OWNER’S MANUAL

Outdoor LP Gas / Charcoal Barbecue Grill

Model No. GBC1793W

WARNING
FOR YOUR SAFETY:

1. Do NOT store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other appliance.


2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

WARNING
FOR YOUR SAFETY:
For Outdoor Use Only! (outside any enclosure)

DANGER
If you smell gas 1. Shut off gas to the appliance.

1. Extinguish any open flame.


2. Open lid.


3. If odor continues, keep away from the appliance, immediately call your gas supplier or your fire department.
   Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death.

The use and installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2, or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
This instruction booklet contains important safety information. Please read and keep for future reference.
If you are assembling this unit for someone else, give this manual to him or her to read and save for future reference.
California Proposition 65: Handling the brass material on this product exposes you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash your hands after handling this product.

WARNING
CALIFONIA PROPOSITION 65
This product can expose you to chemicals including benzene, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
DANGER
Never operate this appliance unattended.

Manufactured in China for: RevoAce Inc. Limited
Hong Kong, China
1.800.694.0013 • service@revoace.com
8:00 am to 4:00 pm central time, Monday to Friday.
GBC1793W-OM-E-F101

FOR YOUR SAFETY

WARNINGS:

1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.
2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.
3. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.
4. This instruction manual contains Important information necessary for the proper assembly and safe use of the appliance.
5. Read and follow all warnings and instructions before assembling and using the appliance.
6. Follow all warnings and instructions when using the appliance.
7. Keep this manual for future reference.

IMPORTANT SAFEGUARDS

DANGER: Failure to follow the dangers, warnings, and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property.
WARNINGS:

• This grill is for outdoor use only, and should not be used in a building, garage, or any other enclosed area.

• Do NOT operate, light, or use this appliance within ten feet (3.05 m) of walls, structures, or buildings.

• For residential use only. This grill is NOT for commercial use.

• This grill is NOT intended for and should never be used as a heater. TOXIC fumes can accumulate and cause asphyxiation.

• This grill is safety certified for use in the United States and/or Canada only. Do NOT modify for use in any other location. The modification will result in a safety hazard and will void your warranty.

•  Do NOT use the grill for indoor cooking. TOXIC carbon monoxide fumes can accumulate and cause asphyxiation. W Propane: The “gas” side of the grill, from the factory, is for use with liquid propane (LP) gas only. The conversion to or attempted use of natural gas in this LP gas grill is dangerous, may cause bodily harm and
  will void your warranty.

• Charcoal: Never use charcoal that has been pre-treated with lighter fluid. Use only high-grade plain charcoal, charcoal/wood mixture, lump charcoal or cooking wood. The conversion to or attempted use of any other fuel source in this charcoal grill is dangerous and will void your warranty.

•  Propane: Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene, or alcohol in the “gas” side of the grill.

• LP gas characteristics:
  a. LP gas is flammable and hazardous if handled improperly. Become aware of the characteristics before using any LP gas product.
  b. LP gas is explosive under pressure, heavier than air, and settles/pools in low areas.
  c. LP gas in its natural state has no odor. For your safety, an odorant is added that smells like rotten cabbage.
  d. Contact with LP gas can cause freeze burns to the skin.

• Apartment dwellers: Check with management to learn the requirements and fire codes for using an LP gas grill in your apartment complex. If allowed, use outside on the ground floor with a ten-foot (3.05 m) clearance from any structure. Do NOT use on or under balconies.

• LP gas cylinder needed to operate. Only cylinders marked “propane” may be used.

• The LP gas cylinder must be constructed and marked in accordance with the Specifications for LP-gas Cylinders of the U.S. Department of Transportation (D.O.T.) or the National Standard of Canada, CAN/ CSA-B339, Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods; and Commission.

• LP gas cylinder must be arranged for vapor withdrawal.

• The LP gas cylinder must have a listed overfilling prevention device (OPD).

• Only use LP gas cylinders equipped with a cylinder connection device compatible with the connection for outdoor cooking appliances.

• The LP gas cylinder must have a cylinder collar to protect the cylinder valve.

• Never use a LP gas cylinder with a damaged body, valve, collar or footing.

• Dented or rusted LP gas cylinders may be hazardous and should be checked by your LP gas supplier prior to use.

• The LP gas cylinder should not be dropped or handled roughly.

