Jintaobao

3CH Touch Wall Switch

SKU: JTB-3011-03

Quickstart

This is a ****

On/Off Power Switch
for
CEPT (Europe).

To run this device please connect it to your mains power supply.

To add this device to your network execute the following action:
Start master controller add device mode as instruction, press and hold the channel 1 touch icon (located on leftmost) for 2 second, RF icon LED on right bottom flashindicator inclusion processing until included or 60 seconds timeout no detect any master controller.

Please refer to the
Manufacturers Manual for more information.

Important safety information

Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law.
The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material.
Use this equipment only for its intended purpose. Follow the disposal instructions.

Do not dispose of electronic equipment or batteries in a fire or near open heat sources.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This
device is suited for use in the region mentioned in the Quickstart section.

Z-Wave ensures a reliable communication by reconfirming every message ( two- way
communication) and every mains powered node can act as a repeater for other nodes
( meshed network ) in case the receiver is not in direct wireless range of the
transmitter.

This device and every other certified Z-Wave device can be used together with any other
certified Z-Wave device regardless of brand and origin as long as both are suited for the
same frequency range.

If a device supports secure communication it will communicate with other devices
secure as long as this device provides the same or a higher level of security.
Otherwise it will automatically turn into a lower level of security to maintain
backward compatibility.

For more information about Z-Wave technology, devices, white papers etc. please refer
to www.z-wave.info.

Product Description

The product is designed to operate with neutral wire control three channel loads individually. Zero-cross detect function to support a large load of less than 800 Watt per channel.Each channel supports associated control another multi-channel endpointto setup multi-control switch.An individual led indicates inclusion/exclusion processing status.Standard 86 size box with 25mm depth of embedded only.

Prepare for Installation / Reset

Please read the user manual before installing the product.

In order to include (add) a Z-Wave device to a network it must be in factory default
state. Please make sure to reset the device into factory default. You can do this by
performing an Exclusion operation as described below in the manual. Every Z-Wave
controller is able to perform this operation however it is recommended to use the primary
controller of the previous network to make sure the very device is excluded properly
from this network.

Reset to factory default

This device also allows to be reset without any involvement of a Z-Wave controller. This
procedure should only be used when the primary controller is inoperable.

The factory default settings are restored when the device is removed from the network.Please use this procedure only when the network primary controller is missing or otherwise inoperable.

Safety Warning for Mains Powered Devices

ATTENTION: only authorized technicians under consideration of the country- specific
installation guidelines/norms may do works with mains power. Prior to the assembly of
the product, the voltage network has to be switched off and ensured against re-switching.

Inclusion/Exclusion

On factory default the device does not belong to any Z-Wave network. The device needs
to be added to an existing wireless network to communicate with the devices of this network.
This process is called Inclusion.

Devices can also be removed from a network. This process is called Exclusion.
Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is
then performed doing a special manual action right on the device.

Inclusion

Start master controller add device mode as instruction, press and hold the channel 1 touch icon (located on leftmost) for 2 second, RF icon LED on right bottom flashindicator inclusion processing until included or 60 seconds timeout no detect any master controller.

Exclusion

Start master controller remove device mode as instruction, press and hold the channel 1 touch icon (located on leftmost) for 2 second, RF icon LED on right bottom flash indicator inclusion processing until included or 15 seconds timeout no detect any master controller.LED flash slowly indicated has no included any controller.

Quick trouble shooting

Here are a few hints for network installation if things dont work as expected.

1. Make sure a device is in factory reset state before including. In doubt exclude before include.
2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing

Association – one device controls an other device

Z-Wave devices control other Z-Wave devices. The relationship between one device
controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always
related to certain events (e.g. button pressed, sensor triggers, …). In case
the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a ‘Basic Set’ Command.

Association Groups:

Group NumberMaximum NodesDescription

1| 1| Z-Wave Plus Lifeline, assigned to send switch lifeline status to associated devices.
---|---|---
2| 1| Association Group 2 is assigned to send Basic Set On frame to associated devices corresponding while channel 1 switch turn on.
3| 1| Association Group 3 is assigned to send Basic Set Off frame to associated devices corresponding while channel 1 switch turn off.
4| 1| Association Group 4 is assigned to send Basic Set On frame to associated devices corresponding while channel 2 switch turn on.
5| 1| Association Group 5 is assigned to send Basic Set Off frame to associated devices corresponding while channel 2 switch turn off.
6| 1| Association Group 6 is assigned to send Basic Set On frame to associated devices corresponding while channel 3 switch turn on.
7| 1| Association Group 7 is assigned to send Basic Set Off frame to associated devices corresponding while channel 3 switch turn off.

Technical Data

Motor)LEDMLV (Magnetic)
Frequency| XXfrequency
Maximum transmission power| XXantenna

Supported Command Classes

• Association Grp Info
• Association V2
• Basic
• Device Reset Locally
• Manufacturer Specific V2
• Multi Channel Association V3
• Multi Channel V4
• Powerlevel
• Switch All
• Switch Binary
• Version V2
• Zwaveplus Info V2

Controlled Command Classes

• Basic

Explanation of Z-Wave specific terms

• Controller — is a Z-Wave device with capabilities to manage the network.
  Controllers are typically Gateways,Remote Controls or battery operated wall controllers.

• Slave — is a Z-Wave device without capabilities to manage the network.
  Slaves can be sensors, actuators and even remote controls.

• Primary Controller — is the central organizer of the network. It must be
  a controller. There can be only one primary controller in a Z-Wave network.

• Inclusion — is the process of adding new Z-Wave devices into a network.

• Exclusion — is the process of removing Z-Wave devices from the network.

• Association — is a control relationship between a controlling device and
  a controlled device.

• Wakeup Notification — is a special wireless message issued by a Z-Wave
  device to announces that is able to communicate.

• Node Information Frame — is a special wireless message issued by a
  Z-Wave device to announce its capabilities and functions.
