Yuyao Yunjin Electrical Appliance YJ-312 Smart RGBW LED String Light Instruction Manual

USTX-SMTSL01-1
Model: YJ-312

Smart RGBW LED String Light App Control

Can’t connect? Need help?
Email: MLambert@l63.com

Please read this manual before operation and keep it for future reference.

Parameters

Total Length: 49Ft (15M)
Number of Sockets: 15
Input Volts: 110-250V AC .
Output Volts: 12V DC
Rated Wattage: 7.5W
Max Wattage: 24W
Bulb Wattage (each): 0.5W
Bulb Type: S14| Socket Type: E26
Memory Function: Yes
Dimmable: Yes
Waterproof: IP65
Work with Alexa: Yes
Work with Google Voice Assistant: Yes
Connectable: MAX up to 3 strands
---|---

Step 1: Initial Setup

1. Carefully unpack Smart String Lights from the package.
2. Before installing, plug the Smart String Lights into an outlet to ensure all lights work properly.
3. Before hanging up, please test to confirm the Smart String Lights can be connected to the Smart Life APP.

IMPORTANT: Please unplug the Smart String Lights prior to mounting.

Step 2: Download APP

Download the Smart Life APP from App Store or Google Play.

Step 3: Register

1. Enter your email address, and create a password.| 2. Enter the verification code
---|---
|
3. Create a password and Log in to the App.| 4. Please enable the Smart Life app to get your Bluetooth while using it.
|

Step 4: Plugin

Plug Smart String Lights into any standard outlet.

Notes:

1. After power on, the light bulbs will automatically enter the connecting state (fast blinking);
2. If there is no connection after 3 minutes, the indicator lights will remain on. If you want to add a device at this time, you need to press and hold the power button on the controller for about 5 to 7 seconds until the lights blink rapidly.

Step 5: Add Device

Auto Scan

Select “Add Device” or click “+” at the top right corner of the homepage.| • Please enable the Smart Life APP to get your Access location while using the APR
• Fill in your 2.4GHz network name and password.
• Allow Smart Life APP to enable Bluetooth.
---|---
|
• The device in the connecting state will be displayed at the left of the page.| • Click “Next” and confirm your network again.
|
• The product starts to connect until it displays 100% complete.| • After you edit the product name and save it, click “DONE” at the top right.
|

Please keep the router, mobile phone, and product as close as possible to ensure a good reception signal.

Congratulation!
Now you can use Smart Life APP to control your string lights.

If your device is not automatically discovered, you can add it manually.

Add Manually
EZ Mode

Select “Add Device” or click “+” at the top right corner of the homepage.

Choose Lighting – String Lights -String Light (BLE+Wi-Fi) from the device list.

• Select “EZ Mode” in the upper right corner.
• If the light is not blinking rapidly automatically, please long-press the power button on the controller for about 5 to 7 seconds, until the string lights blink rapidly.
• And click “Confirm the light is blinking rapidly”.
• Follow the prompts on the interface to fall in your 2.4GHz Wi-Fi name and password, and click “Next”.
• The device enters the state of connecting and distributing the network, then waits for the completion of adding the device. Have difficulty pairing the string lights with EZ Mode? You could try the “AP Mode”

AP Mode: If you cannot add a device with EZ Mode, or you are not sure whether the network is 2.4GHz, please try “AP Mode”.

Add Manually
AP Mode

• Select “Add Device” or click “+” at the top right corner of the homepage.
• Choose Lighting – String Lights -String Light (BLE+Wi-Fi) from the device list.
• Select “AP Mode” in the upper right corner.
• Long-press the power button on the controller for about 5-7 seconds until the lights blink rapidly.
• Under the blinking state, long press the power button for about 5-7 seconds until the lights turn to slow blinking (blink 1 time every 3 seconds). If they still blink rapidly, repeat this step until they blink slowly.
• Click “Confirm the light is blinking slowly”.
• Follow the prompts on the interface to fill in your 2.4GHz Wi-Fi name and password, and click “Next”.
• Select the hotspot “SamrtLife-XXXX” in the available network to connect. Please confirm that the hotspot network is connected successfully, then go back to the APP to start the connection.
• The device enters the state of connecting and distributing the network! After the product is initialized, you can use Smart Life APP to control the string lights.

Besides “EZ Mode” and “AP Mode”, you can use “Bluetooth Mode” as well.

Add Manually
Bluetooth

• Under Bluetooth Mode, please make sure you fill in your 2.4GHz network name and password already. And click “Confirm the light has flashed or breathed”.
• Allow Smart Life APP to enable Bluetooth.
• After 1 device is found, click “+”.
• Confirm your network and click “Next”.

When adding 1 device successfully, Click “Next”.

