Saykey

PIR Detect Sensor

SKU: SK-3003-07

Quickstart

This is a ****

Alarm Sensor
for
CEPT (Europe).

Please make sure the internal battery is fully charged.

To add this device to your network execute the following action:

1. Make sure battery level is normally and the product is located within direct range of the ZWave controller.2) Set the main controller into the inclusion/Add device mode (refer to main controllers operating manual).3) Click the Add/Remove button on the left side of product triple times in 1.5 seconds.4) The product will be detected and included in the ZWave network.

Please refer to the
Manufacturers Manual for more information.

Important safety information

Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law.
The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material.
Use this equipment only for its intended purpose. Follow the disposal instructions.

Do not dispose of electronic equipment or batteries in a fire or near open heat sources.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This
device is suited for use in the region mentioned in the Quickstart section.

Z-Wave ensures a reliable communication by reconfirming every message ( two- way
communication) and every mains powered node can act as a repeater for other nodes
( meshed network ) in case the receiver is not in direct wireless range of the
transmitter.

This device and every other certified Z-Wave device can be used together with any other
certified Z-Wave device regardless of brand and origin as long as both are suited for the
same frequency range.

If a device supports secure communication it will communicate with other devices
secure as long as this device provides the same or a higher level of security.
Otherwise it will automatically turn into a lower level of security to maintain
backward compatibility.

For more information about Z-Wave technology, devices, white papers etc. please refer
to www.z-wave.info.

Product Description

This product equips with precision spherical Fresnel lens, to improve the efficiency of energy reception, high sensitivity and to reducefalse alarm rate.

Prepare for Installation / Reset

Please read the user manual before installing the product.

In order to include (add) a Z-Wave device to a network it must be in factory default
state. Please make sure to reset the device into factory default. You can do this by
performing an Exclusion operation as described below in the manual. Every Z-Wave
controller is able to perform this operation however it is recommended to use the primary
controller of the previous network to make sure the very device is excluded properly
from this network.

Reset to factory default

This device also allows to be reset without any involvement of a Z-Wave controller. This
procedure should only be used when the primary controller is inoperable.

The factory default settings are restored when the device is removed from the network or press and hold the Add/Remove button onthe left side of product excess 10 seconds.Please use this procedure only when the network primary controller is missing or otherwise inoperable.

Inclusion/Exclusion

On factory default the device does not belong to any Z-Wave network. The device needs
to be added to an existing wireless network to communicate with the devices of this network.
This process is called Inclusion.

Devices can also be removed from a network. This process is called Exclusion.
Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is
then performed doing a special manual action right on the device.

Inclusion

1. Make sure battery level is normally and the product is located within direct range of the ZWave controller.2) Set the main controller into the inclusion/Add device mode (refer to main controllers operating manual).3) Click the Add/Remove button on the left side of product triple times in 1.5 seconds.4) The product will be detected and included in the ZWave network.

Exclusion

1. Make sure battery level is normally and the product is located within direct range of the ZWave controller.2) Set the main controller into the exclusion/Remove device mode (refer to main controllers operating manual).3) Click the Add/Remove button on the bottom side of product triple times in 1.5 seconds.4) The product will be detected and excluded from the ZWave network.

Communication to a Sleeping device (Wakeup)

This device is battery operated and turned into deep sleep state most of the time
to save battery life time. Communication with the device is limited. In order to
communicate with the device, a static controller C is needed in the network.
This controller will maintain a mailbox for the battery operated devices and store
commands that can not be received during deep sleep state. Without such a controller,
communication may become impossible and/or the battery life time is significantly
decreased.

This device will wakeup regularly and announce the wakeup
state by sending out a so called Wakeup Notification. The controller can then
empty the mailbox. Therefore, the device needs to be configured with the desired
wakeup interval and the node ID of the controller. If the device was included by
a static controller this controller will usually perform all necessary
configurations. The wakeup interval is a tradeoff between maximal battery
life time and the desired responses of the device. To wakeup the device please perform
the following action:

The product is in battery power, you can set up the wake up time based in seconds. At each wake up, the product communicateswith the master controller to updates parameters settings if necessary, e.g. receive the association group setting. The product will wake up at defined time interval and will ALWAYS try to communicate with the master controller. Longer time interval means less frequent communication and thus a longer battery life.The product default wakeup interval is 86400 seconds. User can operate inclusion/exclusion process in order to trigger productwakeup manually, it will keeps 30 seconds in wakeup state without initial wakeup parameter setting and keeps 10 seconds inwakeup after initial wakeup parameter.

Quick trouble shooting

Here are a few hints for network installation if things dont work as expected.

1. Make sure a device is in factory reset state before including. In doubt exclude before include.
2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing

Association – one device controls an other device

Z-Wave devices control other Z-Wave devices. The relationship between one device
controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always
related to certain events (e.g. button pressed, sensor triggers, …). In case
the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a ‘Basic Set’ Command.

Association Groups:

Group NumberMaximum NodesDescription

1| 1| Z-Wave Plus Lifeline, assigned to send unsolicited report of motion detection status, battery level and factory default reset to the associated device as soon while the status is change.
---|---|---
2| 5| assigned to send Notification report to other device while motion detected.
3| 5| assigned to send Binary sensor report to other device while motion detected.
4| 5| assigned to send Basic Set On Command to control other device while the PIR sensor detect motion.
5| 5| assigned to send Basic Set Off Command to control other device while the PIR sensor detect motion.
6| 5| assigned to send Basic Set On Command to control other device while the PIR sensor clear motion.
7| 5| assigned to send Basic Set Off Command to control other device while the PIR sensor clear motion.

Technical Data

Supported Command Classes

• Application Status
• Association Grp Info
• Association V2
• Battery
• Device Reset Locally
• Firmware Update Md V2
• Manufacturer Specific V2
• Multi Channel Association V3
• Notification V4
• Powerlevel
• Sensor Binary
• Version V2
• Wake Up V2
• Zwaveplus Info V2

Controlled Command Classes

• Basic

Explanation of Z-Wave specific terms

• Controller — is a Z-Wave device with capabilities to manage the network.
  Controllers are typically Gateways,Remote Controls or battery operated wall controllers.

• Slave — is a Z-Wave device without capabilities to manage the network.
  Slaves can be sensors, actuators and even remote controls.

• Primary Controller — is the central organizer of the network. It must be
  a controller. There can be only one primary controller in a Z-Wave network.

• Inclusion — is the process of adding new Z-Wave devices into a network.

• Exclusion — is the process of removing Z-Wave devices from the network.

• Association — is a control relationship between a controlling device and
  a controlled device.

• Wakeup Notification — is a special wireless message issued by a Z-Wave
  device to announces that is able to communicate.

• Node Information Frame — is a special wireless message issued by a
  Z-Wave device to announce its capabilities and functions.
