INSTALLATION MANUAL
GARD 3250 Automatic Road Barriers
MANUAL RELEASE
Releasing the device may be dangerous for the user, if the boom fastening has
been damaged or if the boom is no longer intact, as the result of an accident
or installation error.
In these cases, the tensioned springs no longer guarantee that the boom is
balanced. The boom may suddenly rotate when being released.
Manual release may cause the operator to move in an uncontrolled manner due to
a mechanical fault or an imbalance.
GENERAL PRECAUTIONS FOR INSTALLERS
Important safety instructions.
Please follow all of these instructions. Improper installation may cause
serious bodily harm.
Before continuing, please also read the general precautions for users.
Only use this product for its intended purpose. Any other use is hazardous. •
The manufacturer cannot be held liable for any damage caused by improper,
unreasonable or erroneous use. • This product is defined by the Machinery
Directive (2006/42/EC) as partly completed machinery. • Partly completed
machinery means an assembly which is almost machinery but which cannot in
itself perform a specific application. • Partly completed machinery is only
intended to be incorporated into or assembled with other machinery or other
partly completed machinery or equipment thereby forming machinery to which the
Machinery Directive (2006/42/EC) applies. • The final installation must comply
with the Machinery Directive (2006/42/EC) and the European reference standards
in force. • The manufacturer declines any liability for using non-original
products, which would also void the warranty.
• All operations indicated in this manual must be carried out exclusively by
skilled and qualified personnel and in full compliance with the regulations in
force. • The device must be installed, wired, connected and tested according
to good professional practice, in compliance with the standards and laws in
force. • Make sure the mains power supply is disconnected during all
installation procedures. • Check that the temperature ranges given are
suitable for the installation site. • Make sure that opening the automatic
barrier does not constitute a hazard. • Do not install on slopes i.e. any
surfaces that are not perfectly level. • Do not install the operator on
surfaces that could yield and bend. If necessary, add suitable reinforcements
to the anchoring points. • Make sure that no direct jets of water can wet the
product at the installation site (sprinklers, water cleaners, etc.). • Make
sure you have set up a suitable dual-pole cut-off device along the power
supply that is compliant with the installation rules. It should completely cut
off the power supply according to category III surcharge conditions. •
Demarcate the entire site properly to prevent unauthorised personnel from
entering, especially minors. • In case of manual handling, have one person for
every 20 kg that needs hoisting; for non-manual handling, use proper hoisting
equipment in safe conditions. • When the operator is being fixed in place, it
may be unstable and overturn. Be careful and do not lean on it until it is
fully fastened in place. • Use suitable protection to prevent any mechanical
hazards due to persons loitering within the operating range of the operator. •
The electrical cables must pass through special pipes, ducts and cable glands
in order to guarantee adequate protection against mechanical damage. • Make
sure that the moving mechanical parts are suitably far away from the wiring. •
The electrical cables must not touch any parts that may overheat during use
(such as the motor and transformer). • All fixed controls must be clearly
visible after installation, in a position that allows the guided part to be
directly visible, but far away from moving parts. In the case of a hold-to-run
control, this must be installed at a minimum height of 1.5 m from the ground
and must not be accessible to the public. • If the passage is wider than 3 m,
you must use a fixed support for the boom. • If not already present, apply a
permanent tag that describes how to use the manual release mechanism close to
it. • Make sure that the operator has been properly adjusted and that the
safety and protection devices and the manual release are working properly. •
Before handing over to the final user, check that the system complies with the
harmonised standards and the essential requirements of the Machinery Directive
(2006/42/EC). • Any residual risks must be indicated clearly with proper
signage affixed in visible areas, and explained to end users. • Put the
machine’s ID plate in a visible place when the installation is complete. • If
the power supply cable is damaged, it must be immediately replaced by the
manufacturer or by an authorised technical assistance centre, or in any case,
by qualified staff, to prevent any risk. • Keep this manual inside the
technical folder along with the manuals of all the other devices used for your
automation system. • Make sure to hand over to the end user all the operating
manuals of the products that make up the final machinery. • The product, in
its original packaging supplied by the manufacturer, must only be transported
in a closed environment (railway carriage, containers, closed vehicles). • If
the product malfunctions, stop using it and contact customer services at
https://www.came.com/global/en/contact-us or via the telephone number on the
website. • The manufacture date is provided in the production batch printed on
the product label. If necessary, contact us at https://www.came.com/global/en
/contact-us. • The general conditions of sale are given in the official CAME
price
Main points of danger for people Risk of trapping hands.
No transiting.
DISMANTLING AND DISPOSAL
CAME S.p.A. employs an Environmental Management System at its premises. This
system is certified and compliant with the UNI EN ISO 14001 standard to ensure
that the environment is respected and safeguarded. Please continue
safeguarding the environment. At CAME we consider it one of the fundamentals
of our operating and market strategies. Simply follow these brief disposal
guidelines:
DISPOSING OF THE PACKAGING
The packaging materials (cardboard, plastic, etc.) can be disposed of easily
as solid urban waste, separated for recycling.
Before dismantling and disposing of the product, please always check the local
laws in force.
DISPOSE OF THE PRODUCT RESPONSIBLY.
DISPOSING OF THE PRODUCT
Our products are made of various materials. Most of these materials
(aluminium, plastic, iron and electrical cables) are classified as solid urban
waste. They can be separated for recycling and disposed of at authorised waste
treatment plants.
Other components (electronic boards, transmitter batteries, etc.) may contain
pollutants.
These must be removed and disposed of by an authorised waste disposal and
recycling firm.
It is always advisable to check the specific laws that apply in your area.
DISPOSE OF THE PRODUCT RESPONSIBLY.
PRODUCT DATA AND INFORMATION
Key
This symbol shows which parts to read carefully.
This symbol shows which parts describe safety issues.
This symbol shows what to tell users.
The measurements, unless otherwise stated, are in millimetres.
When the device is in operation, some mechanical parts are hot and may cause
burns.
Description
G4000
Barrier made of painted galvanized steel designed to fit accessories.
G4001
Barrier made of AISI 304 satin-finish steel, designed to fit accessories.
G4000N
Barrier made of grey painted galvanized steel designed to fit accessories.
G40001-316
Barrier with cabinet made from satin-finished AISI 316 steel designed to fit
accessories.
G4000X
Barrier made of galvanized steel with customised RAL paint designed to fit
accessories.
G4010
Barrier made of painted galvanized steel set up to fit accessories. The
barrier includes balance springs (1 x 001G04060).
G4010X
Barrier made of galvanized steel with customised RAL paint designed to fit
accessories.
Intended use
Ideal solution for apartment blocks and industrial use.
Any installation and/or use other than that specified in this manual is
forbidden.
Usage limitations
References
Read User Manual Online (PDF format)
Read User Manual Online (PDF format) >>
