Model: UHNP315-IS02A
USER GUIDE & SERVICE MANUAL
WELCOME TO U-LINE
Congratulations on your U-Line purchase. Your product comes from a company
with over five decades of premium modular ice making, refrigeration, and wine
preservation experience. U-Line continues to be the American leader,
delivering versatility and flexibility for multiple applications including
residential, light commercial, outdoor and marine use. U-Line’s complete
product collection includes Wine Captain® Models, Beverage Centers, Clear Ice
Machines, Nugget Ice Machines, Crescent Ice Makers, Glass & Solid Door
Refrigerators, Drawer Models, Freezers, Combo® Models, and more.
U-Line has captivated those with an appreciation for the finer things with
exceptional functionality, style, inspired innovations, and attention to even
the smallest details. We are known and respected for our unwavering dedication
to product design,
quality, and selection. U-Line is headquartered in Milwaukee, Wisconsin, and
has shipped product to five continents for over two decades and is proud to
have the opportunity to ship to you.
U-LINE — RIGHT PRODUCT. RIGHT PLACE. RIGHT TEMPERATURE
PRODUCT INFORMATION
IMPORTANT – Before connecting your new Nugget Ice Machine, be sure to
carefully follow all manufacturer recomendations throughout this guide
regarding water quality. Please see WATER HOOKUP section for more information.
Looking for additional information on your product? User Guides, Spec Sheets,
CAD Drawings, Compliance Documentation, and Product Warranty information are
all available for reference and download at u-line.com.
PROPERTY DAMAGE / INJURY CONCERNS
In the unlikely event property damage or personal injury is suspected related
to a U-Line product, please take the following steps:
- U-Line Customer Care must be contacted immediately at +1.414.354.0300.
- Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the field without prior written approval from U-Line, claims will not be eligible.
GENERAL INQUIRIES
U-Line Corporation
8900 N. 55th Street
Milwaukee, Wisconsin 53223 USA
Monday – Friday 8:00 am to 4:30 pm CST
T: +1.414.354.0300
Email: sales@u-line.com
u-line.com
SERVICE & PARTS ASSISTANCE
Monday – Friday 8:00 am to 4:30 pm CST
T: +1.414.354.0300
Service Email: onlineservice@u-line.com
Parts Email: onlineparts@u-line.com
CONNECT WITH US
Safety and Warning
NOTICE
Please read all instructions before installing,
operating, or servicing the appliance.
Use this appliance for its intended purpose only and follow these general
precautions with those listed throughout this guide:
SAFETY ALERT DEFINITIONS
Throughout this guide are safety items labeled with a Danger, Warning, or
Caution based on the risk type:
DANGER
Danger means that failure to follow this safety statement will result in
severe personal injury or death.
WARNING
Warning means that failure to follow this safety statement could result in
serious personal injury or death.
CAUTION
Caution means that failure to follow this safety statement may result in minor
or moderate personal injury, property, or equipment damage.
Caution: risk of fire, flammable refrigerant and blowing gas used.
GENERAL PRECAUTIONS
Use this appliance for its intended purpose only and follow these general
precautions with those listed throughout this guide.
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING
Please accord to local regulations regarding disposal of the appliance for its
flammable refrigerant and blowing gas. Before you scrap the appliance, please
remove the doors to prevent child entrapment.
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
WARNING
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING
Do not damage the refrigerating circuit.
This warning is only applicable for appliances with refrigerating circuits
which are accessible by the user.
WARNING
Do not use electrical appliances inside the food/ice storage compartments
unless they are of the type recommended by the manufacturer.
WARNING
When positioning the appliance, ensure the supply cord is not trapped or
damaged.
WARNING
Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance.
WARNING
DO NOT use medical devices or other means to accelerate the defrosting process
other than those recommended by the manufacturer. DO NOT use an ice pick or
other sharp instrument to help speed up defrosting. These instruments can
puncture the inner lining or damage the cooling unit. DO NOT use any type of
heater to defrost. Using a heater to speed up defrosting can cause personal
injury and damage to the inner lining.
NOTICE
Do not lift unit by door handle.
Never install or operate the unit behind closed doors. Be sure front grille is
free of obstruction. Obstructing free airflow can cause the unit to
malfunction and will void the warranty.
Failure to clean the condenser every six months can cause the unit to
malfunction. This could void the warranty.
Allow unit temperature to stabilize for 24 hours before use.