• LP gas cylinders must be stored outdoors out of the reach of children and must not be stored in a building, garage or any other enclosed area. Your cylinder must never be stored where temperatures can reach over 125°F.

• Do NOT insert any tool or foreign object into the valve outlet or safety relief valve. You may damage the valve and cause a leak. Leaking propane may result in an explosion, fire, severe personal injury or death.

•  Do NOT block holes in sides or back of grill.

• Never keep an LP gas cylinder in a hot car or trunk. Heat will cause the gas pressure to increase, which may open the relief valve and allow gas to escape.

• Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane.

• If grill is not in use, the gas must be turned off at the supply cylinder and disconnected.

• Do NOT store a spare LP gas cylinder under or near this appliance.

• Never fill the cylinder beyond 80 percent full.

• A fire causing serious injury or damage to property may occur if the above is not followed exactly.

•  Never attempt to attach this grill to the self-contained LP gas system of a camper trailer, motor home or house.

• Your grill has been checked at all factory connections for leaks. Recheck all connections as described in the “Operating Instructions” section, as shipping can loosen connections.

•  Check for leaks even if your unit was assembled for you by someone else.

• Do NOT operate if a gas leak is present. Gas leaks may cause a fire or explosion.

• You must follow all instructions in the “Checking for Leaks” section before operating. To prevent fire or explosion hazards when testing for a leak:
  a. Always perform a leak test before lighting the grill and each time the cylinder is connected for use.
  b. No smoking. Do NOT use or permit sources of ignition in the area while conducting a leak test.
  c. Conduct the leak test outdoors in a well-ventilated area.
  d. Do NOT use matches, lighters, or a flame to check for leaks.
  e. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly assemble or safely operate the appliance.
  f. Strong odors, colds, sinus congestion, etc. may prevent the detection of propane. Use caution and common sense when testing for leaks.
  g. Do NOT use grill until any and all leaks are corrected. If you are unable to stop a leak, disconnect the LP gas supply. Call a gas appliance serviceman or your local LP gas supplier.

• This grill is designed to operate at an inlet pressure of: 11 inches water column.

• LP gas cylinder must be arranged for vapor withdrawal.

• The LP gas cylinder must have a listed overfilling prevention device (OPD).

• Only use LP gas cylinders equipped with a cylinder connection device compatible with the connection for outdoor cooking appliances.

• The LP gas cylinder must have a cylinder collar to protect the cylinder valve.

• Never use a LP gas cylinder with a damaged body, valve, collar or footing.

•  Dented or rusted LP gas cylinders may be hazardous and should be checked by your LP gas supplier prior to use.

• The LP gas cylinder should not be dropped or handled roughly.

• LP gas cylinders must be stored outdoors out of the reach of children and must not be stored in a building,
  garage or any other enclosed area. Your cylinder must never be stored where temperatures can reach over 125°F.

•  Do NOT insert any tool or foreign object into the valve outlet or safety relief valve. You may damage the valve and cause a leak. Leaking propane may result in an explosion, fire, severe personal injury or death.

• Do NOT block holes in sides or back of grill.

• Never keep an LP gas cylinder in a hot car or trunk. Heat will cause the gas pressure to increase, which may open the relief valve and allow gas to escape.

• Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane.

•  If grill is not in use, the gas must be turned off at the supply cylinder and disconnected.

• Do NOT store a spare LP gas cylinder under or near this appliance.

• Never fill the cylinder beyond 80 percent full.

•  A fire causing serious injury or damage to property may occur if the above is not followed exactly.

• Never attempt to attach this grill to the self-contained LP gas system of a camper trailer, motor home or house.

• Your grill has been checked at all factory connections for leaks. Recheck all connections as described in the “Operating Instructions” section, as shipping can loosen connections.

• Check for leaks even if your unit was assembled for you by someone else.

•  Do NOT operate if a gas leak is present. Gas leaks may cause a fire or explosion.

