ROCODILE J1708 Contactless Reader User Manual

ROCODILE J1708 Contactless Reader

Product Information

The CANCrocoLITE is a contactless reader developed by TECHNOTON JV, Minsk, and BELARUS. It is designed for use in Telematics systems to read data from the onboard CAN bus of personal cars and light commercial vehicles without interfering with the integrity of electronic circuits.

Specifications

• Product Name: CANCrocoLITE
• Version: 1.0

Distinctive Features:

• Allows data reading from onboard CAN bus without interference
• Used for Telematics systems

Important:
It is strongly recommended to strictly follow the instructions in the Operation Manual for the proper use, mounting, and maintenance of the CANCrocoLITE. Certified professionals trained by the manufacturer should carry out its installation and setup.

The manufacturer guarantees that the CANCrocoLITE complies with technical regulations provided that it is stored, transported, and operated according to the conditions specified in the Manual.

Note:
The CANCrocoLITE is used together with the MasterCAN vehicle data interface.

Product Usage Instructions

Installation and Setup:
For the proper functioning of the CANCrocoLITE, follow these steps:

1. Ensure that certified professionals trained by the manufacturer carry out the installation and setup.
2. Refer to the Installation section in the Operation Manual for detailed instructions on mounting and connecting the CANCrocoLITE.

Application Area:
The CANCrocoLITE output signal is received by a tracking device that collects, records, stores, and transfers the received signals to the vehicle tracking system server. The software installed on the server processes and analyzes the received data, compiling reports that contain information on fuel consumption, operating modes of the engine, sensor status, and troubleshooting of the vehicle.

FAQ (Frequently Asked Questions)

• Q: What is the purpose of the CANCrocoLITE?
  A: The CANCrocoLITE is designed to read data from the onboard CAN bus of personal cars and light commercial vehicles without interfering with the electronic circuits. It is used in Telematics systems for various purposes such as monitoring fuel consumption and engine performance.

• Q: Who should carry out the installation and setup of the CANCrocoLITE?
  A: Certified professionals who are trained by the manufacturer should handle the installation and setup of the CANCrocoLITE to ensure its proper functioning.

• Q: What kind of reports can be generated using the CANCrocoLITE?
  A: The CANCrocoLITE provides data that can be used to generate reports on fuel consumption, engine operating modes, sensor status, and vehicle troubleshooting.

Revision history

Terms and Definitions

• ORF 4 — is the Telematics Service by Technoton developed for receiving and processing Onboard Reports via the Internet, displaying Operational Data overlapped on area maps, information storage in the database and Analytical Reports generation upon the user’s request.
• S6 — is the vehicle onboard data interface developed by JV Technoton to enable integration of the GPS/GLONASS-based vehicle monitoring system into the vehicle electrical equipment. It comprises a set of cables, interfaces and protocols. Physically, it is implemented based on CAN 2.0B (ISO 11898-1:2003) and K-Line (ISO 9141). S6 bus data exchange protocol complies with SAE J1939 International Standard. To get more details on the S6 telematics interface visit http://s6.jv-technoton.com/en/ Telematics interface S6 operation manual contains guidelines and rules that refer to the S6 cabling system, S6 SK service kit and service software for the S6 Telematics interface
• PGN (Parameter Group Number) — is a combined group of S6 parameters, which has a common name and number. Functional Modules (FM) of the Unit can have input/output PGNs and set-up PGNs.
• SPN (Suspect Parameter Number) — an informational unit of S6. Each SPN has a determined name, number, extension, data type and numerical value. The following types of SPN exist: Parameters, Counters, Events. SPN can have a qualifier that allows qualification of the parameter’s value (e.g. – Onboard power supply limit/Minimum).
• FMS are data packets of vehicles’ digital onboard interfaces (further on vehicles) that comply with the document FMS-Standard Interface Description (further on — FMS-Standard). FMS-Standard is an open FMS Interface Standard developed by world-leading truck manufacturers. More detailed descriptions of FMS messages are described in the FMS-Standard Interface description document. The actual version of the document can be downloaded from the website of the developer http://www.fms-standard.com.
• Telematics — a special set of telematics messages developed by Technoton. Meets requirements of SAE J1939/71 standards. Telematics messages contain important operation parameters of vehicle.
• Onboard equipment (OE) — Telematics System Elements, directly installed in the vehicle.
• Telematics terminal (Tracking device, Telematics unit) is a unit of Telematics System used for reading the signals of Vehicle standard and additional sensors, getting location data and transmitting the data to the Server.
• Telematics system — complex solution for real-time and after-trip vehicle monitoring and control. Main vehicle parameters monitored: route, fuel consumption, operation time, the technical condition of the vehicle, and safety. Consists of OE, Communication channels, Telematics service ORF 4.
• Vehicle — an object controlled within the Telematic system. Usually, a Vehicle means a truck, tractor or bus, sometimes a locomotive or river boat. From the Telematic system point of view, stationary objects are also considered to be vehicles: diesel gensets, stationary tanks, boilers/burners.