Do not block any internal fans.
Use only genuine U-Line replacement parts.
Imitation parts can damage the unit, affect its operation or performance and
may void the warranty.
This appliance is intended to be used in household and similar applications
such as:
- Staff kitchen areas in shops, offices and other working environments.
- Farm houses and by clients in hotels, motels and other residential type environments.
- Bed and breakfast type environments.
- Catering and similar non-retail applications.
Disposal and Recycling
DANGER
RISK OF CHILD ENTRAPMENT. Before you throw away your old refrigerator or
freezer, take off the doors and leave shelves in place so children may not
easily climb inside.
If the unit is being removed from service for disposal, check and obey all
federal, state, and local regulations regarding the disposal and recycling of
refrigeration appliances, and follow these steps completely:
- Remove all consumable contents from the unit.
- Unplug the electrical cord from its socket.
- Remove the door(s)/drawer(s).
Environmental Requirements
This model is intended for indoor/interior applications only and is not to be
used in installations that are open/exposed to natural elements.
This unit is designed to operate between 50°F (10°C) and 90°F (32°C). Higher
ambient temperatures may reduce the unit’s ability to reach low temperatures
and/or reduce ice production on applicable models.
For best performance, keep the unit out of direct sunlight and away from heat
generating equipment.
In climates where high humidity and dew points are present, condensation may
appear on outside surfaces.
This is considered normal. The condensation will evaporate when the humidity
drops.
CAUTION
Damages caused by ambient temperatures of 40°F (4°C) or below are not covered
by the warranty.
CLIMATE CLASSES
Test room
climate class| Dry bulb
temperature
0C| Relative
humidity
we| Dew point
°C| Water vapor
mass in dry air g/kg
---|---|---|---|---
0| 20| 50| 9.| 7.
1| 16| 80| 13.| 9.
2| 22| 65| 15.| 11.
3| 25| 60| 17.| 12.0
4| 30| 55| 20.0| 15.
6| 27| 70| 21.| 16.
5| 40| 40| 24.| 19.
7| 35| 75| 30.0| 27.
8| 24.| 55| 14.| 10.
NOTE: The water vapor mass in dry air is one of the main points influencing
the performance and the energy consumption of the cabinets.
Electrical
WARNING
SHOCK HAZARD – Electrical Grounding Required.
Never attempt to repair or perform maintenance on the unit until the
electricity has been disconnected.
Never remove the round grounding prong from the plug and never use a two-prong
grounding adapter.
Altering, cutting or removing power cord, removing power plug, or direct
wiring can cause serious injury, fire, loss of property and/or life, and will
void the warranty.
Never use an extension cord to connect power to the unit.
Always keep your working area dry.
If the detachable type electric supply cord is damaged, it must be replaced by
an equivalent cord available from the manufacturer or its service agent.
NOTICE
Electrical installation must observe all state and local codes. This unit
requires connection to a grounded (three-prong), polarized receptacle that has
been placed by a qualified electrician.
The unit requires a grounded and polarized 220-240 VAC, 50 Hz, 8A power supply
(normal household current). An individual, properly grounded branch circuit or
circuit breaker is recommended. A GFCI (ground fault circuit interrupter) is
usually not required for fixed location appliances and is not recommended for
your unit because it could be prone to nuisance tripping. However, be sure to
consult your local codes.
See CUTOUT & PRODUCT DIMENSIONS for recommended receptacle location.
Cutout & Product Dimensions
PREPARE SITE
Your U-Line product has been designed for either freestanding or built-in
installation. When built-in, your unit does not require additional air space
for top, sides, or rear.
However, the front grille must NOT be obstructed, and clearance is required
for an electrical connection in the rear.
CAUTION
Unit can NOT be installed behind a closed cabinet door.
If you would like to align the face of the unit with other adjacent cabinet
doors, you may need to alter the wall just behind the drain connection on the
unit to accommodate the drain.
CUTOUT DIMENSIONS
PRODUCT DIMENSIONS
REAR
FRONT
TOP
SIDE
Side-by-Side Installation
OTHER SITE REQUIREMENTS
Side-by-Side Installation
Units must operate from separate, properly grounded electrical receptacles
placed according to each unit’s electrical specifications requirements.
Cutout width for a side-by-side installation is the total of the widths listed
under Cutout Dimensions in each unit’s Installation Guide. Each door can be
opened individually(one at a time) without interference.