• You must follow all instructions in the “Checking for Leaks” section before operating. To prevent fire or explosion hazard when testing for a leak:
  a. Always perform a leak test before lighting the grill and each time the cylinder is connected for use.
  b. No smoking. Do NOT use or permit sources of ignition in the area while conducting a leak test.
  c. Conduct the leak test outdoors in a well-ventilated area.
  d. Do NOT use matches, lighters, or a flame to check for leaks.
  e. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly assemble or safely operate the appliance.
  f. Strong odors, colds, sinus congestion, etc. may prevent the detection of propane. Use caution and common sense when testing for leaks.
  g. Do NOT use grill until any and all leaks are corrected. If you are unable to stop a leak, disconnect the LP gas supply. Call a gas appliance serviceman or your local LP gas supplier.

• This grill is designed to operate at an inlet pressure of 11 inches water column.

•  Do NOT store or use gasoline or other flammable liquids or vapors within 25 feet (7.62 m) of this appliance.

• Do NOT use it in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline , and other flammable vapors and liquids.

• Minimum clearance from sides and back of the unit to combustible construction is 36 inches (91.4 cm). Do NOT use this appliance under any type of overhang or roof.

• It is essential to keep the grill’s valve compartment, burners, and circulating air passages clean.

• Inspect the grill before each use.

• Do NOT alter the grill in any manner. Any alteration will void your warranty.

• Do NOT use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.

•  Do NOT build this model of the grill in any built-in or slide-in construction. Ignoring this warning could cause a fire or an explosion that can damage property and cause serious bodily injury or death.

• This grill should be thoroughly cleaned and inspected on a regular basis.

• Clean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior to operation.

• Use only the regulator and hose assembly provided. Use only the replacement regulator and hose assembly specified by RevoAce Inc. Limited

• Use only RevoAce Inc. Limited. factory-authorized parts. The use of any part that is not factory authorized can be dangerous and will void your warranty.

• Do NOT operate this appliance without reading “Operating Instructions” in this manual.

• Do NOT touch metal parts of the grill until they have completely cooled to avoid burns unless you are wearing protective gear (pot holders, gloves, BBQ mitts, etc.).

• Do NOT install or use in or on boats or recreational vehicles.

• When cooking, fire extinguishing materials should be readily accessible. In the event of an oil/grease fire, do NOT attempt to extinguish with water. Use type BC dry chemical fire extinguisher or smother with dirt, sand, or baking soda.

• Do NOT use the grill in high winds.

• Charcoal: Position grill so the wind cannot carry ashes to combustible surfaces.

• Never lean over the grill when lighting.

• Do NOT leave a lit grill unattended. Keep children and pets away from the grill at all times.

• Do NOT leave the grill unattended while preheating or burning off food residue on high. If the grill has not been cleaned, a grease fire can occur that may damage the product.

• Do NOT place empty cooking vessels on the appliance while in operation.

• Use caution when placing anything on the grill while the appliance is in operation.

• Do NOT attempt to move the grill when in use. Allow the grill to cool before moving or storing.

• LP gas cylinder must be properly disconnected and removed prior to moving this grill.

• Storage of grill indoors is permissible only if the cylinder is disconnected, removed from the grill, and properly stored outdoors.

• Charcoal: Never add lighting fluid to hot or warm coals as a flashback may occur causing serious injury or damage to property.

• Charcoal: Do NOT remove the ashes until they are completely and fully extinguished.

• Charcoal: Live hot briquettes and coals can create a fire hazard.

• Charcoal: Always empty the bottom bowl and grill after each use.

• Charcoal: Do NOT place fuel (charcoal briquettes, wood, or lump charcoal) directly into the bottom of the grill. Place fuel only on the charcoal pan/grid.

• Charcoal: Do NOT allow the charcoal to rest on the walls of the grill. Doing so will greatly reduce the life of the metal and finish of your grill.

• Charcoal: Check to make sure the air vents are free of debris and ash before using the grill.

• Charcoal: Extinguished coals and ashes should be placed at a safe distance from all structures and combustible materials.

• Charcoal: With a garden hose, completely wet the surface beneath and around the grill to extinguish any ashes, coals, or embers that may have fallen during the cooking or cleaning process.

• Always open grill lid carefully and slowly as heat and steam trapped within the grill can cause severe burns.

• Do NOT attempt to disconnect the gas regulator from the cylinder or any gas fitting while the grill is in use.

• Always place your grill on a hard, non-combustible, level surface. An asphalt or blacktop surface may not be acceptable for this purpose.

• Move gas hoses as far away as possible from hot surfaces and dripping hot grease.

•  Keep all electrical cords away from a hot grill.

