Whirlpool WTW4850HW 3.9 Cu. Ft. White Top Load Washer User Guide
- June 5, 2024
- Whirlpool
Table of Contents
WTW4850HW 3.9 Cu. Ft. White Top Load Washer
User Guide
WARNING
Fire Hazard
Never place items in the washer that are dampened with gasoline or other
flammable fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on it (including cooking
oils).
Doing so can result in death, explosion, or fire.
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS, located in your
appliance’s Owner’s Manual, before operating this appliance.
NOTES:
- Not all features and cycles are on all models, and control panel appearance may vary.
- If your model has a touch interface, the control panel features a sensitive surface that responds to a light touch of your finger. To ensure your selections are registered, touch the control panel with your fingertip, not your fingernail. When selecting a setting or option, simply touch its name.
- If your model has physical buttons, make sure to press the button firmly.
- At cycle completion, your setting and option choices will be remembered for the next cycle. However, if power to the washer is lost, the settings and options will go back to the factory defaults.
Step 1. Add HE Detergent
NOTE: See the “Adding Laundry Products” section for more information on
adding HE detergent, fabric softener, and/or bleach.
Step 2. Load Clothes
For best results, load garments in loose heaps evenly around the basket wall.
Step 3. Close Lid; then Select Cycle and Settings
Step 4. Press Start/Stop
Cycle Guide – Normal Cycle
For best fabric care, choose the cycle that best fits the load being washed. Recommended settings for best performance are shown in bold. Not all cycles and options are available on all models. Not all settings and options are available on each cycle.
Items to Wash: | Cycle: | Temperature: | Description: |
---|---|---|---|
Cotton, linens, and mixed-garment loads | Normal-Regular | Hot Warm Cool Cold | |
Tap Cold | Use this cycle for normally soiled cotton and mixed-fabric loads. A |
high spin speed is a default for this cycle.
Online Ordering Information
For detailed installation instruction and maintenance information, winter
storage, and transportation tips, please see the Owner’s Manual included with
your machine.
For information on any of the following items, a full-cycle guide, detailed
product dimensions, or complete instructions for use and installation, please
visit https://www.whirlpool.com/owners, or in Canada
https://www.whirlpool.ca/owners. This may save you the cost of a service
call.
However, if you need to contact us, use the information listed below for the appropriate region.
United States:
1–800–253–1301
Whirlpool Brand Home Appliances
Customer Experience Center
553 Benson Road
Benton Harbor, MI 49022–2692| Canada:
1–800–807–6777
Whirlpool Brand Home Appliances
Customer Experience Centre
200–6750 Century Ave.
Mississauga, Ontario L5N 0B7
---|---
Button Descriptions
Designed to use only HE High- Efficiency detergents.
WASH TEMPERATURE
Wash Temperature senses and maintains uniform water temperatures by regulating
incoming hot and cold water.
Select a wash temperature based on the type of fabric and soils being washed.
For best results and following the garment label instructions, use the warmest
wash water safe for your fabric.
NOTES:
- On some models and cycles, warm and hot water may be cooler than your previous washer.
- Even in a cold- or cool-water wash, some warm water may be added to the washer to maintain a minimum temperature. All rinses are cold.
FABRIC SOFTENER
This option must be set to “Yes” if you are using fabric softener in the
fabric softener dispenser. This ensures that fabric softener is added at the
correct time in the rinse for even distribution.
WATER LEVEL
Set the Water Level knob to the Auto Sensing setting and the washer will fill
to a level that ensures the load engages the agitator. From this point, the
electronic control will sense the load and determine if additional water is
needed.
Set the Water Level knob to the Deep Water Wash setting and the washer will
fill to the maximum water level.
NOTE: Expect longer cycle times due to extended fill times when using the
Deep Water Wash option. Deep Water Wash is unavailable in the Normal cycle
mode. The normal cycle with the Deep Water Wash modifier chosen will result in
Auto Sensing water level.
WASH CYCLE KNOB
Use the Wash Cycle knob to select available cycles on your washer.
Turn the knob to select a cycle for your laundry load. See the online “Cycle
Guide” for detailed descriptions.
START/STOP BUTTON
Press to start the selected cycle; press again to pause the cycle and unlock
the lid.