However, to ensure unobstructed door swing (opening both doors at the same time), 1/4″ (6.4 mm) of space needs to be maintained between the units.
Hinge-by-Hinge Installation (Mullion)
When installing two units hinge-by-hinge, 13/16″ (22 mm) is required for
integrated models. Additional space may be needed for any knobs, pulls or
handles installed. ![U-LINE UHNP315-IS02A Ice Makers Refrigeration Appliances
- Figure 8](https://manuals.plus/wp-content/uploads/2024/01/U-LINE-UHNP315 -IS02A-Ice-Makers-Refrigeration-Appliances-Figure-8.png)
Stainless steel models which include the standard stainless handle will require 4-9/16″ (116 mm) to allow both doors to open to 90° at the same time.
Water Hookup
****CAUTION
TO PREVENT DAMAGE TO Y0UR ICE MACHINE AND/OR VOID YOUR WARRANTY, FOLLOW ALL
WATER SUPPLY GUIDELINES AS LISTED BELOW. PREPARE PLUMBING
The water valve uses a standard 1/4” (6.35 mm) compression fitting. U-Line
recommends using accessory water hook up kit – part # 80-54674-00. The kit
includes a 10’ (3 m) braided flexible water supply line and a brasshose
fitting.
CAUTION
Plumbing installation must observe all state and local codes. All water and
drain connections MUST BE made by a licensed/qualified plumbing contractor.
Failure to follow recommendations and instructions may result in damage and/or
harm.
Water Supply
When connecting the water supply, please note the following:
-
Water Mineral Content must meet the following:
◦ TDS: less than 200 ppm (mg/l)
◦ Hardness: Less than 200 mg/l (12 gpg) -
Water supply MUST NOT be from a water softener.
-
A TDS meter is included with your unit
Water Treatment Options
◦ TDS level of 200 ppm or higher and/or a hardness of 12-19 gpg can be treated by U-Line’s in-line water filter accessories available at u-line.com or your local dealer:
ULALINEFILTER — Standard
ULALINEFILTERL — Large
ULALINEFILTERHEAD — 3/8” NPT, initial setup requires head & filter -
Use bypass level 6
Measure Water TDS
Every Nugget Ice Machine comes with a TDS meter similar to the one below. The
TDS meter measures the Total
Dissolved Solids level that exists in the water supply; this is measured in
ppm (parts per million).
WARNING
The TDS meter does not test the toxicity of the water and is not to be used to
determine potability. A TDS METER CANNOT DETECT THE TOXINS THAT MAKE WATER
UNSAFE TO DRINK.
-
Turn on sink faucet and let run for 30 seconds.
-
Fill a clean glass (2 inches of water is sufficient).
-
Remove cap from meter.
-
Turn on meter and immerse meter into the water.
-
Leave meter immersed for 30 seconds.
-
Remove meter and check the readout for the TDS level in ppm – to save the reading, press the hold button.
-
Turn off meter, dry off, and replace cap.
Based upon the TDS measurement, see the below table to determine the correct filter required to protect the ice machine.
Water Quality | 1-3 Users | 4+ Users |
---|---|---|
200 TDS and/or 12 gpg hardness or less | Required for extended warranty | |
Standard Filter Change 1x per year | Required for |
extended warranty
Large Filter
Change 1x per year
201-400 TDS and/or 12-19 gpg hardness| Required Large Filter Change 1x per
year| Required Large Filter Change 2x per year
400+ TDS, and/ or 20+ gpg hardness| Contact your local water quality
professional prior to installation
- The water pressure should be between 20 and 120 psi (138 and 827 kPa).
- The water line MUST have a shut-off valve in the supply line.
- The water line should be looped into 2 coils. This will allow the unit to be removed for cleaning and servicing. Make certain that the tubing is not pinched or damaged during installation.
Use caution when handling back panel. The edges could be sharp.
HOOKUP WATER
-
Turn off water supply and disconnect electrical supply to product prior to attempting installation.
-
Remove the back panel.
-
Thread water line through back panel hole (with bushing).
-
Locate water valve inlet and connect to valve.
-
Turn on water supply and check for leaks.
-
Reinstall back panel.
Drain
Model numbers including “CL” or “NB” do not include a
factory installed drain pump.
Model numbers including “CP” or “NP” include a factoryinstalled drain pump.