• After a period of storage and/or nonuse, check for leaks, burner obstructions and inspect for any abrasion, wear, or cuts to the hose.

• Failure to open the lid while igniting the grill’s burners, or not waiting 5 minutes to allow the gas to clear if the grill does not light, may result in an explosive flare-up.

• Never operate grill without its heat plates installed.

• Always use a meat thermometer to ensure food is cooked to a safe temperature.

• Use protective gloves when assembling this product.

• Do NOT force parts together as this can result in personal injury or damage to the product.

•  Never cover the entire cooking area with aluminum foil.

• Death, serious injury, or damage to property may occur if the above is not followed exactly.

Expanded View

![RevoAce Outdoor LP Gas Charcoal Barbecue

• Expanded View2](https://manuals.plus/wp-content/uploads/2021/08/RevoAce- Outdoor-LP-Gas-Charcoal-Barbecue-Expanded-View2.jpg)

Parts List

• Pre-assembled

Hardware

Tools Required for Assembly (Included)

2 Phillips Head Screwdriver| ![RevoAce Outdoor LP Gas Charcoal Barbecue - #2

Phillips Head Screwdriver](https://manuals.plus/wp-content/uploads/2021/08 /RevoAce-Outdoor-LP-Gas-Charcoal-Barbecue-2-Phillips-Head-Screwdriver.jpg)| 1 pc
---|---|---
M10-M6 Wrench| | 1 pc
M10-M8 Wrench| | 1 pc

Assembly Instructions

DO NOT RETURN TO PLACE OF PURCHASE

Please have your Owner’s Manual and model number available for reference.
Note: The model number is printed on a label which can be found on the inside door, back or side of the cart assembly. Assembly Tips:

1. Select an area where you will assemble this product.
   To protect components, choose a smooth surface that’s free of cracks or openings.

2. Spread out all parts.

3. Tighten all hardware connections by hand first. Then, before completing each step, go back and fully tighten all hardware. Be careful not to over-tighten. That could
   damage surfaces or strip threads.

4. For best results, complete each step in the order presented.

To complete assembly you will need:

• PROPANE: (1) Leak detection solution (instructions on how to make the solution are included in the “Operating Instructions” section of this manual) (not included).
• PROPANE: (1) Precision-filled LP gas grill tank with Acme Type 1 external threaded valve connection (standard grill size) (not included).
• CHARCOAL: One bag of charcoal (not included).

Typical assembly is approximately one hour.

Attach Smoke Stack and Smoke Stack Top

Assemble Front, Center, Back Panels and Charcoal Pan Handle SupportCharcoal

Attach LP Gas Manifold, Regulator/Hose Assembly, Charcoal Door Handle and Charcoal Door Handle Support

Assemble LP Gas Panel, LP Gas Heat Shield and Front Heat Plate Support

Attach LP Gas Heat Shield

Attach Left Panel and Right Panel

Attach Receiver Tray Support

Attach Feet, Legs and Bottle Opener

Attach Bottom Shelf

Insert Axle and Attach Wheels

Attach Bottom Rack

Attach Bottom Hinges
Note: Do not tighten all screw C till step 22 is completed.

Attach Charcoal Pan

Attach Charcoal Pan Handle, Side Air Vent and Lighting Rod

Attach Igniter Wires and Burners

Attach Left Side Shelf and Tool Holders (Hardware F)

Attach Right Side Shelf

Attach Side Burner Gas Valve

Insert Side Burner, Igniter Wire and Side Burner Grid

Attach Lids

Attach LP Gas Tank Retainer Wire

Attach Tray Handles

Insert Ash Receiver Tray, Grease Receiver Tray and Control Knobs

Insert Grease Cup

Insert Warming Racks
Note: Charcoal warming rack is smaller / Gas warming rack is bigger.

Insert Heat Plates and Cooking Grids
Note: Charcoal cooking grid Dimension: 204x420mm.
Gas cooking grid dimension: 229x420mm.

Installing LP Gas Tank

To operate, you will need one precision-filled standard grill LP gas tank with external valve threads.

CAUTION

LP gas tank must be properly disconnected and removed prior to moving this grill.

Inserting / Securing LP Gas Tank
Place precision-filled LP gas tank upright into the notches in the right cart frame so the tank valve is facing the gas line connection.
Secure tank by sliding the tank retainer wire over shoulder of LP gas tank.

