DS18 Waterproof Bt Remote Controller – Square Owner’s Manual
BTRC-SQ
Congratulations on the purchase of the BTRC-SQ. It has been designed,
engineered
and manufactured for the highest level of performance and quality.
FEATURES
Waterproof universal BT remote controller.
Inputs & Outputs: USB Port
USB Charging (1A)
Two RCA Line out
AUX Input
General: IPX6
Illuminated Controls
WHAT’S INCLUDED
- BT remote controller
- 3.5mm Stereo wire
WARNING
While we have designed the mounting system to provide a safe and stable
installation, it is important to remember these are objects that will be used
in
an environment that is extremely bumpy and turbulent. Please consider all
possible scenarios where these will be placed and secured.
| NO. | OPERATIONS – CONTROLS |
|---|---|
| 1 | RCA Pre-Output: Audio Signal to the external amplifier |
(White: Left Ch, Red: Right Ch)
2| 3.5mm Jack Audio Input: Analog Audio Auxiliary input using a
stereo plug wire
3| USB Port: Connect a USB Drive up to 32Gb with MP3/WMA Audio files
4| Blue Wire: Remote Output, connect this to the external amplifier
5| Red Wire: ACC, connect this to an Accessory switch or a Master Switch,
this allows to turn on/off the device to avoid baery from discharging
when not in use
6| Yellow Wire with Fuse Holder: Power +12V, connect directly to the
battery source (positive)
7| Black Wire: Negative/Ground, Connect this directly to the Negative
post or chassis ground
CONTROLS FUNCTION
| NO | CONTROL | FUNCTION |
|---|---|---|
| 1 |  | Long press 3 |
seconds for Powe on / off
Short press for switching BT / Aux in / USB mode
2| | Short press for play / pause
Long press for LED off / on
3| | Short press for previous song
4| | Short press for next song
5| | Short press to increase volume by one scale
Long press to continuously increase volume
6| | Short press to decrease volume by one scale
Long press to continuously decrease volume
FUNCTION DEFINITION
| No | CONTROL | FUNCTION | REMARK |
|---|---|---|---|
| 1 |  | Press 3 |
seconds for power on. After turned on the
BTRC/SQ, the default red background light is always on.
After power on, the red/blue LED flashes alternately,
the BT is in searching situation, and the old connected
device will be searched synchronously and paired. When
the device is searched, only the blue light is on. The blue
light flashes quickly during the connection process and is
always on after connected.| Each time you
swithc the
sources mode,
you must set
the volume
back to 1/3 of
the total
volume.
2| | When play music in BT / AUX IN / USB mode, short press
for play/pause (AUX is mute); the corresponding indicator
light flashes during pause, long press to control the
background light to turn on and off.|
3| | When playing music in BT / AUX IN / USB mode,
short press for previous song.|
4| | When playing music in BT / AUX IN / USB mode,
short press for next song.|
5| | When playing music in BT / AUX IN / USB mode, short press
to increase volume by one scale; long press to continuously
increase volume. There is a beep when the volume is at its
maximum, and it will keep beeping if pressing.|
6| | When playing music in BT / AUX IN / USB mode,
short press to decrease volume by one scale; long press
to continuously decrease volume.|
7| BT
Connection| When BT is connected, the blue light will always be on,
and the volume synchronized with the phone.
BT device name: “DS18-BTRC”|
8| Auto
connect
function| BT will be disconnected if exceed the receiving range.
The red background light flashes quickly when BT is in
searching situation, and waiting for connection. When
the device returns to the range, it will be automatically
reconnected, the blue background light is always on.
Press play to continue play music and volume is the
same as earlier disconnection. While the device is not in
range, other devices can connect to BT.|
INSTALLATION
SEAMLESS FLUSH MOUNT MEASUREMENTS:
Overall Lenght: 3.81” / 97mm
Overall Depth: 1.47” / 37.4mm
Overall Height: 2.19” / 55.8mm
Mounting Hole Size: 1.99”x3.34″ / 50.7x85mm
SPECIFICATIONS
Frequency response: 20Hz-20Khz
Signal to noise ratio: ≧80dB
T.H.D: ≦0.1%
Channel Separation: ≧60dB
Power: DC 12V-14.4V
BT Wireless: Ver. 5.0
RCA Line Out (Pre-Amp): Ver. 5.0
Aux Line Input: 1 Pair (Left & Right) 2.5Volts
Remote Out: Plug 3.5mm
USB Player: 200mA 4Ft Extension Cord
FOR MORE INFORMATION PLEASE VISIT DS18.COM