DRAIN CONNECTION
CAUTION
If your U-Line unit did not come with a factory installed drain pump you
must use a gravity style drain connection. For assistance in determining if
your unit has a pump please contact U-Line. The floor drain must be large
enough to accommodate drainage from all attached drains. Follow these
guidelines when installing drain lines to prevent water from flowing back into
the ice maker storage bin and/ or potentially flowing onto the floor, which
may result in personal injury or property damage
NOTICE
Drain can NOT be located directly below the unit. Unit has a solid base that
will not allow the unit to drain below itself.
There is a possibility that hose connections may have loosened during
shipment.
Verify all connections and fittings are free from leaks.
CAUTION
This equipment is to be installed with adequate backflow protection to comply
with applicable federal, state and local codes
GRAVITY DRAIN
A gravity drain may be used if:
Drain line has at least a 1” drop per 48” (approximately 2 cm drop per 100 cm)
of run.
Drain line does not create traps and is vented per local code.
- Cut the pre-installed drain tube to length.
- Connect to your local plumbing per the local code.
- If necessary, insulate drain line to prevent condensation.
CAUTION
Failure to connect water supply or drain line connections properly can result
in personal injury and property damage. Gravity drain connections must be
routed downward from the rest of the unit at the rate of 1/4” per foot (1 cm
per 50 cm).
FACTORY INSTALLED DRAIN PUMP
If your drain line will run up to a stand pipe, disposal or spigot assembly,
or does not otherwise meet the requirements for a gravity drain, you may have
ordered afactory installed drain pump.
If you need to install a drain pump into your unit, see DRAIN PUMP section in
the User Manual.
To order a drain pump, order part number
ULADRAINPUMP115V online at u-line.com.
See below for typical installations requiring a drain pump.
NOTICE
The maximum lift for the drain pump is 10 feet. This must be done as close
to the rear of the unit as possible.
Anti-Tip Bracket
Use one of the methods below to secure the unit CABINET/COUNTER ANTI-TIP INSTALLATION (For built-in applications)
-
Slide unit out so screws on front of unit are easily accessible.
-
Remove the two screws from the front of the unit.
-
Bend bracket along one of the perforations to allow attachment to the desired adjoining surface.
-
Gently push unit into position. Be careful not to entangle the electrical cord or water line, if applicable.
-
Check to be sure the unit is level from front to back and side to side. Make any necessary adjustments. The unit’s top surface should be approximately 1⁄8” (3 mm) below the countertop.
-
Secure bracket to adjoining surface.
FLOOR MOUNTED ANTI-TIP INSTALLATION
(For free-standing applications)
-
Locate two anti-tip brackets included with the kit.
-
Place the unit into the area where it will be installed. Check the door, sides, and top for a proper fit. Also test to make sure the door opens and closes freely.
-
Remove grille and place a mark on the floor at the front of the unit. Also place a mark on the floor in the center of the unit.
-
Remove the unit. Using a square, extend center line “B” (see chart below). This line serves as the back edge for the anti-tip brackets. From the center line, measure “A” to the left and right. This line is the outer edge of each bracket.
-
Place the anti-tip brackets on the floor against the line drawn for the outer edge. Mark spots for the screw holes.
-
Use a 1/8” drill to make two starter holes and fasten the anti-tip brackets to the floor using the screws provided.
-
Place the unit back into position, making sure the feet engage the anti-tip brackets properly. Check the alignment of the lines made on the floor in step 3 with the position of the front feet to ensure proper positioning.
General Installation
LEVELING INFORMATION
-
Use a level to confirm the unit is level. Level should be placed along topedge and side edge as shown.
-
If the unit is not level, adjust the legs on the corners of the unit as necessary.
-
Confirm the unit is level after each adjustment and repeat the previous steps as needed.
INSTALLATION TIP
If the room floor is higher than the floor in the cutout opening, adjust the
rear legs to achieve a total unit rear height of 1⁄8” (3 mm) less than
opening’s rear height.
Shorten the unit height in the front by adjusting the front legs. This allows
the unit to be gently tipped into the opening. Readjust the front legs to
level the unit after it is correctly positioned in the opening.
INSTALLATION
- Plug in the power/electrical cord.
- Gently push the unit into position. Be careful not to entangle the cord or water and drain lines, if applicable.
- Re-check the leveling, from front to back and side to side. Make any necessary adjustments. The unit’s top surface should be approximately 1⁄8” (3 mm) below the countertop.
- Install the anti-tip bracket.
