A4 portable printer
Quick Start Guide
Before using this product, please read this manual carefully.

Package Contents

Phomemo A4 Portable Printer - Fig 1

1	2	3	4	5
Printer*1	Data Cable*1	F4lannel Bag*1	Quick Start Guide*1	Ink Ribbon*1

Printer Components

1	Indicator Light (Status)
2	Indicator Light

(Connection)
3| Power Button
4| Power Port
5| Reset Button
6| Open Cover Button

Button Function

(Power) Button Function	Operation
(Power) Button Function	Press and hold the button for around 3 seconds until

the indicator light turns on.
Turn on the printer| Double-press the button to print QR code. You can scan the QR code using the App on the phone and connect to the printer.
Turn off the printer| Press and hold the button for around 3 seconds until the indicator light turns off.

Indicator Light

| Status/Function| Indicator Light
---|---|---
Pri| Normal| Lit (Green)
Low Power| Blink Slowly (Red)
No Power: Automatic Shutdown| Blink Quickly (Red)—’Off
Charging| Blink Slowly (Green)
Fully Charged| Lit (Green)
Printing Normally| Lit (Green)
Finished Printing| Lit (Green)
On/Off Button| Lit (Green)
Pa per St| Normal| Lit (Green)
No Paper (Ink Ribbon) / Paper Not Detected| Lit (Red)
install Paper (ink Ribbon)| Lit (Green)
Paper Compartment Opened| Lit (Green)
Paper Compartment Closed| Lit (Green)
Others| Print Head is overheated| Lit (Red)
Connecti Status| Reset Button| Printer and Light are Off
Bluetooth: Receiving Data| Indicator Light (Connection) – Blink Quickly (Green)
Bluetooth: Disconnecting| Indicator Light (Connection) – Off
Bluetooth: Connected| Indicator Light (Connection) – Lit (Green)
PC: Receiving Data| Indicator Light (Connection) – Blink Quickly (Green)
PC: Disconnecting| Indicator Light (Connection) – Off
PC: Connected| Indicator Light (Connection) – Lit (Green)

Precautions

Please use 5V ****2A input for charging.
Please connect the USB cable to the power adapter before charging, Please gently insert or unplug the charging cable when charging, to prevent excessive force from damaging the port.
After the charging is completed, please unplug the charging cable in time.
In order to avoid danger, do not use or charge in the environment of high temperature, high humidity, heavy smoke and dust, such as in bathroom, steam room, near to open flame, etc.
Improper charging may cause damage to the print head.
Do not touch the print head to prevent scalding caused by overheating.
The tearing blade is sharp, please be careful to avoid touching it by mistake.
If the machine is malfunctioning, insert the reset hole to restart the machine.

Battery warning instructions

It is forbidden to disassemble, hit, squeeze the battery, or throw it into fire;
If severe swelling occurs, please do not reuse it;
Do not place in a high temperature environment, and it is strictly prohibited to use the battery after soaking in water;
There is a danger of explosion if the battery is replaced by the wrong type. Be sure to dispose of the used battery according to the instructions;
If consumers use a power adapter for power supply, they should purchase a power adapter that meets the requirements of corresponding safety standards or a power adapter with CCC certification.

Install App

7.1 Download the App
Please search for “Phomemo” on your phone’ s App market and download the App.
7.2 How to download and install driver
Download the latest driver from the official website. Download the relevant driver according to the your operating system version and follow the instruction to install the driver. Official website:
Download
T831 App in Google Play
T831 App in APP Store
T831 PC Driver For Windows
T831 PC Driver For MAC
NOTE

If you wish to obtain more tutorials on how to install the driver, please open your Phomemo APP > Profile > Use Tutorial to obtain more guidance.

7.3 Connect the printer to the App
Method 1:
Turn on your phone’ s Bluetooth and open your Phomemo App. Press the button on the top right of your Phomemo App home page and select P831 from the list.
NOTE
system needs to enable positioning and allow app to obtain relevant permissions.
Method 2:
Double-press the printers power button to print a QR code. Open your Phomemo App and press the button on the top right of your Phomemo App home page. On the selection page, press scan and scan the QR code to connect to the printer.

Instruction Manual

8.1 Installing Ink Ribbon

Press the two Open Cover Buttons at the same time to open the cover.
Put the Ink Ribbon flat in the device according to the right direction shown.
Close the Cover.

8.2 Paper usage method

The printer supports a wide range of paper sizes, so please adjust the snap position in the direction of the arrow in the diagram below, depending on the size of the paper being used.
Use two hands to hold the paper and make sure it is straight and aligned. Insert the paper carefully into the printer’ s feeder until the roller pulls the paper to its optimal position. To get the best printing quality, please use original papers.
When you need to take out the printing paper, press the PUSH buttons simultaneously to open the printer cover and take out the paper.

NOTE

The paper must be inserted aligned to the paper feeder.
The printer supports various kinds of paper sizes. It can print both sides of normal paper.

After-sales Service

9.1 Warranty description
100% warranty within 1 year

Although the product has undergone strict testing and quality inspection, accidents may occur during transportation, resulting in damages to the machine. If there is any problem with the printer, please contact us through the following methods. We have a quick response after-sales team to solve the problem professionally.
If the problem is still not solved through our joint efforts, we will replace you with a new machine for free, and you need not to pay any fees. Your satisfaction makes us advance.

9.2 After-sales information
OnlineContact information: Whatsapp : +86 13928088284 / +86 15338193665 Skype : Phomemo Team-Jessie / Phomemo Team-Helen Customer Service phone number: +1 855 957 5321(US only) Service time: Mon-Fri 9AM-5PM (EST) for any questions & suggestions. Email address: support@phomemo.com Official Website: www.phomemo.com Otelube Please search for “Phomemo” to get the printer operation guide

FCC Warning

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
IC Caution:
Radio Standards Specification RSS-Gen, issue 5 – English: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’ s licence-ex-empt RSS(s). Operation is subject to the following two conditions: This device may not cause interference. This device must accept any interference, including interference that may cause undesired operation of the device. RF exposure statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