Introduction

• Recommendations and guidelines contained in this Operation Manual are related to contactless reader CANCrocoLITE (hereinafter CANCrocoLITE) developed by TECHNOTON JV, Minsk, BELARUS.
• This document contains information on CANCrocoLITE design, principle of operation, specifications as well as recommendations on its installation, connection and exploitation.

CANCrocoLITE
Is a tool for Telematics systems used for data reading from onboard CAN buses of personal cars and light commercial vehicles without interference in the integrity of electronic circuits.

Distinctive features of CANCrocoLITE:

• contactless data obtained through wire insulation without interfering with its integrity;
• zero impact on the electronic and electrical equipment of the Vehicle;
• compact open-frame design allows a handy connection to the wires of the CAN bus even in the most hard-to-reach places of a car;
• reliable protection of car’s electronic circuits against exposures via CAN interface, e.g. active requests sent from connected Telematics unit;
• safe data integration from one or several informational vehicle buses to the Telematics interface *;
• powered from the vehicle’s onboard power supply — does not require a piece of additional equipment (power supply unit);
• protected against reverse polarity;
• easy to install and operate;
• setting-up is not needed;
• competitive price.

ATTENTION:
It is strongly recommended to follow strictly the instructions of the present Manual when using, mounting or maintaining CANCrocoLITE.

To ensure the proper functioning of CANCrocoLITE, certified professionals who are trained by the manufacturer should carry out its installation and setup. The Manufacturer guarantees CANCrocoLITE compliance with the requirements of technical regulations subject to the conditions of storage, transportation and operation set out in this Manual.

• When CANCrocoLITE is used together with the MasterCAN vehicle data interface.

See Figure 1 for identification codes for CANCrocoLITE ordering:

ATTENTION:
While making an order, it is allowed not to specify the identification codes that correspond to the basic version of CANCrocoLITE.

Example of CANCrocoLITE ordering identification codes:

“Contacless reader CANCrocoLITE”, (output interface — CAN 2.0B; nominal supply voltage — 12/24 V; length of connecting cable — 0.5 m; end of connecting cable — isolated wires with bare end).

ATTENTION:
The manufacturer reserves the right to modify CANCrocoLITE specifications that do not lead to a deterioration of the consumer qualities without prior customer notice.

General information and technical specifications

Purpose of use and application area

• CANCrocoLITE is used for contactless data reading from CAN buses of personal cars and light commercial vehicles. CANCrocoLITE generates an output signal fully corresponding to a data set of the connected vehicle bus.
  Application – CANCrocoLITE is used within the Telematics system to obtain available data on fuel consumption, engine operation modes, the status of sensors and gauges, and the presence of malfunctions.

• CANCrocoLITE can be installed on all types of personal cars, vans and light commercial vehicles equipped with CAN bus (see Figure 2).

• CANCrocoLITE is compatible with all types of Telematics terminals that have a port for CAN bus connection.

• CANCrocoLITE output signal is received by a tracking device that collects, records, stores and transfers received signals to the vehicle tracking system server. Software installed on the server processes and analyzes received data and then compiles reports that contain information on fuel consumption, operating modes of the engine, sensors status and troubleshooting of the vehicle (see figure 3).

• While used together with MasterCAN vehicle data interfaces, CANCrocoLITE becomes a ready-made solution for safe data integration from the automotive CAN bus into the S6 Telematics interface. It allows the monitoring of over 100 operation parameters of Vehicles via just one CAN-port of the telematics terminal (see Figure 4).

• Output messages content (FMS и Telematics), installation and setting-up sequence and other useful information about MasterCAN can be found in the MasterCAN operation manual.

• ORF 4 Telematics service’s reports, based on data obtained via CANCrocoLITE, which is used together with MasterCAN CC, provide extensive possibilities for monitoring of vehicle’s hourly fuel consumption as well as total fuel consumption per trip (see Figure 5).

WARNING:
Set of information transmitted via CAN bus may differ depending on the manufacturer, model and manufacture year of a Vehicle.

Delivery set

1. Contactless reader – 5 pcs.;
2. Specification containing basic technical characteristics and brief installation instructions – 1 pc.;
3. Cable tie – 10 pcs.

Figure 6 — CANCrocoLITE delivery set.