- Remove interior packing material and wipe out the inside of the unit with a clean, water-dampened cloth.
Integrated Panel Dimensions
Metric measurements rounded and optimized.
INTEGRATED PANEL
NOTICE
Due to differences in surrounding cabinetry the panel may not perfectly align
with door. The procedure below is designed to provide a finished integrated
panel that seamlessly integrates with surrounding cabinetry.
Panel Preparation
A full integrated door panel completely covers the door frame and provides a
built-in appearance.
NOTICE
The door panel must not weigh more than 20 lbs (10 kg).
It is important to ensure that all drilled holes are drilled to the correct
depth in order to avoid splits in the wood when hardware is installed.
-
Cut the panels to the dimensions listed in the diagram below.
-
Optional: Stain or finish panel to desired stain or color.
Be sure to closely follow the instructions provided by the manufacturer. -
Optional: Install handles and hardware.
NOTICE
When applying an integrated panel to a unit, ensure that both sides are
finished in order to prevent warping. In some panel installations, the panel
may be visible through the glass while the door is open.
Integrated Panel Dimensions
HANDLELESS INTEGRATED DOOR PANEL
The following procedure is designed to provide a finished, handleless solid
panel for an 15” (381 mm) door that seamlessly integrates with its surrounding
cabinetry.
NOTE: Many cabinet manufacturers provide a ready solution for a
handleless, integrated design that can be easily applied to your model.
Consult your cabinet manufacturer for applicable design and installation
details. The cabinet manufacturer’s solution to this design and integration
detail will often result in an integrated panel solution wherein the size of
the panel may result in a height dimension taller than what we specify. This
can be achieved provided the additional height is positioned above the
appliance door.
NOTICE
The integrated panel aligns with the surrounding cabinetry and, due to
differences in cabinetry, may not align perfectly with the door.
The appliance will need up to 34-1/2” (876 mm) to the underside of the counter
to leave room for leveling adjustments.
A single prepared panel with insert must not weigh more than 20 lbs (10 kg).
Integrated Panel Preparation
- Cut the main panel to the dimensions below. For details, see the drawings on the next page.
Main panel width| Main panel height
---|---
14-15/16” (379 mm)| 28-13/16” (732 mm) - Create the top design for the handleless feature and the 1/8” (3 mm) notch for the insert(s) indicated on the Top Detail drawing, on the next page.
- Prepare the insert(s) that will back up the handleless design. Wooden Insert – Cut 1/8” (3 mm) thick wooden insert(s) to the dimensions below.
Wooden insert width| Wooden insert height
---|---
14-15/16” (379 mm| 3-1/2” (89 mm)
-
Optional: Stain or finish panel and wooden insert to desired stain or color. Be sure to closely follow the instructions provided by the manufacturer.
NOTICE
If finishing panel or wooden insert, all sides must be finished to prevent warping. -
Attach the insert to the panel. Wood glue or equivalent adhesive should be used to attach insert to panel.
Handleless Integrated Panel Dimensions
Wooden Insert Dimensions
EXTENDED INTEGRATED PANEL
NOTICE
Due to differences in surrounding cabinetry the panel may not perfectly align
with door.
The procedure below is designed to provide a finished panel that seamlessly
integrates with surrounding cabinetry.
Panel Preparation
An extended integrated panel can be used to maintain alignment with an
adjacent extended cabinet height or a reduced toe-kick/grille application.
- Cut the panels to the dimensions listed in the appropriate diagram on the next page.
- Optional: Stain or finish panel to desired stain or color. Be sure to closely follow the instructions provided by the manufacturer.
- Optional: Install handles and hardware
NOTICE
The door panel must not weigh more than 20 lbs (10 kg).
It is important to ensure that all drilled holes are drilled to the correct
depth in order to avoid splits in the wood when hardware is installed.
Appliance will need up to 34-1/2” (876 mm) to the underside of the counter to
leave room for leveling adjustments.
When applying an integrated panel to a unit, ensure that both sides are
finished in order to prevent warping. In some installations, the panel may be
visible through the glass while the door is open.
- Panel can extend beyond the door frame.
** A minimum of 1” (25 mm) from the floor is required for proper ventilation.
Extended Integrated Panel Dimensions
- A minimum of 1” (25 mm) from the floor to the bottom of the extended integrated panel/frame for proper ventilation.
Integrated Panel Installation
-
Fully open door.
