Yale

Conexis L1

SKU: SD-L1000-CH

Quickstart

This is a
secure
Door Lock – Keypad
for
CEPT (Europe).

Please make sure the internal battery is fully charged.

To add this device to your network execute the following action:
Put the Z-Wave controller into add or learn modePress the R button on the lock 3 times quickly (within 1.5 seconds)Refer to the operation manual of the Z-Wave controller to complete the learn in processFor more information on this please visit:www.yale.co.uk/smart-living

Please refer to the
Manufacturers Manual for more information.

Important safety information

Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law.
The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material.
Use this equipment only for its intended purpose. Follow the disposal instructions.

Do not dispose of electronic equipment or batteries in a fire or near open heat sources.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This
device is suited for use in the region mentioned in the Quickstart section.

Z-Wave ensures a reliable communication by reconfirming every message ( two- way
communication) and every mains powered node can act as a repeater for other nodes
( meshed network ) in case the receiver is not in direct wireless range of the
transmitter.

This device and every other certified Z-Wave device can be used together with any other
certified Z-Wave device regardless of brand and origin as long as both are suited for the
same frequency range.

If a device supports secure communication it will communicate with other devices
secure as long as this device provides the same or a higher level of security.
Otherwise it will automatically turn into a lower level of security to maintain
backward compatibility.

For more information about Z-Wave technology, devices, white papers etc. please refer
to www.z-wave.info.

Product Description

Features:Control Via Smartphone – Configure, Control and unlock your Smart Door Lock from your smartphone via our secure Bluetooth App.Keyless – Say goodbye to keys, Open your Smart Door lock via your smartphone, Key Card or Key Tag.Simple to Fit – Engineered for easy installation.Connectivity – Compatible with the Yale Smart Home system. (Yale module sold separately)Security as standard – Built in tamper alarm, PAS24 accredited.Battery Operated – Powered by 4 AA batteries and a warning when they’re running low.Battery Backup – A 9v battery connection port can be used to power the Smart door lock in the event of flat batteries.Secure Push & Turn Thumbturn – Engineered to give additional convenience and security to your door

Prepare for Installation / Reset

Please read the user manual before installing the product.

In order to include (add) a Z-Wave device to a network it must be in factory default
state. Please make sure to reset the device into factory default. You can do this by
performing an Exclusion operation as described below in the manual. Every Z-Wave
controller is able to perform this operation however it is recommended to use the primary
controller of the previous network to make sure the very device is excluded properly
from this network.

Reset to factory default

This device also allows to be reset without any involvement of a Z-Wave controller. This
procedure should only be used when the primary controller is inoperable.

Only use this when the existing Z-Wave controller is missing or inoperable Lift up the lever handleWhile holding the handle up, press the R button 3 times within 1.5 seconds

Inclusion/Exclusion

On factory default the device does not belong to any Z-Wave network. The device needs
to be added to an existing wireless network to communicate with the devices of this network.
This process is called Inclusion.

Devices can also be removed from a network. This process is called Exclusion.
Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is
then performed doing a special manual action right on the device.

Inclusion

Put the Z-Wave controller into add or learn modePress the R button on the lock 3 times quickly (within 1.5 seconds)Refer to the operation manual of the Z-Wave controller to complete the learn in processFor more information on this please visit:www.yale.co.uk/smart-living

Exclusion

Put the existing Z-Wave controller into Remove ModePress the R button on the lock 3 times quickly (within 1.5 secs)The lock is now ready to be added to a new Z-Wave controllerFor more information on this please visit:www.yale.co.uk /smart-living

Quick trouble shooting

Here are a few hints for network installation if things dont work as expected.

1. Make sure a device is in factory reset state before including. In doubt exclude before include.
2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing

Association – one device controls an other device

Z-Wave devices control other Z-Wave devices. The relationship between one device
controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always
related to certain events (e.g. button pressed, sensor triggers, …). In case
the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a ‘Basic Set’ Command.

Association Groups:

Group NumberMaximum NodesDescription

Configuration Parameters

Z-Wave products are supposed to work out of the box after inclusion, however
certain configuration can adapt the function better to user needs or unlock further
enhanced features.

IMPORTANT: Controllers may only allow configuring
signed values. In order to set values in the range 128 … 255 the value sent in
the application shall be the desired value minus 256. For example: To set a
parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56.
In case of a two byte value the same logic applies: Values greater than 32768 may
needed to be given as negative values too.

Parameter 1: Volume

Volume Control (Silent, Low, High)
Size: 1 Byte, Default Value: 3

SettingDescription

Parameter 2: Auto Relock

Auto relock will cause the lock to automatically relock if the Conexis has been unlocked, but the lever handle has not been depressed (no-one has walked through the door). On or Off
Size: 1 Byte, Default Value: 0

SettingDescription

Parameter 3: Relock Time

The amount of time in seconds before the Conexis auto relocks. This will only happenif the Conexis has been unlocked, but the lever handle has not been depressed (no-one has walked through the door).
Size: 1 Byte, Default Value: 30

SettingDescription

Parameter 4: Wrong Tag Limit

The amount if incorrect tags that can be presented to the lock before it times out. Once it has timed out it will stop accepting tags for the amount of time specified in the Wrong Tag timeout
Size: 1 Byte, Default Value: 5

SettingDescription

Parameter 7: Wrong tag timeout

The amount of time the lock will not accept tags for once the wrong tag limit has been reached. It will still be possible to unlock through BLE or the Z-Wave hub.
Size: 1 Byte, Default Value: 180

SettingDescription

Technical Data

Supported Command Classes

• Alarm
• Association Grp Info
• Association V2
• Battery
• Configuration
• Device Reset Locally
• Door Lock Logging
• Door Lock V2
• Firmware Update Md V4
• Manufacturer Specific V2
• Powerlevel
• Security
• Security 2
• Supervision
• Time Parameters
• Time V2
• Transport Service V2
• Version V2
• Zwaveplus Info V2

Explanation of Z-Wave specific terms

• Controller — is a Z-Wave device with capabilities to manage the network.
  Controllers are typically Gateways,Remote Controls or battery operated wall controllers.

• Slave — is a Z-Wave device without capabilities to manage the network.
  Slaves can be sensors, actuators and even remote controls.

• Primary Controller — is the central organizer of the network. It must be
  a controller. There can be only one primary controller in a Z-Wave network.

• Inclusion — is the process of adding new Z-Wave devices into a network.

• Exclusion — is the process of removing Z-Wave devices from the network.

• Association — is a control relationship between a controlling device and
  a controlled device.

• Wakeup Notification — is a special wireless message issued by a Z-Wave
  device to announces that is able to communicate.

• Node Information Frame — is a special wireless message issued by a
  Z-Wave device to announce its capabilities and functions.