NOTE: If the washer is spinning, it may take several minutes to unlock
the lid. Press and hold for 3 seconds to cancel a cycle.
CYCLE STATUS
The Cycle Status lights show the progress of a cycle. At each stage of the
process, you may notice sounds or pauses that are different from your previous
washer.
Sensing/Fill
When the Start/Stop button is pressed and the Water Level knob is set to Auto
Sensing, the washer will fill and begin sensing to determine load size and
balance.
Once sensing is complete, the washer will fill to the appropriate level for
the detected load size and then begin the wash phase of the cycle.
NOTE: Sensing and wash phases will be paused by opening the unlocked lid.
Close the lid to resume the cycle. If the lid is left open for more than 10
minutes, the washer will cancel the cycle and pump out the water. The lid will
lock after the wash phase to begin the initial spinout and remain locked for
the remainder of the cycle.
Wash
The washer will fill to the correct water level based on the load size and the
Water Level selection. Certain cycles may agitate during the filling process
to boost cleaning. You will hear the agitator rotate, followed by a pause
lasting several seconds. When the wash cycle begins, you will hear the
agitator increase speed. The motor sounds may change at different stages in
the wash cycle while the washer performs different wash actions.
Rinse
Certain cycles use a spray rinse, which adds water to the tub while the basket
spins. When Fabric Softener “Yes” is selected, you will hear sounds similar to
the wash cycle as the washer rinses and moves the load. You may hear the motor
turning on briefly (short hum) to move the basket while filling.
Final Spin
The washer spins the load at increasing speeds for proper water removal based
on the selected cycle and spin speed.
Cycle Complete
Once the cycle is complete, the lid will unlock and this light will come on.
Remove the load promptly for best results.
Lid Locked
The lock feature allows for higher spin speeds. When the Lid Locked light is
lit, the lid is locked and cannot be opened without pausing the cycle. When
the light is off, the lid can be opened.
To open the lid after it has been locked, press Start/Stop. The lid will
unlock once the washer movement has stopped. This may take several minutes if
the load was spinning at a high speed. Press Start/Stop again to resume the
cycle.
WARNING: Do not wash water-resistant or water repellant-type clothing.
Failure to closely follow these instructions may result in an abnormal
vibrating and out-of balance condition that could result in physical injury,
property damage, and/or appliance damage.
Adding Laundry Products
IMPORTANT: Using non-HE detergent will likely result in longer cycle times and reduced rinsing performance. It may also result in component malfunction and, over time, the buildup of mold or mildew. HE detergents should be low-sudsing and quick-dispersing to produce the right amount of suds for the best performance.![Whirlpool WTW4850HW 3 9 Cu Ft White Top Load Washer
- figure 7](https://manuals.plus/wp-content/uploads/2022/04/Whirlpool- WTW4850HW-3-9-Cu-Ft-White-Top-Load-Washer-figure-7-550x217.jpg)
Adding HE detergent to the basket:
Add a measured amount of HE detergent or single-dose laundry packets into the
basket. If using Oxitype boosters, color-safe bleach, or fabric softener
crystals, add to the bottom of the washer basket before adding clothes.
NOTE: Follow the manufacturer’s instructions to determine the number of
laundry products to use.
Adding liquid chlorine bleach:
Do not overfill, dilute, or use more than 1 cup (236 mL). Do not use color-
safe bleach or Oxi products in the same cycle as liquid chlorine bleach.
Adding liquid fabric softener to dispenser:
Pour a measured amount of liquid fabric softener into the dispenser; always
follow the manufacturer’s directions for the correct amount of fabric softener
based on your load size. Dilute liquid fabric softener by filling the
dispenser with warm water until liquid reaches the underside of the rim. See
Max Fill line arrows.
Adding liquid fabric softener manually to wash load:
During the final rinse, wait until the washer has completed filling and press
the Start/Stop button to pause the washer. Lift the lid and add the measured,
recommended amount of liquid fabric softener. Do not use more than the
recommended amount. Close the lid and press the Start/Stop button again to
start the washer. Always follow the manufacturer’s directions for the correct
amount of fabric softener based on your load size.
IMPORTANT: Fabric Softener knob must be set to “Yes” when using the fabric softener dispenser. This ensures that fabric softener is added at the correct time in the rinse for even distribution.
W11556498A
W11556537A-SP