-
Starting at corner, pull gasket away from door.
-
Continue to pull gasket free from gasket channel.
-
Upon removal, lay gasket down on a flat surface.
-
Align top of panel with top edge of door. Center paneon door.
NOTICE
Due to differences in floor construction or surrounding cabinetry, the panel may not sitflush with the top of the door.
-
Secure integrated panel to door using clamps. A robust tape may also be used. U-Linerecommends the use of bar clamps to secure the panel to the door. If using tape, be certain the tape will not damage panel finish upon removal.
-
Using a 7/64″ (3 mm) drill bit, drill 6 pilot holes into the wood panel 1/2″ (12 mm) deep using the holes in the door frame as a guide.
NOTICE
It is important to ensure that all drilled holes are drilled to the correct depth in order to avoid splits in the wood when hardwood is installed. -
Locate 6 of the #6x 1-1/2″ (38 mm) screws provided with your unit.
-
Using a Phillips screwdriver, place one screw into each of the 6 pilot holes and screw down. Do not overtighten screws.
-
Ensure the screws sit flush against the bottom of the channel.
-
Remove clamps from door.
NOTICE
If panel requires additional adjustment after removing clamps, slightly loosen each screw and adjust panel as necessary. Tighten screws upon completion. -
Starting at the corners, re-install the gasket into the gasket channel in the frame. Make sure the gasket is fully seated.
Grille Installation
REMOVING AND INSTALLING GRILLE
WARNING
Disconnect electric power to the unit before removing the grille.
When using the unit, the grille must be installed.
WARNING
DO NOT touch the condenser fins. The condenser fins are SHARP and can be
easily damaged.
Removing the grille
- Disconnect power to the unit.
- Loosen the two screws (1).
- Remove grille (2) from unit.
Installing the grille
- Align cabinet and grille holes and secure, but do not over tighten grille screws (1).
- Reconnect power to the unit.
Door Swing
For Integrated models that are installed adjacent to a wall, 1/2″ (13 mm)
clearance is recommended from wall on hinge side to allow the door to open
90°. Allow for additional space for any knobs or pulls installed on the
integrated panel/frame.
Stainless Steel models that are installed adjacent to a wall require 2-1/4″
(57 mm) door clearance on hinge side to allow for door handle.
Units have a zero clearance when installed adjacent to cabinets.
Integrated
Stainless
Door Stop
Your U-Line unit was shipped to you with the optional 90° pin.
Your unit’s door(s) will open 115° straight from the factory. If you would
like the door stop at 90°, follow these instructions.
NOTICE
If your unit is already undercounter, it will need to be moved out to access
the hinge.
- Open door approximately 90°.
- Slide hinge pin into hole as shown. Pin should slide into place, stopping the door at 90°; if the pin does not go into the hole shown, hold the door less than 90° open and try again.
- To fully seat the pin, tap it lightly with a hammer.
- Carefully slide your unit back in place.
NOTICE
The pin can be removed to return the door swing back to its original 115°
swing by tapping the pin out from the bottom of the hinge.
CLOSER
The door hinge has a self-closing feature that engages when the door is open
approximately 6” (150 mm) (about 25°).
Door Adjustments
DOOR ALIGNMENT AND ADJUSTMENT
Align and adjust the door if it is not level or not sealing properly. If the
door is not sealed, the unit may not cool properly, or excessive frost or
condensation may form in the interior.
NOTICE
Properly aligned, the door’s gasket should be firmly in contact with the
cabinet all the way around the door (no gaps). Carefully examine the door’s
gasket to ensure that it is firmly in contact with the cabinet. Also make sure
the door gasket is not pinched on the hinge side of the door.
CAUTION
Do not attempt to use the door to raise or pivot your unit. This would put
excessive stress on the hinge system.
Alignment and Adjustment Procedure
- Open door and remove gasket near the hinges.
- Using a T-25 Torx bit, loosen each pair of Torx head screws both the upper and lower hinge plates.
- Square and align door as necessary.
- Tighten Torx head screws on hinge.
- Reinstall gasket into the channel starting at the corner.
REVERSING THE DOOR
-
Open door.
-
Using T-25 Torx bit loosen screw #1 and remove screw #2 on top and bottom hinge. Slide and remove the door from the unit.