Congratulation! Now you can use Smart Life APP to control your string lights.

Step 6: Installing

Please confirm that each light bulb can work normally and Smart Life APP can control the string lights. Then install it in the desired position.

1. When hanging the light string, it is recommended to use s-hooks, zip ties, etc. to hang the ring on the top of each bulb. If you can’t hang all of them, it’s better not to tighten the wires. Keep the wires lax to avoid breaking the signal line inside due to high tension or high gravity.
2. Or use a guidewire. Fix the guidewire to structure and then attach the rings above the bulbs to the guidewire by hooks, zip ties, etc.

White Mode

Color Temperature
Rotate the white wheel to adjust the color temperature of the white lights from 2700k to 6000k.

Brightness
Slide the “Brightness” bar to adjust the brightness of the string lights, then you can freely brighten or dim the lights.

Color Changing Mode

Color Wheel
Rotate the color wheel to adjust the color of the lights from a broad spectrum of colors.

Default Color
Or click the round color icons to choose a default color. You can also click the “+’ to add a default color.

Color Temperature
Slide the “Saturation” bar to adjust the color temperature of the string lights from cool to white.

Brightness
Slide the “Brightness” bar to adjust the brightness of the string lights, then you can freely brighten or dim the lights.

Scenes
Smart Life APP has a scene selection function. Press the scene button to enter the scene selection interface. You can choose your favorite scenes from 9 default scenes.

Pick 2
Hold the”Pick 2″ button for 2 seconds to activate the customized color scene. Pick two colors and customize their brightness and saturation as you like.

Schedule
The App is free to add and set the working time of the Smart String Light, which can be turned on and off freely according to the set time.

Select the time to repeat the setting within a week.

Define whether the set time is the beginning of the end of the work.

Troubleshooting Ways:

Cannot connect to your Wi-Fi network.

1. Please make sure your Wi-Fi router is under the 2.4 GHz setting, and the entered router password is correct.
2. If the Wi-Fi signal is too weak, reset your Wi-Fi router and try again.
3. Please enable the Smart Life APP to get your local location and Bluetooth.

The setup is not working properly.

1. Clean all apps that are running in the background then reopen the Smart Life APP;
2. Uninstall and reinstall the Smart Life APP then repeat the setup process.

The string lights are not responding to Smart Life APR

1. Delete the original connection record in-app and repeat the connection process.
2. Check if the string lights are turned off. If yes, turn them on and wait until lights reconnect with the Wi-Fi network automatically;
3. Check if there are problems with your internet connection. If necessary, reset your Wi-Fi router and try again.

The home network is 5.0GHz.
The wall penetration capability of 5.0GHz is weaker than 2.4GHz, which means that the outdoor signal of 5.0GHz is worse than 2.4GHz. Therefore, most smart devices support 2.4GHz networks or dual-frequency networks of 2.4GHz and 5.0GHz.

1. If you are using a dual-band router(2.4GHz and 5.0GHz frequency share a Wi-Fi account), you can connect the device using the AP mode.
2. Or you can log in to the management page of your router and change the SSIDs of the 2.4 GHz and 5.0GHz networks to differentiate them.

Email: MLambert@163.com

Caution

1. The product is NOT a toy. To avoid the risk of fire, burns, personal injury, or electric shock, please install in a place where children cannot reach.
2. To reduce the risk of electric shock, DO NOT operate when no bulbs on the sockets.
3. When the string light is used outdoor, please connect it to a Ground Fault Circuit Interrupting (GFCI) outlet.
4. DO NOT install near gas or electric heaters, fire, candles, or any dangerous places.
5. DO NOT use staples or nails to fix the wiring of the product, or place it on sharp hooks.
6. DO NOT place the string lights on the supply cord or any wire.
7. DO NOT cover the product with cloth, paper, or other objects when in use.
8. Unplug it when not used, store it in a cool, dry place and avoid sunlight, never leave it unattended.

After-sales Service Guarantee
A 12-Month warranty is provided for this device from the date of purchase. If you have any issues or queries when using this device, please sign in to Amazon and contact us or E-mail us via MLambert@163.com. Note: An order ID with a detailed description or image is preferred when contacting our customer service if possible.

Warranty

1. During the warranty period, we provide services including refund or replacement without charge to those who use the device in accordance with its intended use.
2. This warranty does not cover
   (A) Failure or damage due to improper use, repair, or remodeling.
   (B) Failure or damage because of falling.
   (C) Failure or damage caused by fire, earthquake, flood, lightning, and other natural disasters.
   (D) Failure or damage when used other than its intended use.
   (E) Failure or damage caused by third-party products other than this device.

Made in China

FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body.

FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.

NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
