Chuangxin BabyN-EBG01 Intelligent Diaper Monitor User Manual

Chuangxin BabyN-EBG01 Intelligent Diaper Monitor

Product Information

Specifications

• Battery Type: Li-ion Polymer Battery
• Standby Time: 1.5 days
• Charging Time: Approx. 2 hours

Product Usage Instructions

Velcro Removal and Installation

To remove the Velcro:

1. Pinch the host body, and then push any two corners of the snap to the back to separate the host body from the Velcro.
2. Pinch the middle of the product connection line, and then tear it to the front to take off the tail of the Velcro.

To install the Velcro:

3. Ensure that the patterned side of the Velcro is facing you.
4. Insert the Velcro into the fixed holes on the snap, and then attach the host to the snap.
5. Vertically attach the Velcro, with the hook side facing towards you.
6. Align the tail of the Velcro with the upper edge of the magic hair and the magic hook, and paste them together.

Charging
To charge the device:

1. Connect the Type-C end of the charging cable to the host, and the other end to a power adapter (5V / 1A).
2. When the device is charging, the red light will be continuously on.
3. When the device is fully charged, the red light will turn off.

Pairing

1. Turn on the toggle switch until the blue light flashes for 3 seconds, indicating that the device is powered on and ready for pairing.
2. Scan the QR code on the box or search for “GoBabyN” in Google Play for the iOS system, or search for “BabyN” for the Android system.
3. Connect the device by selecting it from the device list in the app.

Wearing the Device

1. Attach the device to the reference location of the diaper according to the provided diagram, considering the front and back of the diaper.
2. Attach the rear part of the device to the reference position of the urine spot of the diaper.

FAQ

• Q: How long does the battery last?
  A: The battery has a standby time of 1.5 days.

• Q: How long does it take to fully charge the device?
  A: It takes approximately 2 hours to fully charge the device.

• Q: How can I pair the device with my smartphone?
  A: Turn on the device, open the app, and follow the instructions to connect the device from the device list in the app.

Let each guardian can scientific parenting, bring better care and health to the baby.

PREFACE

Thank you for choosing BabyN Intelligent Diaper Monitor， Monitor designed by Shenda Chuangxin (Shenzhen) Technology Co., Ltd. In order to make your experience with the product easy, we have provided detailed instructions for use. You can get knowledge about the product, how to use it, etc. Please read the manual carefully before you use the device. We hope you will understand if there are any printing errors or translation mistakes. Our Diaper Monitor radiation is less than the national standard, long-term attached to the use of the user will not produce radiation damage, and the device are environmentally friendly materials, Velcro using non-woven composite way more skin care.

In order for users to use Diaper Monitor correctly and ensure good product performance, please read carefully and comply with:

1. Do not seriously hit the host or high-frequency vibration.
2. Do not expose to benzene, thinner, high concentrations of corrosive and other chemicals or places with volatile gases.
3. Do not splash or immerse the sensor location in water.
4. Do not be near strong magnetic or electric fields.
5. Avoid direct light or heat generating appliances.
6. Do not disassemble or repair by yourself.
7. Please dispose of the waste packaging, batteries and old electronic products properly.
8. Do not let the baby play with the product like a toy, in order to avoid unnecessary safety problems.
9. Do not touch/disturb the sensors while detecting.

PRODUCT

Your BabyN-EBG01 Intelligent Diaper Monitor

Package Description

Recognize BabyN-EBG01 Intelligent Diaper Monitor

Velcro removal and installation

Removal of Velcro：

1. Pinch the host body, and then push any two corners of the snap to the back, you can separate the host body from the Velcro. As shown in the figure below:
2. Pinch the middle of the product connection line, and then to the front tear, you can take off the tail of the Velcro. As shown in the following figure:
3. Velcro will have the patterned side facing you, and then the Velcro in accordance with the fixed holes into the snap, and then the host into the snap. As shown in the following figure:
4. Let a vertical way of Velcro, hook side toward themselves, the tail of the upper edge of the magic hair and the magic hook and level centered paste, as shown in the following figure:

Charging

The distribution of Type-C into the host, the other end of the USB into the power adapter (5V/1A).

• Charging in: when the device is charged in, the red light is always on.
• Fully charged: when the device is fully charged, the red light is off.

Description:

Pairing

1. Turn on the toggle switch，until the blue light flash for 3 seconds，indicating that the power on successfully waiting for pairing.
2. Scan the QR code on the box, or go to Google Play to search “GoBabyN” for the iOS system,otherwise, search “BabyN” for Android system.(The QR code appears on the first page of the instruction book)

Wearing the device

1. Attach the device to the reference location of the diaper according to the diagram below. (note the front and back of the diaper)
2. Attach the rear part of the device to the reference position of the urine spot of the diaper according to the figure below.
3. Then put the diaper with the device attached onto the baby.

Note:

1. After the baby wears the diaper with the device attached, make sure that there is no obvious offset and gap between the diaper and monitor otherwise, the monitoring results will be affected.
2. After the initial connection of the device, the device will have a warm-up time of three minutes, this process is not monitored.

Desorption equipment

The host is desorption from the diaper in the following manner.

TROUBLESHOOTING

Before contacting the after-sales department, it is recommended that you review the following for a possible solution:

1. The device is not connected
   Due to the problem of signal interference in the wireless connection, the connection time may vary from time to time. If you can not connect for a long time, you can try the following methods and then reconnect:

2. Switching the device back on and off.

3. Restart the phone/APP, or reconnect in the device list.

4. Check whether the device has power.

5. The device can not be charged
   Please check whether the host and charging cable are in good contact. The red light will be on when the device is charging, and the charging status and power will be displayed on the data page after the device is connected to the phone.

6. Abnormal device data
   Avoid the device in a bad working environment, which will cause irreversible damage to the device (refer to Notes). Place the power-on device in a clean environment for a period of time, and connect the phone to observe the data.

BASIC PARAMETERS

• Product Name: BabyN-Intelligent Diaper Monitor
• Product Model: BabyN-EBG01
• Battery Capacity: 110mAh
• Connection Method: Wireless
• Material: ABS, TPU
• Weight: 20g
• Battery Type: Li-ion Polymer Battery
• Charging Method: DC 5V (Type-C)
• Dimensions: Length 147mm Width 34.5mm Thickness 12.9mm Length 194mm Width 80.2mm Thickness 12.9mm (Including Velcro)
• FCC ID: 2BD3D -BABYNEBG01
• Support System: Android 6.0 or iOS 11.0 and above

FCC STATEMENT

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures:

• Reorient the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into and outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

The distance between user and products should be no less than 20cm The EUT is Indoor use only

Shenda Chuangxin (Shenzhen) Technology Co., Ltd.

• Official Website:www.gobabyn.com
• Service Hotline: + 86 400-881-9391 (Weekday 9:00-18:00)

After sales support provided by Shenda Chuangxin (Shenzhen) Technology Co., Ltd.