Note: One hinge includes a metal spacer. Spacer must be used with that hinge when reversing the door. -
Remove caps from screw heads on opposite side (2 on top and 2 on bottom). Using #2 Phillips bit, remove the 4 underlying screws. Reinstall the screws and caps on the opposite side.
-
Partially install screw #1 in the outer most holes on top and bottom. Rotate door 180o, align hinge over screw #1 and slide/seat into position. Reinstall screw #2 on top and bottom. Tighten both screws and install hinge cover.
Align and adjust the door:
Align and adjust the door (see DOOR ALIGNMENT AND ADJUSTMENT).
First Use
Initial startup requires no adjustments. See CONTROL OPERATION section for
more details.
NOTICE
U-Line recommends discarding the ice produced during the first two to three
hours of operation to avoid possible dirt or scale that may dislodge from the
water line.
When plugged in, the unit will begin operating under the factory default
settings. If the unit was turned off during installation, simply press and the
unit will immediately switch on. To turn the unit off, press and release.
Control Operation
DOOR ALERT NOTIFICATION
When the door is left open for more than 30 minutes:
- Ice production will cease
- A tone will sound for several seconds every minute
- will appear in display
- Close door to silence alert and reset (Ice production will resume if bin sensor is not satisfied)
Airflow and Product Loading
NOTICE
The unit requires proper airflow to perform at its highest efficiency. Do not
block the front grille at any time, or the unit will not perform as expected.
Do not install the unit behind a door.
Cleaning
EXTERIOR CLEANING
Vinyl Clad (Black or White) Models
Clean surfaces with a mild detergent and warm water solution. Do not use
solvent-based or abrasive cleaners.
Use a soft sponge and rinse with clean water. Wipe with a soft, clean towel to
prevent water spotting. Clean any glass surfaces with a non-chlorine glass
cleaner.
Stainless Models
Stainless door panels, handles and frames can discolor when exposed to
chlorine gas, pool chemicals, saltwater or cleaners with bleach.
Keep your stainless unit looking new by cleaning with a good quality all-in-
one stainless steel cleaner and polish monthly. For best results use Claire®
Stainless Steel Polish and Cleaner. Comparable products are acceptable.
Frequent cleaning will remove surface contamination that could lead to rust.
Some installations may require cleaning weekly.
Do not clean with steel wool pads.
Do not use stainless steel cleaners or polishes on any glass surfaces.
Clean any glass surfaces with a non-chlorine glass cleaner.
Do not use cleaners not specifically intended for stainless steel on stainless
steel surfaces (this includes glass, tile, and counter cleaners).
If any surface discoloring or rusting appears, clean it quickly with Bon-Ami®
or Barkeepers Friend Cleanser® and a nonabrasive cloth. Always clean with the
grain. Always finish with Claire® Stainless Steel Polish and Cleaner or
comparable product to prevent further problems.
Using abrasive pads such as ScotchBrite™ will cause the graining in the
stainless steel to become blurred.
Rust not cleaned up promptly can penetrate the surface of the stainless steel
and complete removal of the rust may not be possible.
For information on Keg and Tap Towers, please reference the Single and Double
Tap Tower Kits User Guide on u-line.com.
Integrated Models
To clean integrated panels, use household cleaner per the cabinet
manufacturer’s recommendations.
INTERIOR CLEANING
Disconnect power to the unit.
Clean the interior and all removed components using a mild nonabrasive
detergent and warm solution applied with a soft sponge or non-abrasive cloth.
Rinse the interior using a soft sponge and clean water.
Do not use any solvent-based or abrasive cleaners. These types of cleaners may
transfer taste and/or odor to the interior products and damage or discolor the
interior.
NUGGET ICE MACHINE CLEANING CYCLE
This ice machine has an automatic clean alert function.
The control will indicate CL in the display, reminding you to clean your unit.
When CL is displayed, ice production will continue. Depending on water
conditions, more frequent cleaning may be necessary: see chart below.
Cleaning removes lime scale, other mineral deposits, and sanitizes the
machine. Poor ice quality and reduced ice output are signs that cleaning is
necessary.
BEFORE RUNNING THE CLEANING CYCLE, MEASURE THE TDS (TOTAL DISSOLVED SOLIDS)
LEVEL OF YOUR WATER SUPPLY.
CAUTION
(See WATER HOOKUP section in this guide to find instructions for using the TDS
meter that was included with this ice machine.)