Installing LP Gas Tank (continued)

Connecting LP Gas Tank

1. Before connecting, be sure there is no debris caught in the head of the LP gas tank, head of the regulator valve or in the head of the burner or burner ports.
2. Connect regulator/hose assembly to the tank by turning the knob clockwise until it stops.

Disconnecting LP Gas Tank

1. Before disconnecting, make sure the LP gas tank valve is “CLOSED.”

2. Disconnect regulator/hose assembly from LP gas tank by turning the knob counterclockwise until it is loose.
   CAUTION: LP gas tank must be properly disconnected and removed prior to moving this grill.

3. Place the protective cap cover on the LP tank and store the tank outdoors in a well-ventilated area out of direct sunlight.

Operating Instructions

Checking for Leaks
Burner Connections

1. Make sure the regulator hose and valve connections are securely fastened to the burner and the tank.

2. Visually check the connection between the burner/venturi tube and orifice.

3. Make sure the burner/venturi tube fits over the orifice.

   WARNING: Failure to inspect this connection or follow these instructions could cause a fire or an explosion which can cause death, serious bodily injury, or damage to property.

4. Please refer to the diagram for proper installation (Figure 1 and 2).

5. If the burner/venturi tube does not rest flush to the orifice, as shown，please contact 1.800.694.0013 for assistance.

Tank/Gas Line Connection

1. Make 2-3 oz. of leak detection solution by mixing one part liquid dishwashing soap with three parts water.
2. Make sure control knobs are in the “ OFF” position (Figure 2).
3. Connect LP gas tank per “Installing LP Gas Tank” section.
4. Turn LP gas tank valve to “OPEN.”
5. Spoon several drops of solution, or use a squirt bottle, at all “X” locations (Figures 1, 2 and 4).

   a. If any bubbles appear, turn the LP gas tank valve to “CLOSED,” reconnect, and re-test.
   b. If you continue to see bubbles after several attempts, turn the LP gas tank valve to “CLOSED” and disconnect the LP gas tank, per
   “Disconnecting LP Gas Tank” section.
   c. If no bubbles appear after one minute, turn the LP gas tank valve to “CLOSED,” wipe away the solution and proceed.

Operating Instructions (continued)

Operating Main Burners
First Use

1. Make sure all labels, packaging and protective films have been removed from the grill.
2. Remove manufacturing oils before cooking on this grill for the first time by operating the grill for at least 15 minutes on (HIGH) with the
   lid closed. This will “heat clean” the internal parts and dissipate odors.

Lighting
CAUTION: Keep outdoor gas cooking appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
CAUTION: Do NOT obstruct the flow of combustion and ventilation air.
CAUTION: Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire.
CAUTION: Attempting to light the burner with the lid closed may cause an explosion.

1. Open lid.

2. Check for obstructions of airflow to the burners. Spiders, insects, and webs can clog the burner/venturi tube. A clogged burner tube can lead to a fire.

3. All control knobs must be in the “ OFF” position (Figure 3).

4. Connect LP gas tank per “Installing LP Gas Tank” section.

5.  Turn LP gas tank valve to “OPEN.”

6. Push and turn any control knob to (HIGH). The burner should light. If it does not, repeat up to three times.

7. If ignition does not occur in 5 seconds, turn the burner control knob “ OFF,” wait 5 minutes, and repeat the lighting procedure.

8. If the igniter does not light burner, use a lit match secured with the lighting rod (included with grill) to light burners. Access the burners through the cooking grid and heat plates. Position lit match near the side of the burner (Figure 5).
   Important: Always use the lighting rod (included) when lighting burners with a match.


9. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height matches the illustration (Figure 6).
   Note: Each burner lights independently – repeat steps 5-9 for the other burners.

   CAUTION: If burner flame goes out during operation, immediately turn the control knobs to the “ OFF” position, LP gas tank valve “CLOSED” and open lid to let the gas clear for 5 minutes before re-lighting.

Turning Off

1. Turn LP gas tank valve to “CLOSED.”

2. Turn all control knobs clockwise to the “ OFF” position.
   Note: A “poof” sound is normal as the last of the LP gas is burned.

3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.

