeller | PES+GF |
| Shaft | Ceramic | |
| Pump cover | SS 304 | |
| Thrust bearing | Graphite | |
| Radial bearing | Ceramic | |
| Radial bearing sleeve | EPDM | |
| Magnet ring | Ferrite | |
| Magnet ring sleeve | SS 304 | |
| Magnet ring package | PA66+30%GF | |
| 3 | Sealing ring I | EPDM |
| 4 | Rotor can | SS 304 |
| Thrust bearing | Graphite | |
| 5 | Sealing ring II | EPDM |
| 6 | O-ring | EPDM |
| 7 | Air cock | Brass |
| 8 | Stator | / |
| 9 | Hex socket screws | Steel |
| 10 | Stator housing | Aluminium |
| 11 | Screws | Steel |
| 12 | Control box gasket | EPDM |
| 13 | Control box seat | PC+10%GF |
| 14 | Warranty sticker | Silver paper |
| 15 | Cable | / |
| 16 | Screws | Stainless steel |
| 17 | Screws | Steel |
| 18 | Drive PCB | / |
| 19 | Display PCB | / |
| 20 | Radiator | Aluminium |
| 21 | Control box cover | PC+10%GF |
| 22 | Operation panel | PVC+PET |
EXPLODED DRAWING（12m）
| Pos. | Component | Material |
|---|---|---|
| 1 | Pump body | Cast iron |
| 2 | Impeller | PES+GF |
| Shaft | Ceramic | |
| Pump cover | SS 304 | |
| Thrust bearing | Graphite | |
| Radial bearing | Ceramic | |
| Radial bearing sleeve | EPDM | |
| Magnet ring | Ferrite | |
| Magnet ring sleeve | SS 304 | |
| Magnet ring package | PA66+30%GF | |
| 3 | Sealing ring I | EPDM |
| 4 | Rotor can | SS 304 |
| Thrust bearing | Graphite | |
| 5 | Sealing ring II | EPDM |
| 6 | O-ring | EPDM |
| 7 | Air cock | Brass |
| 8 | Stator | / |
| 9 | Stator housing | Aluminium |
| 10 | Hex socket screws | Steel |
| 11 | Control box gasket | EPDM |
| 12 | Control box seat | PC+10%GF |
| 13 | Cable | / |
| 14 | Baffle | PC |
| 15 | Screws | Stainless steel |
| 16 | Screws | Stainless steel |
| 17 | Drive PCB | / |
| 18 | Display PCB | / |
| 19 | Warranty sticker | / |
| 20 | Radiator | Aluminium |
| 21 | Control box cover | PC |
| 22 | Operation panel | PVC+PET |
PERFORMANCE CURVE
ELECTRICAL AND HYDRAULIC DATA
Model| Pipe Distance
(mm)| Electrical Data| Max.head
(m)| Max. flow
(m3/h)
---|---|---|---|---
Voltage| P1
(W)| In
(A)
APM20-4-130| 130| 220V-50Hz| 22| 0.18| 4| 2.5
APM20-6-130| 38| 0.30| 6| 3.0
APM25-4-130| 130| 22| 0.18| 4| 2.5
APM25-6-130| 38| 0.30| 6| 3.0
APM25-4-180| 180| 22| 0.18| 4| 2.5
APM25-6-180| 38| 0.30| 6| 3.0
APM32-4-180| 180| 22| 0.18| 4| 2.5
APM32-6-180| 38| 0.30| 6| 3.0
APM25-8-180| 180| 80| 0.72| 8| 8
APM32-8-180| 80| 0.72| 8| 8
APM25-10-180| 180| 120| 1.08| 10| 9
APM32-10-180| 120| 1.08| 10| 9
APM25-12-180| 180| 180| 1.53| 12| 10
APM32-12-180| 180| 1.53| 12| 10
DIMENSIONS
Model| L| L1| B| H| H1| H2| G|
Unions
---|---|---|---|---|---|---|---|---
APM20-4-130| 133| 113| 95| 130| 128| 78| G1″| G1″ to G¾”
APM20-6-130
APM25-4-130| 138| 113| 95| 130| G1½”| G1½” to G1″
APM25-6-130
APM25-4-180| 138| 113| 95| 180| 61½”| G1½” to G1″
APM25-6-180
APM32-4-180| 143| 113| 95| 180| G2″| G2″to G1½”
APM32-6-180
APM25-8-180| 180| | 95| 182| 131| | G1½”| G1½” to G1″
APM25-10-180
APM25-12-180| G1½”| G1½” to G1″
APM32-8-180| 180| | 95| 182| 131| | G2″| G2″to G1½ “
APM32-10-180
APM32-12-180| G2″| G2″to G1½”