Technical specifications

Main exploitation specifications
Table 1 —CANCrocoLITE main exploitation specifications

Parameter, measuring unit

|

Value

---|---
Acceptable message loss, %, not more than| 1
Nominal supply voltage for versions U12/24, V| 12 or 24
Current consumption at supply voltage 12 V, mA, not more| 10
Current consumption at supply voltage 24 V, mA, not more| 12.5
Power supply voltage range for versions U12/24, V| from 9 to 36
Temperature range, °C| from -40 to +85
Dimensions, mm, not more than| see figure 7
Weight, kg, not more| 0.05
Compatibility| SAE J1939, CAN Open,

DeviceNet, NMEA 2000

Overall Dimensions

Output interface of CANCrocoLITE
CANCrocoLITE output interface — CAN 2.0B, according to international standard SAE J1939.

Unit structure and operation principle of CANCrocoLITE

• The principle of CANCrocoLITE operation is based on reading the electromagnetic field that is formed around the wires during the signal passing.
• CANCrocoLITE forms digital output signals that contain data packages identical to the signal of the connected CAN bus. This signal can contain information about the operating modes of the engine, fuel consumption, sensor status, and malfunctioning of the Vehicle.

Connection of CANCrocoLITE

ATTENTION:
Strictly follow safety rules of automobile repair works as well as local safety rules of the customer company when mounting CANCrocoLITE. Before CANCrocoLITE installation it is recommended to study carefully the electrical circuit diagram and the Operating Manual of the vehicle on which CANCrocoLITE is mounted.

Exterior inspection before connection

• It is required to conduct CANCrocoLITE exterior inspection for the presence of possible defects of body or connectors arising during transportation, storage or careless use.
• Contact the supplier if any defects are detected.

Recommendations for the search of CAN bus wires

• To connect CANCrocoLITE to the on-board CAN bus, you should find and identify CAN-H (CAN HIGH) and CAN-L (CAN LOW) wires.
• Physically, the CAN bus most often represents a twisted (stranded) pair of wires (30 windings per running meter) with splitters to connect electronic control units (further on – ECU) that have terminating resistors of 120 Ohms nominal impedance located at the ends of the bus. The resistors may be mounted separately or may be integrated into the ECU. As a rule, there is no SHLD wire.

Example:
DEUTSCH company manufactures CAN buses made of special three-conductor cable (CAN-H, CAN-L, and signal GND) with 7 to 12 mm external coating diameter, special splitters, and terminating elements – terminating resistors designed to match wave impedance during the transmission of messages in the bus and to suppress interference (see figure 9).

• There may be from one to six and more CAN buses on the vehicle of EURO-3 Environmental Standard. They may be defined as M-CAN, T-CAN, I-CAN, H-CAN, A-CAN, EBS-CAN etc.
• The following three CAN buses are of interest for fuel consumption monitoring: T-CAN, M-CAN, and I-CAN (seldom).

T-CAN and M-CAN may have the following features:

• Availability of OBD II connector for diagnostics (see figure 10);
• the color and cross-section of stranded pairs of wires;
• connection of stranded pairs of wires to contacts at OBD II and ECU connectors.

Example:
If there is an OBD II diagnostics connector on the vehicle and a pair of stranded wires of orange colour one of which has a black band, and the other has a brown one, and this pair of stranded wires matches the OBD II diagnostics connector, so this may be the CAN bus you are looking for. In this case, the orange wire with the black band is CAN-H, while the wire with the brown band is CAN-L.

Contacts of the ABS/ASR ECU system corresponding to the CAN bus are identified according to Figure 11.

WARNING:
Features of CAN bus may be different for different vehicle manufacturers. Besides, those features may be different for the same manufacturer depending on the design features of the vehicle and its configuration (the engine, fuel supply system, the link between the engine EDC and the throttle pedal, availability or absence of the electronic dashboard, digital tachograph, etc).

Initial diagnostics and assessment of CAN bus serviceability may be carried out using a multimeter by means of the following traditional methods:

• continuity test of CAN-L and CAN-H wires;
• short circuit and impedance check (full impedance depending on the terminating resistors and input impedance of ECUs connected to the bus) between CAN-L and CAN-H wires;
• measurement of voltages in CAN-L and CAN-H wires in the recessive mode (the ignition is off, the battery disconnect switch is on) and in the dominant mode (the ignition is on and the engine has been started).

The impedance check should be carried out with the whole onboard circuit off (the battery disconnect switch is off). The control impedance value must be no more than 60 Ohms.

The serviceability check of the CAN bus is carried out with the ignition and engine on, by pressing and releasing the throttle pedal between the wires of the stranded pair of wires. The control voltage value must be from 1.2 to 3.0 V.