Cooking

1. Open the lid and ignite the side burner per “Lighting” instructions.
2. Adjust control knob to desired flame height.
3. Place pan on the center of the grid.
4. Cook and adjust the temperature as needed.
5. Turn grill off per “Turning Off” instructions.

Operating Instructions (continued)

Operating Charcoal Grill

CAUTION: Never use charcoal that has been pre-treated with lighter fluid. Use only high-grade plain charcoal, charcoal/wood mixture, lump charcoal, or cooking wood.

First Use

1. Make sure all labels, packaging, and protective films have been removed from the grill.
2. Remove manufacturing oils before cooking on this grill for the first time, by operating the grill for at least 15 minutes with the lid closed.
   This will “heat clean” the internal parts and dissipate odors.

Lighting Instructions
  CAUTION: Keep outdoor cooking appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
CAUTION: Check to make sure the air vents are free of debris and ash before using the grill.
CAUTION: Attempting to light the grill with the lid closed may cause an explosion.
CAUTION: When using a liquid starter, always check the bottom bowl before lighting. Fluid can collect in the bottom bowl and could ignite, resulting in a fire.
CAUTION: Never add lighting fluid to hot or warm coals as flashbacks may occur, causing serious injury or damage to property.

1. Open lid and vents.
2. Make sure the bottom bowl is empty.
3. Remove the cooking grid.
4. Arrange charcoal briquettes or other fuel on the charcoal grid to the “Fill Line” (Figure 8).
5. Light per instructions on fuel package.
6. Allow fuel time to ash into glowing coals before cooking.

Turning Off

1. Allow charcoal to completely extinguish itself.
   WARNING: Do NOT use water to extinguish. This can be dangerous and cause damage.

2. Dispose of the ashes in a proper location.

Controlling Flare-ups:

CAUTION: Do NOT use water on a grease fire. This can cause the grease to splatter and could result in serious burns, bodily harm or other damage.
CAUTION: Do NOT leave grill unattended while preheating or burning off food residue. If grill has not been cleaned, a grease fire can occur that may damage the product.
WARNING: When cooking, fire extinguishing materials should be readily accessible. In the event of an oil/ grease fire, use a type BC dry chemical fire extinguisher or smother with dirt, sand or baking soda. Do NOT attempt to extinguish with water.
Flare-ups are a part of cooking meats on a grill and adds to the unique flavor of grilling.
Excessive flare-ups can overcook your food and can be dangerous.
Important: Excessive flare-ups result from the build-up of grease in the bottom of your grill.
If a grease fire occurs, close the lid until the grease burns out. Use caution when opening the lid as sudden flare-ups may occur.
If excessive flare-ups occur, do NOT pour water onto the flames.

Minimize Flare-ups:

1. Trim excess fat from meats prior to cooking.
2. Cook high-fat content meats indirectly.
3.  Ensure that your grill is on a hard, level, non-combustible surface.

Cleaning and Care

CAUTION

1. All cleaning and maintenance should be done when the grill is cool and with the fuel supply disconnected.


2. Do NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the finish.


3. Do NOT enlarge valve orifices or burner ports when cleaning the valves or burners.

NOTICE

1. This grill should be thoroughly cleaned and inspected on a regular basis.
2. Abrasive cleaners will damage this product.
3. Never use oven cleaner to clean any part of the grill.

Before Each Use:

1. Keep the grill area clean and free from any combustible materials, gasoline, and other flammable vapors and liquids.
2. Do NOT obstruct the flow of the combustion of LP gas and the ventilation of air.
3. Keep the ventilation opening(s) of the LP gas tank area free and clear from debris.
4. Visually check the burner flames to make sure your grill is working properly (Figure 9).
5. See sections below for proper cleaning instructions.
6. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/venturi tube. A clogged burner tube can lead to a fire.

Cleaning Surfaces

1. Wipe surfaces clean with mild dishwashing detergent or baking soda mixed with water.
2. For stubborn surfaces, use a citrus-based degreaser and a nylon scrubbing brush.
3. Rinse clean with water.
4. Allow to air dry.

Figure 9
Burner Flame Conditions
Use this chart to see if your burners need to be cleaned.

Normal: Soft blue flames with yellow tips between 1 in. – 2 in. height.

Cleaning Main Burners

1. Turn LP gas tank valve to “CLOSED.”

2. Turn all control knobs clockwise to the “ OFF” position.
   Note: A “poof” sound is normal as the last of the gas is burned.

