adafruit 969 Articulated Arm Stand for USB Microscope Instructions
- June 5, 2024
- adafruit
Table of Contents
DESCRIPTION
We love pulling out our 5 Megapixel USB microscope for inspecting PCBs once in
a while, but we really got to use it every day when we picked up this
beautiful machined aluminum 3D stand.
It has multiple articulated ‘joints’ for positioning the microscope in any way
and is very sturdy and solid with a large flat base.
A single hand-friendly knob is used to loosen all the joints for positioning,
then tighten it up to fix the position. The microscope is clamped in solidly
but it can easily be removed by releasing the clasp for hand positioning when
you need it. This is the best stand available for this microscope and it makes
an excellent companion!
This is just a microscope stand. A USB microscope is not included! Suitable
for digital microscopes with diameters of 30mm – 35mm. Please check out our
5MP USB Microscope in
Note: As of Monday, March 14th, 2016, this stand now comes with a camera
fixed holder which is suitable for most lightweight cameras.
TECHNICAL DETAILS
| Retaining bracket diameter: | 30 – 35 mm / 1.1″ – 1.3″ |
|---|---|
| Upper arm length: | 120 mm / 4.7″ |
| Lower arm length: | 120 mm / 4.7″ |
| Dimensions (W x D): | 110 x 118 mm / 4.3″ x 4.6″ |
| Weight: | 443 g |
Instructions here (PDF)