U-Line Corporation (U-Line) Limited Warranty
One Year Limited Warranty
For one year from the date of original purchase, this warranty covers all
parts and labor to repair or replace any part of the product that proves to be
defective in materials or workmanship. For products installed and used for
normal residential use, material cosmetic defects are included in this
warranty, with coverage limited to 60 days from the date of original purchase.
All service provided by U-Line under the above warranty must be performed by a
U-Line factory authorized servicer, unless otherwise specified by U-Line.
Service provided during normal business hours.
Two Year Limited Warranty (5 Class Product)
For two years from the date of original purchase, this warranty covers all
parts and labor to repair or replace any part of the product that proves to be
defective in materials or workmanship. For products installed and used for
normal residential use, material cosmetic defects are included in this
warranty, with coverage limited to 60 days from the date of original purchase.
All service provided by U-Line under the above warranty must be performed by a
U-Line factory authorized servicer, unless otherwise specified by U-Line.
Service provided during normal business hours.
Available Second & Third Year Limited Warranty
In addition to the standard one and two year warranties outlined above, U-Line
offers a one year extension of the warranties from the date of purchase, free
of charge. To take advantage of this extension, you must register your product
with U-Line within 60 days from the date of purchase at u-line.com and
provide proof of purchase. Nugget Ice Machine proof of purchase must include
the purchase of an in-line water filter and filter head to qualify for this
additional limited warranty.
Five Year Sealed System Limited Warranty
For five years from the date of original purchase, U-Line will repair or
replace the following parts, labor not included, that prove to be defective in
materials or workmanship: compressor, condenser, evaporator, drier, and all
connecting tubing. All service provided by U-Line under the above warranty
must be performed by a U-Line factory authorized servicer, unless otherwise
specified by U-Line. Service provided during normal business hours.
Terms
These warranties apply only to products installed in any one of the fifty
states of the United States, the District of Columbia, or the ten provinces of
Canada. The warranties do not cover any parts or labor to correct any defect
caused by negligence, accident or improper use, maintenance, installation,
service, repair, acts of God, fire, flood or other natural disasters. The
product must be installed, operated, and maintained in accordance with your
product’s User Guide.
The remedies described above for each warranty are the only ones that U-Line
will provide, either under these warranties or under any warranty arising by
operation of law. U-Line will not be responsible for any consequential or
incidental damages arising from the breach of these warranties or any other
warranty, whether express, implied, or statutory. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. These warranties give you
specific legal rights, and you may also have other rights which vary from
state to state.
Any warranty that may be implied in connection with your purchase or use of
the product, including any warranty of merchantability or any warranty fit for
a particular purpose is limited to the duration of these warranties, and only
extends to five years in duration for the parts described in the section
related to the five year limited warranty above. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitations
may not apply to you.
- The warranties only apply to the original purchaser and are non-transferable.
- The second, third, and five year warranties cover products installed and used for normal residential or designated marine use only.
- The warranties apply to units operated outside only if designed for outdoor use by model and serial number.
- U-Line Commercial products are covered by the one year and 5 year limited warranties and are not eligible for the second and third year limited warranties.
- Replacement water filters, light bulbs, and other consumable parts are not covered by these warranties.
- The start of U-Line’s obligation is limited to four years after the shipment date from U-Line.
- In-home instruction on how to use your product is not covered by these warranties.
- Food, beverage, and medicine loss are not covered by these warranties.
- If the product is located in an area where U-Line factory authorized service is not available, you may be responsible for a trip charge or you may be required to bring the product to a U-Line factory authorized service location at your own cost and expense.
- Units purchased after use as floor displays, and/or certified reconditioned units, are covered by the limited one year warranty only and no coverage is provided for cosmetic defects.
- Signal issues related to Wi-Fi connectivity are not covered by these warranties.
For parts and service assistance, or to find U-Line factory authorized service near you, contact U-Line: 8900 N. 55th
Street, Milwaukee, WI 53223
u-line.com
onlineservice@u-line.com
+1.414.354.0300
Copyright U-Line Corporation. All Rights Reserved. | Publication Number 30379
| 11/2022 Rev. P
References
- Blank | Spesialister på digital produktutvikling
- cord.No
- drain.no is parked
- fall.no
- harm.P65warnings.CA
- BestShop | Best Price, Smart Shopping
- LineService.com
- unit.No
- Kosher Certificates | Kosher Certification | STAR-K
- U-LineService.com
Read User Manual Online (PDF format)
Read User Manual Online (PDF format) >>