3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.

4. Remove cooking grids and heat plates.

5. Remove burners by removing the fasteners, which secure the burners to the grill bottom.

6. Lift burners up and away from gas valve orifice.

7.  Disconnect wire from spark electrode.

8.  Clean venturi of each burner with a small bottle brush or compressed air.

9. Remove all food residue and dirt from the burner surface.

10. Clean any clogged ports with a stiff wire (such as an opened paper clip).

11. Inspect burners for any damage (cracks or holes). If damage is found, replace it with a new burner(s) from the manufacturer.

12. Re-install burner(s). Checking to ensure that gas valve orifice is correctly positioned inside each burner/venturi tube. Also, check the position of the spark electrode.

13. Replace heat plate(s) and cooking grid(s).

14. Connect LP gas tank per “Installing LP Gas Tank” section.

15. Perform leak test per “Checking for Leaks” section.

Needs cleaning: Noisy with hard blue flames.

Has to be replaced: Wavy with yellow flames.

Cleaning Side Burner

1. Turn LP gas tank valve to “CLOSED.”

2. Turn all control knobs clockwise to the “ OFF” position.
   Note: A “poof” sound is normal as the last of the gas is burned.

3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.

4. Remove side burner grid.

5. Remove burner by removing the screws that secure the burner to the side shelf

6. Lift burner up and away from gas valve orifice.

7. Clean venturi of the burner with a small bottle brush or compressed air.

8. Remove all food residue and dirt from the burner surface.

9. Clean any clogged ports with a stiff wire (such as an opened paper clip).

10. Inspect burner for any damage (cracks or holes). If damage is found, replace it with a new burner from the manufacturer.

11.  Re-install burner(s). Checking to ensure that gas valve orifice is correctly positioned inside each burner/venturi tube. Also, check the position of the spark electrode.

12. Replace cooking grid(s).

13. Connect LP gas tank per “Installing LP Gas Tank” section.

14. Perform leak test per “Checking for Leaks” section.

Before Storing

1. Turn LP gas tank valve to “CLOSED.”

2. Turn all control knobs clockwise to the “ OFF” position.
   Note: A “poof” sound is normal as the last of the gas is burned.

3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.

4. Clean all surfaces.

5. Lightly coat the burner(s) and cooking grid(s) with cooking oil to prevent excess rusting.

6. If storing the grill indoors, disconnect the LP tank per the “Disconnecting LP Gas Tank” section.

7. Place the protective cap cover on the LP tank and store the tank outdoors in a well-ventilated area out of direct sunlight.

8. If storing the grill indoors, cover the grill and store it in a cool dry place.

9. If storing the grill outdoors, cover the grill with a grill cover for protection from the weather.

Limited Warranty

RevoAce Inc. Limited (“RA”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled, maintained, and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year for all remaining parts from the date of purchase, all parts in such product shall be
free from defects in material and workmanship. RA may require reasonable proof of your date of purchase. Therefore, you should retain your sales slip or invoice. This Limited Warranty shall be limited to the repair or replacement of parts, which prove defective under normal use and service and which RA shall determine in its reasonable discretion
upon examination to be defective. Before returning any parts, you should contact RA’s Customer Care Department using the contact information listed below. If RA confirms, after examination, a defect covered by this Limited Warranty in any returned part, and if RA approves the claim, RA will replace such defective part without charge. If you return defective parts, transportation charges must be prepaid by you. RA will return replacement parts to the original retail purchaser, freight or postage prepaid. This Limited Warranty does not cover any failures or operating difficulties due to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance
or service by you or any third party, or failure to perform normal and routine maintenance on the product as set out in this owner’s manual. In addition, the Limited Warranty does not cover damage to the finish, such as scratches, dents, discoloration, rust, or other weather damage, after purchase.

This Limited Warranty is in lieu of all other express warranties. RA disclaims all warranties for products that are purchased from sellers other than authorized retailers or distributors, including the warranty of merchantability or the warranty of fitness for a particular purpose. RA ALSO DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
RA SHALL HAVE NO LIABILITY TO THE PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. RA further disclaims any implied or express warranty of, and assumes no responsibility for, defects in workmanship caused by third parties. This Limited Warranty gives the purchaser specific legal rights; a purchaser may have other rights depending upon where he or she lives. Some jurisdictions do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long a warranty lasts, so the above exclusion and limitations may not apply to everyone. RA does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return,
or replacement of its equipment and no such representations are binding on RA.

