advantech Modular Fanless Box PC
Features
- Intel 6th/7th Gen Intel® CoreTM U-series (i3/i5/i7)
- VGA and HDMI dual display, option 3rd display for triple display
- 12V lockable DC jack power input
- 9-36V optional power module compatible with all-in-one ordering
- -20 ~ 60 °C extend temperature operating
- 2 x full-size mPCIe expansion for WIFI/Cellular communication module
- 1 x full-size mSATA and 1 x 2.5″ SATA storage device
- Advantech iDoor module compatible
- Advantech ARK Plus module support by dual-layer configurations
Specifications
1 SIM holder is the hardware interface for wireless communication integration
only. System-level RF certification is not available.
Fanless Embedded Box PCs
All product specifications are subject to change without notice.
Dimensions
Front Panel External I/O Mechanical Layout/Drawing
*Power Input module by option
Rear Panel External I/O Mechanical Layout/Drawing
Ordering Information
Note: Memory, storage, and an operating system bundled by request.
- i5-6300U/i5-7300U are supported by T-P/N with MOQ 30 pcs.
Packing List
ARK-2250 Expansion Option Items
Optional Embedded OS
Note: Default BIOS is for 64bit OS support only. 32bit OS will need to update BIOS
Optional Item for Default SKU
Optional MOS modules for iDoor Expansion
- When configuring with MOS-2120-Z1201, please update BIOS with Advantech part number 1420048565.
Optional 9-36V DC Power module
Optional Display Module
ARK-2250 Dual Layer Expansion Option Items
Optional modules for ARK Plus Expansion
ARK Plus Extended Modules
AMO-2201E
4 x RS232/422/485 + removable 2.5″ drive bay
Specifications
Ordering Information
AMO-2202E
4 x 10/100/1000Base T(X) PoE
Specifications
Ordering Information
AMO-2203E
2-Port isolated CAN-Bus
Specifications
Ordering Information
AMO-2204E
3-Port GbE + iDoor
Specifications
Ordering Information
- 2nd iDoor supported. Please refer to “Optional MOS modules for iDoor Expansion
Online Download www.advantech.com/products