CAN-H and CAN-L can be identified according to the following voltage values:

• recession mode — about 2.5 V (on both CAN-L and CAN-H);
• dominant mode — less than 2.5 V (on CAN-L) and more than 2.5 V (on CAN-H).

Examples of oscilloscope pictures of signals from CAN-high and CAN-low are presented in Figure 12.

Exploitation restrictions

• To install CANCrocoLITE, you need to choose a dry area protected from aggressive environmental influences.
• It is not allowed to install CANCrocoLITE near heating or cooling elements (e.g.: climate-control systems). Also, it is not recommended to install CANCrocoLITE close to the automobile power circuits. The driver’s cabin will be the best place for the installation.
• During installation under the automobile hood, you need to make sure that CANCrocoLITE housing and its cable are located at least 10 cm away from engine rotating parts and surfaces.

Electrical connection
CANCrocoLITE can be powered from the Vehicle’s onboard power network or from the Tracking device.

ATTENTION:

1. Before starting the CANCrocoLITE installation, it is needed to disconnect the electrical circuit of the Vehicle. To do this, you shall use the battery disconnect switch or remove contact terminals from it.
2. It is recommended to use fuses when connecting the CANCrocoLITE power supply (see Figure 13 a). The nominal fuse current is not more than 2 A.
3. CANCrocoLITE power supply “+” and Ground “-” wires should be connected to the same points of the vehicle’s electric circuit as the correspondent wires of the Tracking device.
4. Prior to the electrical connection of the CANCrocoLITE pay special attention to checking vehicle chassis ground. The resistance between any point of the vehicle chassis and the “-” terminal of the battery or between terminals of the chassis ground switch should not exceed 1 Ohm.

To connect CANCrocoLITE power supply wires, it is recommended to use terminals (see Figure 13 b), while connecting signal wires, it is recommended to use connectors as shown in Figure 13 c.

CANCrocoLITE electrical connection is made according to the interface cable wires assignment (see Table 2).

Table 2 — CANCrocoLITE cable wires assignment

After powering on CANCrocoLITE, please switch on the battery (ignition).

Contactless connection to the vehicle wires
To connect CANCrocoLITE, follow the steps by Figure 14.

1. put CAN bus wires on the CANCrocoLITE board according to the marking.
2. firmly fix wires using two cable ties from the delivery set.
3. CANCrocoLITE is ready for operation.

Figure 14 — Steps for CANCrocoLITE connection

Functioning check

• If the connection is done correctly, CANCrocoLITE starts its operation as soon as it is powered on (ignition is on). When you disconnect the power supply (turning off the ignition),
• CANCrocoLITE will be switched off.
• The correctness of the connection can be confirmed by the presence of CAN bus data in the output interface of CANCrocoLITE.

Disconnecting CANCrocoLITE

ATTENTION:
Before you start CANCrocoLITE dismounting, you need to disconnect the electrical circuit of the Vehicle. To do this, you shall use the battery disconnect switch or remove contact terminals from it.

To switch off CANCrocoLITE, you need to fulfil the following steps:

1. Disconnect the CANCrocoLITE connection cable (wire) from the Tracking device. If CANCrocoLITE is powered from the onboard power supply, you need to disconnect CANCrocoLITE power (“+” and “-” wires) from the onboard power supply.
2. Carefully cut cable ties, which fix CAN bus wires on the CANCrocoLITE electronic board.
3. Put off CAN bus wires from the CANCrocoLITE board’s surface.

After dismounting, you can use CANCrocoLITE on other Vehicles.

Packing
CANCrocoLITE delivery set (see 1.2) is placed in a bubble package 230×170 mm.

Storage

• CANCrocoLITE is recommended to be stored in dry enclosed areas or other premises with natural ventilation, without simulated climatic conditions and unheated warehouses.
• CANCrocoLITE storage is allowed only in original packaging at a temperature range from -50 to +40° C and relative humidity up to 98 % at 25 °C.
• Do not store CANCrocoLITE in the same room with substances that cause metal corrosion and/or contain aggressive impurities.

Transportation

• Transportation of CANCrocoLITE is recommended in closed transport that protects CANCrocoLITE from mechanical damage and precipitation.
• Air environment in transportation compartments should not contain acid, alkaline and other aggressive impurities.

Utilization/re-cycling

• CANCrocoLITE does not contain harmful substances and ingredients that are dangerous to human health and the environment during and after the end of life and recycling.
• CANCrocoLITE does not contain precious metals in an amount that should be recorded.

Contacts

Manufacturer

• http://www.jv-technoton.com
• Tel/fax: +375 17 240-39-73
• E-mail: info@jv-technoton.com.

Technical support

• E-mail: support@technoton.by.

Contactless readers CANCrocoLITE. Operation manual. Version 1.0 © Technoton, 2017.