Manufactured in China for: RevoAce Inc. Limited
Hong Kong, China
1.800.694.0013 • service@revoace.com
8:00 am to 4:00 pm central time, Monday to Friday.

Troubleshooting

“Installing LP Gas Tank,” then turn LP gas tank valve to “OPEN”
LP gas tank is low or empty| Exchange, refill or replace LP gas tank
LP gas| 1. Turn LP gas tank valve to “CLOSED”
2. Wait 5 minutes for gas to clear
3. Follow the “Checking for Leaks” section
Wires or electrodes covered with cooking residue| Clean wire and/or electrode with rubbing alcohol
Electrode and burners are wet| Wipe dry with cloth
Electrode cracked/broken – sparks at crack| Replacement part(s) may be needed – contact Customer Care at 1.800.694.0013
Wire loose or disconnected| Reconnect wire or replacement part(s) may be needed – contact
Customer Care at 1.800.694.0013
Wire is shorting (sparking) between ignitor and electrode| Replacement part(s) may be needed – contact Customer Care at 1.800.694.0013
Bad igniter

| Replacement part(s) may be needed – contact Customer Care at 1.800.694.0013
The burner will not light with a match

| No gas flow| Check if LP gas tank is empty
A. If empty, exchange, refill or replace LP gas tank
B.  If LP gas tank is not empty, refer to “Sudden  drop in gas flow or reduced flame height” (see below)
LP gas tank is low or empty| Exchange, refill or replace LP gas tank
LP gas| 1. Turn LP gas tank valve to “CLOSED”
2. Wait 5 minutes for gas to clear
The “Checking for Leaks” section
Coupling nut and regulator not fully connected| Turn the coupling nut about one-half to three-quarters additional turn until solid stop. Tighten by hand only – do NOT use tools
Obstruction of gas flow| 1. Clear burner/venturi tube
2. Check for bent or kinked hose
Disengagement of the burner to valve| Reengage burner and valve
Spider webs or insect nest in venturi| Clean burner/venturi tube
Burner ports clogged or blocked| Clean burner ports
Sudden drop in gas flow or reduced flame height| Out of gas| Exchange, refill or replace LP gas tank
Overfilling prevention device may have been

activated

| 1. Turn control knobs to “    OFF”
2. Wait 30 seconds and light grill
3.  If flames are still too low, reset the overfilling prevention device:
a. Turn control knob(s) “    OFF”
b. Turn LP gas tank valve to “CLOSED”
c. Disconnect regulator
d. Turn control knobs to  (HIGH)
e. Wait 1 minute
f. Turn control knobs to “    OFF”
g. Reconnect regulator and leak check connections, being careful not to fully open valve
h. Light grill per “Lighting” section
Irregular flame pattern, flame does not run the full length of burner| Burner ports are clogged or blocked| Clean burner ports
Flame is yellow or orange| The new burner may have residual manufacturing oils| Burn grill for 15 minutes on   (HIGH) with the lid closed
Spider webs or insect nest in venturi| Clean venturi
Food residue, grease, etc. on burners| Clean burner
Poor alignment of the valve to burner/venturi tube| Ensure burner/venturi tube is properly engaged with the valve

Troubleshooting (Continued)

in gas flow or reduced flame height” (see above)
Flare-up| Grease buildup| Remove and clean all grill parts per the “Cleaning and Care” section
Excess fat in meat| Trim fat from meat before grilling
Excessive cooking temperature| Adjust to lower cooking temperature
Persistent grease fire| Grease trapped by food buildup around the burner system| Adjust to lower cooking temperature
1. Turn control knobs to “    OFF”
2. Turn LP gas tank valve to “CLOSED” 3. Leave lid in the closed position and let the fire burn out
4. After grill cools, remove and clean all parts per the “Cleaning and Care” section
Flashback (fire in burner tube(s))| Burner and/or burner/venturi tube are blocked| Clean burners and/or burner/venturi tube
Inside of lid is peeling (like paint peeling)| Baked on grease buildup has turned to carbon

and is flaking off.

| Clean all grill parts per the “Cleaning and Care” section.
